Main Unit; Rear View; Right Side View; Left Side View - Wintal MICRO4PRO User Manual

Main Unit

Rear View

1 3�5mm
Composite AV
Out
2 IR Input
3 S/PDIF (Optical)
audio out
4 HDMI Output
5 RJ-45 Ethernet
Port
6 2�1mm DC Input

Right Side View

1 USB1 Port
2 USB2 Port

Left Side View

1 SD / SDHC
Reader
Wintal Micro4Pro User Manual
1 3
2
For older displays� You can find a 3�5mm to 3 x RCA lead
in the box�
Connect the included IR receiver if you are hiding the
Micro4Pro behind TV where IR signals can't reach�
For the best digital audio connection to your TV or
speaker�
HDMI 2�0 for greater support
Wired connection to your local network
5V 2A via included power supply
USB 2�0
USB 3�0
USB 2�0
5
4 6
