http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
Before you commence the assembly process, we recommend that you read these instructions
thoroughly beforehand to familiarize yourself with the assembly process and to also check that
you have the correct components. If for any reason you need assistance, you can find our
contact details on the top of page of these instructions.
We highly recommend that any assembly is carried out on a flat, level surface if possible and
that you use another person to assist you if necessary for your convenience all guide holes are
pre-drilled.
Package contents:
• 1x Back panel
• 1x Doors
• 2x Side panels
• 1x Roof
• 1x Metal bards
• 1x Front bar
• 1x Shelf (If added to the kit)
• 40mm screws
• 32mm Black screws
• 80mm screws (If have multi-bay option)
Please note that per additional bay all the
package continents multiply.
.
Binbreeze / Verdibin Assembly Instructions
Tools required:
Electric screwdriver with No2 Pozidrive
bit or No2 Pozidrive screwdriver
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Arbor Technology Binbreeze
Summary of Contents for Arbor Technology Binbreeze
- Page 1 Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR Binbreeze / Verdibin Assembly Instructions Before you commence the assembly process, we recommend that you read these instructions thoroughly beforehand to familiarize yourself with the assembly process and to also check that you have the correct components.
- Page 2 Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR Step 1 Step 2 Begin by selecting one side panel and one back panel. Position BinBreeze Model them according to the configuration displayed in the Align the side panel and the back panel so that the accompanying illustration.
- Page 3 Repeat the procedures outlined in Steps 2 and 4 for depicted in the reference image. This bar will typically be the BinBreeze model, or Steps 3 and 4 for the fixed horizontally across the front upper section of the side VerdiBin model, to assemble the remaining side panels.
- Page 4 01945 410950 support@arborgardensolutions.co.uk http://www.arborgardensolutions.co.uk Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR Step 9 Step 10 Install the second shelf by mirroring the instructions Align the roof by positioning its hinges in line with the 1x4 from Step 8. Secure it to the side panels with six 40mm wooden slats of the back panel.
- Page 5 01945 410950 support@arborgardensolutions.co.uk http://www.arborgardensolutions.co.uk Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR Step 13 Step 14 Align the door hinges with the assembly, noting that doors Position the door latch at a height that is convenient for you. can be installed on either side to suit your preference or Secure it in place using six black screws, ensuring it is spatial requirements.
- Page 6 01945 410950 support@arborgardensolutions.co.uk http://www.arborgardensolutions.co.uk Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR Step 17 Step 18 Your multi-bay wheelie bin storage is now complete. Proceed to align another wheelie bin storage unit with Should you have additional bays to incorporate, simply the one that has the wooden circle spacers in place.
