  • Page 1 Operator’s Manual Floorsaw MFS735-CE 5100055241 0420...
  • Page 2 Wacker Neuson Machinery (China) Co., Ltd. Any type of reproduction or distribution not authorized by Wacker Neuson Machinery (China) Co., Ltd. represents an infringement of valid copyrights. Violators will be prosecuted.

  • Page 3: Foreword

    (China) Co., Ltd. will be referred to as Wacker Neuson. Keep a copy of the Operator’s Manual with the machine at all times. If you are missing any of these documents, please contact Wacker Neuson to order a replacement or visit www.wackerneuson.com.
  • Page 4 The information contained in this manual is based on machines manufactured up until the time of publication. Wacker Neuson reserves the right to change any portion of this information without notice. The illustrations, parts, and procedures in this manual refer to Wacker Neuson factory-installed components.

  • Page 5: Table Of Contents

    MFS735 Table of Contents Foreword Safety Information Signal Words Used in this Manual ............7 Machine Description and Intended Use ..........8 Operating Safety .................. 9 Operator Safety while Using Internal Combustion Engines ....11 Service Safety ..................12 Labels Label Locations ..................
  • Page 6 Table of Contents MFS735 Maintenance Periodic Maintenance Schedule............29 Servicing the Spark Plug ..............30 Servicing the Air Cleaner..............31 Changing the Engine Oil ..............32 Adjusting the Carburetor ..............33 Changing the Drive Belt ...............34 Lubrication Points.................35 Storage....................36 Troubleshooting Technical Data Engine Data..................38 Machine Data ..................38 Sound Measurements ................39 Dimensions...

  • Page 7: Safety Information

    MFS735 Safety Information Safety Information Signal Words Used in this Manual This manual contains DANGER, WARNING, CAUTION, NOTICE, and NOTE signal words which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol.

  • Page 8: Machine Description And Intended Use

    MFS735 Safety Information Machine Description and Intended Use The Wacker Neuson compact and lightweight floorsaw offers outstanding cutting performance, smooth operation and excellent maneuverability. This machine bridge the gap between a hand-held cut-off saw and a larger walk-behind floorsaw, and is ideal for small cuts in asphalt and concrete, for patching and repairs jobs and applications such as installing electric fencing, lighting, etc.

  • Page 9: Operating Safety

    To ensure safe operation of the machine: Do not operate the machine if any safety devices or guards are missing or inoperative. Do not modify or defeat the safety devices. Only use accessories or attachments that are approved by Wacker Neuson.
  • Page 10 MFS735 Safety Information Safe When operating this machine: operating Remain aware of the machine’s moving parts. Keep hands, feet, and loose practices clothing away from the machine’s moving parts. When operating this machine: Do not operate a machine in need of repair. Personal Wear the following Personal Protective Equipment (PPE) while operating this Protective...

  • Page 11: Operator Safety While Using Internal Combustion Engines

    MFS735 Safety Information Operator Safety while Using Internal Combustion Engines WARNING Internal combustion engines present special hazards during operation and fueling. Read and follow the warning instructions in the engine owner’s manual and the safety guidelines below. Failure to follow the warnings and safety standards could result in severe injury or death.

  • Page 12: Service Safety

    Machine When servicing or maintaining the machine: modifications Use only accessories/attachments that are approved by Wacker Neuson. When servicing or maintaining the machine: Do not defeat safety devices. Do not modify the machine without the express written approval of Wacker Neuson.
  • Page 13 MFS735 Safety Information Cleaning When cleaning and servicing the machine: Keep the machine clean and free of debris such as leaves, paper, cartons, etc. Keep the labels legible. When cleaning the machine: Do not clean the machine while it is running. Never use gasoline or other types of fuels or flammable solvents to clean the machine.

  • Page 14: Labels

    MFS735 Labels Labels Label Locations...

