Key Chain Remote Model KR10A Set Up and Operating Instructions
Installation
1. Install two AAA alkaline batteries in the battery
compartment on the back of the KR10A Remote.
2. Press ARM on the KR10A. Its red indicator light blinks
twice.
3. Set the INSTALL/RUN switch on the Console to
INSTALL.
4. Press ARM on the KR10A. The Console beeps.
5. Set the Console's slide switch back to RUN1 or RUN2.
To set up additional Key Chain Remotes (up to 16), repeat
above steps.
BATTERY
ARM
DISARM
LIGHTS
ON
LIGHTS
OFF
Note: If you do not hear a beep in step 4 above, remove
the batteries and then hold down the ARM button for 3
seconds. Refit the batteries and press ARM again. The
LED indicator will flash twice. You can now repeat steps
3, 4, and 5. You can install any combination of Remote
Control types for a total of up to sixteen Remote Controls.
For example, you can install eight Key Chain Remotes and
eight Security/Home Automation Remotes (SH624) or any
other combination for a total of sixteen.
Operation
Note: The Key Chain Remote Control always arms the
Console in the INSTANT mode.
1. Set the Console's INSTALL/RUN switch to RUN1 or
RUN2.
2. Press ARM. The Console beeps and the ARMED
indicator turns on.
If you now open a door or window, the alarm instantly
trips, the siren sounds, lights connected to Lamp Modules
and Wall Switch Modules (set to the same Housecode as
the Console) flash on and off, and the dialer dials out.
X10.com, a Div. of X10 Wireless Technology, Inc.
For additional help, visit www.x10.com/support
PANIC
3. Press DISARM to stop the siren. Lights connected to
X10 Modules remain on.
4. Press LIGHTS OFF on the KR10A to turn off lights
connected to X10 Modules set to the same Housecode
and Unit Code as the Console.
5. Press LIGHTS ON on the KR10A to turn on lights
connected to X10 Modules set to the same Housecode
and Unit Code as the Console
6. Press ARM and DISARM at the same time on the
KR10A to trip the Panic Alarm.
Replacing batteries
Slide the battery compartment cover off and replace the
batteries with two AAA alkaline batteries. After replacing
the batteries, the following steps are necessary to determine
that the Console still recognizes the remote control.
1. Place the Console's slide switch to RUN1 or RUN2.
2. Press ARM on the KR10A. If the system arms, the
Console recognized the KR10A and no further action
is necessary.
If the Console did not arm:
1. Place the slide switch to INSTALL.
2. Press ARM on the KR10A. The red indicator light
flashes once, and Remote Control transmits a random
code to the console. The Console acknowledges this
with a beep and logs in the KR10A.
F.C.C. CAUTION - THIS DEVICE COMPLIES WITH PART 15
OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY
NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS
DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
NOTE: NO CHANGES OR MODIFICATIONS MAY BE MADE
TO THE UNITS. ANY CHANGES MADE TO THE UNITS
WILL VOID THE USER'S AUTHORITY TO OPERATE THE
EQUIPMENT.
LIMITED 1-YEAR WARRANTY
Please visit www.x10.com/warranty
to complete your on-line warranty registration. Thank you.
For help or more information on setup, please visit:
www.x10.com/support
KR10A-8/02
