- Page 1 w e l l m a d e f o r e v e r Whirlpool Alcove Bathtub with Apron INSTALLATION INSTRUCTIONS www.swissmadison.com | 1-434-623-4766 | info@swissmadison.com @SwissMadison #WellMadeForever...
-
Page 2: Prior To Installation
· All dimensions are nominal! Be sure to measure your bathtub prior to installation. · The step-by-step guidelines in the installation instructions are a general reference. Should there be any discrepancies, Swiss Madison cannot be held liable. It is recommended to install all Swiss Madison products by hiring a licensed professional. -
Page 3: Included Parts
INSTALLATION ALCOVE BATHTUB SUGGESTED TOOLS & MATERIALS: Safety Tape Square Caulk Gun Glasses Measure Screws Level Screwdriver Utility 1/4” v-notched (DO NOT use Knife trowel drywall screws) Drill Bit Sealant Adhesive Drop Cloth Drill (Ø 5mm) INCLUDED PARTS: Alcove Bathtub... - Page 4 INSTALLATION ALCOVE BATHTUB INSTALLATION: Rough In Attach Support Bars • If your model does not come with bars pre • Rough plumbing must be pre-installed attached, please attach them according by a certified plumber before installation. to the included Apron Support Installation •...
- Page 5 INSTALLATION ALCOVE BATHTUB Ensure Tub is Level If the hole on the support bar does not line up with the pre-drilled holes in the apron, please complete the following steps: • Place level across the bottom surface - Using a screwdriver, loosen the screws of the apron and the adjustable feet to holding the hinge in place.
- Page 6 INSTALLATION ALCOVE BATHTUB Mark and Pre Drill Holes Screw into Place • Mark stud locations. • Lay mortar bed and carefully lower • Pre-drill Ø5 mm holes on top flange. bathtub into predetermined location. • If stud is not flush to flange, a shim should •...
- Page 7 INSTALLATION ALCOVE BATHTUB Connect to Power • Connect pump to grounded power supply. • A separate 120VAC, 60-Hz, 20 Amp circuit, protected by a Ground-Fault Circuit Interrupter (GFCI) is required. • ELECTRICAL SHOCK HAZARD: Plug into a grounded 3-prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord.
- Page 8 INSTALLATION ALCOVE BATHTUB Control Panel: Parts: 1 - Bottom light A - Control Panel 2 - Water Pump B - Adjustable Jet x 6 3 - Power C - Backwater Cover 4 - Water Jet D - Bottom Light E - Water Pump F - Jet Pressure Dial Usage: 2"...
-
Page 9: Troubleshooting
2. Re-bond the pipe joint. 3. Broken water pipe. 3. Replace the water pipe. If unable to troubleshoot, Swiss Madison recommends reaching out to a liscensed plumber or to Swiss Madison’s customer service team for assistance. Please keep this manual for future reference. -
Page 10: One-Year Limited Warranty
® customers with beautiful, durable, long-lasting products. Should there be any defects in materials or craftsmanship under regular use that are discovered within the first year of installation, Swiss Madison ® will provide replacement parts at no charge, or at its discretion, replace any product or part of the product that is deemed defective, under normal installation, use, service or maintenance.
