General Maintenance - EGO PSX2510 Operator's Manual

NOTICE:
For second and final cuts (from the top of the
limb or branch), hold the bucking spikes against the
limb being cut (Fig. M3). This will help to steady the limb
and make it easier to cut. Allow the chain to cut for you;
only exert light downward pressure. If you force the cut,
damage to the bar, chain, or motor can result.
4. Release the trigger switch as soon as the cut is
completed.
NOTICE:
Failure to follow proper cutting procedures will
result in the bar and chain binding and becoming pinched
or trapped in the limb. If this happens:
1. Stop the motor and remove the battery pack.
2. If the limb can be reached from the ground, lift the
limb while holding the saw. This should release the
"pinch" and free the saw.
3. If the saw is still trapped, call a professional for
assistance.
Limbing and pruning
This pole saw is designed for trimming small branches
and limbs up to 200mm in diameter. For best results,
observe the following precautions:
◾
Plan the cut carefully. Be aware of the direction in
which the branch will fall.
WARNING:
Branches may fall in unexpected
directions. Do not stand directly under the branch being
cut.
◾
The most typical cutting application is to position
the unit at an angle of 60° or less, depending on the
specific situation, as shown in Fig. M4. As the angle
of the pole saw shaft to the ground increases, the
difficulty of making the first cut (from the underside of
limb) increases.
◾
Remove long branches in several stages.
◾
Cut lower branches first to allow the top branches
more room to fall.
◾
Work slowly, keeping both hands on the saw with a
firm grip. Maintain secure footing and balance.
◾
Keep the tree between you and the chain while
limbing. Cut from the side of the tree opposite the
branch you are cutting.
◾
Do not cut from a ladder; this is extremely dangerous.
Leave such operations for professionals.
◾
Do not make the flush cut next to the main limb or
trunk until you have cut off much of the limb to reduce
the weight. Following proper cutting procedures will
prevent stripping the bark from the main member.
14
56-VOLT LITHIUM-ION COMMERICAL POLE SAW — PSX2510
◾
Do not use the pole saw for felling or bucking.
◾
To prevent electrocution, do not operate within 15 m of
overhead electrical lines (Fig. M4).
◾
Keep bystanders at least 15 m away (Fig. M4).
MAINTENANCE
WARNING:
When servicing, use only identical
replacement parts. Inspect and maintain the machine
regularly. To ensure safety and reliability, all repairs should
be performed by a qualified service technician.
WARNING
: Before inspecting, cleaning or servicing
the unit, stop the motor, wait for all moving parts to stop,
and remove the battery pack. Failure to follow these
instructions can result in serious personal injury or
property damage.
NOTICE:
Before each use, inspect the entire product
for damaged, missing, or loose parts such as screws,
nuts, bolts, caps, etc. Tighten securely all fasteners and
caps and do not operate this product until all missing or
damaged parts are replaced. Please contact customer
service or a qualified service technician.

GENERAL MAINTENANCE

Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, oil, grease, etc.
CLEANING
◾
After each use, clean debris from the chain and guide
bar with a soft brush. Wipe the pole saw surface with a
clean cloth moistened with a mild soap solution.
◾
Remove the side cover, and then use a soft brush to
remove debris from the guide bar, saw chain, sprocket
and side cover.
◾
Always clean out wood chips, saw dust, and dirt from
the guide bar groove when replacing the saw chain.
◾
All pole saw service, other than the items listed in
these maintenance instructions, should be performed
by competent pole saw service personnel.
REPLACING THE BAR AND SAW CHAIN
WARNING:
Always wear gloves when handling the
bar and chain; these components are sharp and may
contain burrs.
WARNING
: Never touch or adjust the chain while
the motor is running. The saw chain is very sharp; always
wear protective gloves when performing maintenance to
the chain.
