CQ-20B Rack Kit
The CQ20B-RK19 kit contains the rack ears and fixing screws required to mount a
CQ-20B in a standard 19" rack case.
Contents
CQ12T-RK19
Item Code
AA12065
AA12066
AB0332
Tools required
Fitting ears to the CQ-20B
1.
Place the CQ-20B on a padded surface with the sockets facing down.
2.
Line up the rack ears with the unused screw holes on the underside of the
unit, near to the rubber feet, so that the front panel of each ear is parallel
to the front (socket) panel of the CQ. Each ear will only align correctly with
one side and the right hand ear includes a cut-out for the fan.
3.
Secure each rack ear using two of the provided M4 Torx® screws.
Use only the supplied fixings to attach the rack ears to the CQ. Using
other fittings may cause damage to the unit and/or rack ears.
When fitted, there will be a small gap between the ears and sides of
the CQ to prevent damage to either.
CQ-20B Rack Kit Fitting Note
Copyright © 2021 Allen & Heath Ltd, Kernick Industrial Estate, Penryn, TR10 9LU, UK. All rights reserved.
Description
RACK EAR CQ20B 19" LEFT
RACK EAR CQ20B 19" RIGHT
SCREW M4X8 PAN TORX BK
®
Torx
T20 driver
1
Fitting Note
Quantity
1
1
4
AP12817 iss.1
