SPLIT-TYPE AIR CONDITIONERS INDOOR UNIT MS-SGG09VC MS-SGG13VC For user OPERATING INSTRUCTIONS English • To use this unit correctly and safely, be sure to read these operating instructions before use. www.ttair.co.th | Tel : 02-385-0728 | E-mail : sales@ttair.co.th | LINE ID : @ttair...
● OPERATING INSTRUCTIONS ● SAFETY PRECAUTIONS NAME OF EACH PART PREPARATION BEFORE OPERATION SELECTING OPERATION MODES FAN SPEED AND AIRFLOW DIRECTION ADJUSTMENT ECONO COOL OPERATION POWERFUL COOL OPERATION TIMER OPERATION (ON/OFF TIMER) CLEANING WHEN YOU THINK THAT TROUBLE HAS OCCURRED WHEN THE AIR CONDITIONER IS NOT GOING TO BE USED FOR A LONG TIME INSTALLATION PLACE AND ELECTRICAL WORK SPECIFICATIONS...
AFETY PRECAUTIONS CAUTION Do not operate switches with wet hands. • This may cause electric shock. Do not step on an unstable bench to operate or clean Do not clean the air conditioner with water or place an the unit. object that contains water, such as a fl...
● OPERATING INSTRUCTIONS ● AME OF EACH PART Indoor unit Indoor unit Remote controller Air cleaning fi lter Signal transmitting section Distance of signal : About 6m Heat exchanger Beep(s) is (are) heard from the indoor unit Air inlet when the signal is received.
ELECTING OPERATION MODES I FEEL mode The unit selects the operation mode according to the room temperature when I FEEL is selected. When the room temperature is higher than 25°C, COOL is selected (set temperature: 24°C). When the room temperature is lower than 25°C, DRY is selected.
● OPERATING INSTRUCTIONS ● AN SPEED AND AIRFLOW DIRECTION ADJUSTMENT Airflow direction (AUTO) ..The vane is set to the most effi cient airfl ow direction. : horizontal position. (Manual) ..For efficient air conditioning, select the upper position for COOL/DRY. If the position (2),(3),(4) is selected during COOL/ DRY, the vane automatically moves to the position (1) after 0.5 to 1 hour to prevent any condensation from dripping.
CONO COOL OPERATION IMER OPERATION (ON/OFF TIMER) Press during COOL mode page 4 to start Press during operation to set the timer. ECONO COOL operation. Each press changes timer mode in the following order: The unit performs swing operation vertically in various cycle according TIMER to the temperature of the unit.
● OPERATING INSTRUCTIONS ● LEANING Instructions: • Switch off the power supply or turn off the breaker before cleaning. • Use only diluted mild detergents. • Be careful not to touch the metal parts with your hands. • Do not expose parts to direct sunlight, heat, or fl ames to dry. •...
HEN YOU THINK THAT TROUBLE HAS OCCURRED Symptom Explanation & Check points Even if these items are checked, when the unit does not recover from the trouble, stop using the air conditioner and consult your dealer. Remote controller The display on the remote •...
WB: Wet Bulb Environment care Mitsubishi Electric Air conditioner has been designed environment-friendly. The plastic composition can be used as recycle part. For the optimum effi ciency and energy saving, users recommended to operate air conditioners as following suggestion. Turn off air conditioner in case of not in use.
Page 20
HEAD OFFICE: TOKYO BLDG., 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN SG79F522H01 www.ttair.co.th | Tel : 02-385-0728 | E-mail : sales@ttair.co.th | LINE ID : @ttair...