  • Page 15: Label Meanings

    Labels MFS735 Label Meanings Guaranteed sound power level in dB(A). MFS735 Machine label Cutting blade: rotation label • Caution, risk of injury • Read the operator’s manual. • Wear an eye protection and ear protection! • Machine may not be offset with the cutting blade rotating.
  • Page 16 MFS735 Labels Cutting depth label Company Label Company logo...
  • Page 17 Labels MFS735 A nameplate listing the model number, item number, revision number, and serial number is attached to each unit. Please record the information found on this nameplate so it will be available should the nameplate become lost or damaged. When ordering parts or requesting service information, you will always be asked to specify the model number, item number, revision number, and serial number of...

  • Page 18: Lifting And Transporting

    MFS735 Lifting and Transporting Lifting and Transporting Lifting the This machine is heavy enough to cause injury if proper lifting techniques are not Machine used. Observe the following guidelines when lifting the floorsaw. Do not attempt to lift the machine unassisted. Use appropriate lifting equipment such as slings, chains hooks, ramps or jacks.

  • Page 19: Operation

    1. Make sure all loose packaging materials have been removed from the machine. 2. Check the machine and its components for damage. If there is visible damage, do not operate the machine! Contact your Wacker Neuson dealer immediately for assistance.

  • Page 20: Application

    MFS735 Operation Application The Floorsaw should only be operated in a forward direction. The drive engine fastened to the frame drives the cutting blade by way of a drive belt. The infinitely variable cutting depth of the cutting blade is adjusted with the help of a hand crank, and 1 turn of the crank equals 5 mm (0.20 in) cutting depth adjustment.

  • Page 21: Starting The Machine

    MFS735 Operation Starting the Machine Procedure Perform the procedure below to start the machine. 1. Turn the fuel cock to the “ON” (OPEN) postion (a1). Note: If engine is cold, move choke lever to close position (b1). If engine is hot, set choke to open position (b2).

  • Page 22: Stopping The Machine

    MFS735 Operation Stopping the Machine Procedure Perform the procedure below to stop the machine. 1. Reduce the engine rpm to idle by moving the throttle completely to the left (g). 2. Turn the engine switch to “OFF” (d2) 3. Close the fuel valve (a2). Adjusting the Guide Handle Procedure The height of the stirrup handle can be adjusted according to the use and the body...

  • Page 23: Use Of Cutting Blade

    MFS735 Operation Use of the Cutting Blade Things to General application instructions for use of diamond cutting blades: Remember 1. Never use a diamond cutting blade of a diameter larger than necessary to cut down to a certain depth. 2. Pull the blade out of the cut if it has stopped turning and before restarting the engine.
  • Page 24 MFS735 Operation CAUTION DO NOT cut into the crushed stone layer or similar material layer when working with a diamond blade. Uneven wear may occur when cutting along road edges or two different types of materials (cutting along joints). Special care is required if the material to be cut shows irregularities (eg.

  • Page 25: Installation Of Cutting Blade

    MFS735 Operation Installation of the Cutting Blade Procedure Perform the procedure below to install the blade. 1. Make sure that the engine is switched "OFF". 2. Turn the crank (a) counter-clockwise until the machine tilts up at maximum height. 3. Lift the blade-guard up from the front side. 4.

  • Page 26: Removal Of Cutting Blade

    MFS735 Operation 4.10 Removal of the Cutting Blade Procedure Perform the procedure below to remove the cutting blade. 1. Make sure that the engine and the water feed is switched "OFF", and the blade is cool. 2. Turn the crank (a) counter-clockwise until the blade no longer touches the floor. 3.

  • Page 27: Cutting Depth Adjustment

    MFS735 Operation 4.12 Cutting Depth Adjustment Guidelines Perform the following guidelines in adjusting the cutting depth. The cutting depth can be precisely set with the crank (a). One turn of the crank is equal to 5 mm (0.20 in) cutting depth. A clockwise turn deepens the cutting depth.

