nuPro

The latest operating instructions and other

helpful information can be found here:

https://www.nubert.de/en/downloads-nupro-xs-3000-4000-rc

Cable connections

Please connect all sources and the optional sub-

woofer to one of the two speakers of the stereo

pair.

Analogue XLR connection: Here, as an exception, each loudspeaker

is supplied with the corresponding signal separately.

Among other things, an HDMI/ARC adapter (optional accessory) can

be connected to the digital port input, which

enables a TV to be connected directly.

Each nuPro loudspeaker is connected to the power grid using

the supplied power-cable.

Press the power switch on the back to turn on the speaker. If neces-

sary, press the power-button on the remote control to "wake up" the

speaker.

nuPro XS-3000 / 4000 RC · Quickstart guide E12 · 02/2024

XS-3000/4000 RC

Quickstart guide

Need help?

Do you have a question about the nuPro XS-4000 RC and is the answer not in the manual?

Page 1 XS-3000/4000 RC Quickstart guide The latest operating instructions and other helpful information can be found here: https://www.nubert.de/en/downloads-nupro-xs-3000-4000-rc Cable connections Please connect all sources and the optional sub- woofer to one of the two speakers of the stereo pair. Analogue XLR connection: Here, as an exception, each loudspeaker is supplied with the corresponding signal separately.
Page 2 Master-slave connection The speaker you connected your sources to must The master speaker controls and passes the correct audio signal on to the second (slave-)speaker. be set as the Master speaker. In order to achieve this, the speakers must be connected to each other.
Page 3 Channel selection ➀ Finally, you may have to change the default channel -30dB < > coax 1 settings. If the left speaker is your Master speaker, you can skip this step. < ➁ volume < > If your Master speaker is the right speaker you need to change the settings as follows: ➀...
Page 4 The latter menu is identical to that on the speaker itself. Screenshots: App V1.3 ® Nubert electronic GmbH · Nubertstr. 1 · D-73529 Schwäbisch Gmünd · www.nubert.de · info@nubert.de · Hotline: +49 7171 8712-0 nuPro XS-3000 / 4000 RC · Quickstart guide E12 · 02/2024...
