ALLEN & HEATH CQ-12T Fitting Instructions

CQ-12T and CQ-18T Rack Kit
The CQ12T-RK19 and CQ18T-RK19 kits contain the rack ears and fixing screws
required to mount either a CQ-12T or CQ-18T mixer in a standard 19" rack or case.
Before continuing, ensure that you have the correct kit for your mixer.
The width of each ear is approximately 4" (or 100mm) in the CQ12T-RK19 kit and
approximately 3" (75mm) in the CQ18T-RK19 kit.

Contents

CQ12T-RK19
Item Code
AA12670-L
AA12670-R
AB0332
CQ18T-RK19
Item Code
AA12669-L
AA12669-R
AB0332

Tools required

Fitting ears to the unit

1. Place the CQ face down on a padded surface, taking care not to put
undue pressure on the encoders or touchscreen.
2. Line up the rack ears with the unused screw holes at either side of the
CQ, near to the rubber feet, so that the front panel of the ears are parallel
to the front of the CQ. Each ear will only align correctly with one side.
3. Secure each rack ear using two of the provided M4 Torx® screws.
Use only the supplied fixings to attach the rack ears to the CQ. Using

other fittings may cause damage to the unit and/or rack ears.
When fitted, there will be a small gap between the ears and sides of

the CQ to prevent damage to either.
CQ-12T and CQ-18T Rack Kit Fitting Note
Copyright © 2021 Allen & Heath Ltd, Kernick Industrial Estate, Penryn, TR10 9LU, UK. All rights reserved.
Description
RACK EAR CQ12T 19" LEFT
RACK EAR CQ12T 19" RIGHT
SCREW M4X8 PAN TORX BK
Description
RACK EAR CQ18T 19" LEFT
RACK EAR CQ18T 19" RIGHT
SCREW M4X8 PAN TORX BK
®
Torx T20 driver
1
Fitting Note
Quantity
1
1
4
Quantity
1
1
4
AP12813 iss.1