  • Page 28: Water Tank

    MFS735 Operation 4.13 Water Tank Ref. Description Ref. Description Water tank Strap Retaining clamp Water supply The floor saw features an integrated, removable water tank. To fit the water tank, attach the retaining clamp and tighten it with the strap. To remove the water tank or to attach an external water supply, you can disconnect the hose on two different spots.

  • Page 29: Maintenance

    MFS735 Maintenance Maintenance Periodic Maintenance Schedule Engine Maintenance The chart below lists basic engine maintenance. Refer to the engine manufacturer’s Operation manual for additional information. After Daily Every Every Every first before 50 hr 100 hr 300 hr 20 hr starting or 3 mo.

  • Page 30: Servicing The Spark Plug

    MFS735 Maintenance Servicing the Spark Plug When Clean the spark plug every 100 hours of operation or every 6 months. Replace the spark plug as needed. Requirements Machine shut down Engine cool Procedure Perform the procedure below to clean the spark plug. Note: Refer to chapter 'Technical Data”...

  • Page 31: Servicing The Air Cleaner

    MFS735 Maintenance Servicing the Air Cleaner Background A dirty air filter element can restrict air flowing into the carburetor. To keep the carburetor in good working conditions, service the air filter element periodically. If operating the engine in extremely dusty area, the job should be done more often. WARNING Explosion hazard and fire hazard.

  • Page 32: Changing The Engine Oil

    MFS735 Maintenance Changing the Engine Oil Procedure Perform th procedure below to change the engine oil. 1. Drain the oil while the engine is still warm. 2. Remove the oil filter plug (a) and the drain plug (b) to drain the oil. Note: In the interest of environmental protection, place a plastic sheet and a container under the machine to collect any liquid that drains off.

  • Page 33: Adjusting The Carburetor

    MFS735 Maintenance Adjusting the Carburetor Procedure Perform the procedure below to adjust the carburetor. 1. Start the engine and allow it to warm up to operating temperature. 2. Set the pilot screw (a) two turns out. See Note. 3. With the engine idling, turn the pilot screw (a) in or out to the setting that produces the highest rpm.

  • Page 34: Changing The Drive Belt

    MFS735 Maintenance Changing the Drive Belt Task Check the belt tension or replace the belt. Procedure Perform the procedure below to change the drive belt. 1. Loosen the three screws (a) and remove the beltguard (b) keeping the screw assemblies captured on the beltguard. 2.

  • Page 35: Lubrication Points

    MFS735 Maintenance Lubrication Points Tasks Perform the following task in lubricating the machine. Position the machine at its maximum height by turning the crank (b) counter- clockwise. Apply grease on the hole (a) and grease points (c) as shown.

  • Page 36: Storage

    MFS735 Maintenance Storage Procedure Perform the procedure below to store the machine for more than 30 days. 1. Remove the dirt from the machine. 2. Empty the water tank. 3. Clean or replace the engine air filter. 4. Change the engine oil and clean the engine thoroughly with an oiled cloth. 5.

  • Page 37: Troubleshooting

    Close the fuel tap. The engine turned off. main switch is defective. will switch off after a few seconds. • Have the machine repaired.* * Have these tasks carried out by the service department of your Wacker Neuson contact person.

  • Page 38: Technical Data

    MFS735 Technical Data Technical Data Engine Data Engine Power Rating Net power rating per SAE J1349. Actual power output may vary due to conditions of specific use. MFS735-CE Engine Engine make Loncin Engine model G210F Maximum rated power 4.4 @ 3600 rpm...

  • Page 39: Sound Measurements

    MFS735 Technical Data Sound Measurements The required sound specification, EU Noise Directive 2000/14/EC Annex V & 2005/88/EC Basic noise emission standard EN ISO 3744: 1995 Operation condition in according to point 30 Part B Annex III EU-RL 2000/14/EC The measured sound power level (LWA) = 103 dB(A) The guaranteed sound power level (LWA) = 103 dB(A) The sound measurements were obtained with the machine operating on hard concrete.

  • Page 40: Dimensions

    MFS735 Dimensions Dimensions 880 mm 830 mm 488 mm...
