INSTRUCTION MANUAL
General Description
The Hy-Gain Model 5BDQ-S is a half-
wavelength doublet antenna for 10, 15, 20,
40, and 80 meters. Matched Hy-Gain Hy-Q
traps allow automatic band switching. The
15-20 meter wire is fanned below the 10-40-
80 meter wire to minimize loading. The
maximum overall length is 93' 8".
To further improve the performance of the
5BDQ-S, a Hy-Gain balun Model BN-86 is
recommended. The Model BN-86 is a broad-
band balun designed specifically for doublet
type antennas. It will balance the input im-
pedance
to
the
transmission line radiation to increase the ef-
ficiency of a doublet type antenna.
Overall Length
Maximum Wind Survival
Antenna Wire
Frequency Range
Input Impedance
SWR at Resonance
Maximum Power
Cycolac® is a registered trademark of Borg Warner
Alumoweld® is aegistered trademark of Copperweld Bimetallic
Group
antenna
and
prevent
Specifications
ORDER NO. 383S
Model 5BDQ-S, Doublet Antenna
with Stainless Steel Hardware
Construction
The Hy-Q traps are weather resistant. All
hardware is stainless steel. The center of the
doublet is supported by a yoke-type center
insulator to which the transmission line
attaches. The ends of the doublet are
supported by end insulators constructed of
high impact Cycolac© plastic. The antenna
wire is Alumoweld© #12 which has a
breaking strength of 1200 pounds. It will not
rust or corrode. See "Hints on Handling
Alumoweld© Wire" in the rear of this
manual.
SWR and Feedline
The Model 5BDQ-S antenna is designed for
use with a single 50-ohm coaxial feedline.
The SWR at resonance is 1.5:1 or less on all
bands. Either RG-58/U or RG-8/U can be
used. RG-8/U polyfoam type is reconunended
because of its lower losses and higher power
handling capabilities.
Mechanical
Electrical
93' 8" maximum (48.67m)
80 mph (129 kmph)
Alumoweld® #12
10,15,20,40, and 80 Meters
50 ohms unbalanced
Less than 1.5:1
1 kW AM, 2 kW PEP

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5BDQ-S and is the answer not in the manual?

Questions and answers

Summary of Contents for Hy-Gain 5BDQ-S

  • Page 1 INSTRUCTION MANUAL Construction General Description The Hy-Q traps are weather resistant. All The Hy-Gain Model 5BDQ-S is a half- hardware is stainless steel. The center of the wavelength doublet antenna for 10, 15, 20, doublet is supported by a yoke-type center 40, and 80 meters.
  • Page 2 When suspending the antenna, keep the 10- Installation Notes 4080 meter wire as nearly horizontal as Suspend the antenna by attaching the end in- possible and fan the 15-20 meter wire below sulators to a stable structure. The center it, observing the maximum and minimum insulator may be supported by the antenna separation distance as shown in Figure 1.
  • Page 3 SECTION Mode of Operation English Metric English Metric English Metric English Metric English Metric Low CW 2 0 1 3 m m 8 ' 5 1 /2 " 2 5 7 8 m m 2 8 ' 9 3 /4 " 8 7 8 2 m m 8 ' 7 "...
  • Page 4 Clip off all excess wire extending past the Step-by-Step Assembly wire lock. Assemble the center insulator as shown in Figure 2. First place one half of the insulator Select the 10-meter trap and the trap on a flat surface with the inside facing up. connector clamps.'Assemble the clamps on Assemble the hardware on eyebolts and place both ends of the trap using the # 10-24 x 11/2...
  • Page 5 Item Description Description Insulator, center Nut, Hex, #8-32, Stainless steel Lock, wire Lockwasher, internal, 1/4", stainless steel Bolt, round head, #8-32 x 1/2", stainless steel Flatwasher, 1/4", stainless steel Bolt, round head, #6-32 x 3/8", stainless steel Lockwasher, internal, #8, stainless steel Eyebolt,1/4"...
  • Page 6 Connect the antenna wire (other end Attach the wire to the end insulator as shown connected to 10-meter trap) to the 40-meter in Figure 5. Clip off all excess wire extending trap as shown in Figures 1 and 4. Be sure that past the wire lock.
  • Page 7 Figure 5 Assembly of the Antenna Wire to the End Insulator There may be some difficulty encountered in Your 5BDQ-S is now ready to install. Again, its frequency to kink. Kinks may be removed carefully read the installation instructions by a pole or similar stationary curved object before suspending the antenna.
  • Page 8: Parts List

    PARTS LIST Part No. Description- 691136 Rope, polypropylene, 5/32" x 100' ... . . 1 691458 Antenna Wire, Alumoweld(R), #12x 125' ..1 861021 Insulator, End .
