Planning Information
Model I H 4227 Cooktop Island Hood
Model IH4227
Transition with
backdraft damper
Halogen lighting
The Wolf cooktop island ventilation
hood is available in the classic stainless
steel finish. It is sold as a shell only,
internal, in-line and remote blower
options are available.
Dimensions in parentheses are in
millimeters unless otherwise specified.
9/06
Rating plate
location
W
hen your dream kitchen calls for a centralized
cooking surface, the Wolf cooktop island hood is the
ideal ventilation companion. The sculpted classic
stainless steel shape not only provides the power you
expect from Wolf, but also the beauty you have come
to appreciate as well.
This ceiling mount cooktop hood is 42" (1067) wide
by 27" (686) deep. It has a telescopic chimney flue that
allows you to reach a ceiling height of 8' (2.4 m) to 9'
(2.7 m) with a finished look. A flue extension to
accommodate 10' (3 m) ceilings is available as a sales
accessory.
The Wolf cooktop island hood is recommended for use
with Wolf electric and gas cooktops and integrated
modules. For Wolf dual fuel ranges, gas ranges, sealed
burner rangetops and gas rangetops, a Pro ventilation
hood should be used.
Classic stainless
steel finish
Seamless
Construction
Aluminum mesh
filter
Front mounted
controls
Three-speed
blower control
LED indicators
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the IH4227 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wolf IH4227

Summary of Contents for Wolf IH4227

  • Page 1 Wolf cooktop island hood is the ideal ventilation companion. The sculpted classic stainless steel shape not only provides the power you expect from Wolf, but also the beauty you have come to appreciate as well. This ceiling mount cooktop hood is 42" (1067) wide by 27"...
  • Page 2 Planning Information Model I H 4227 Cooktop Island Hood F E A T U R E S Classic stainless steel finish Internal, in-line and remote blower options Front mounted controls with LED indicator Heavy-duty stainless steel seamless construction Three-speed blower control Variable speed blowers Filter clean timer lets you know when the filter needs cleaning...
  • Page 3 801641 1200 CFM Remote Blower 801642 1500 CFM Remote Blower 804701 Model IH4227 is sold as a shell only, an internal, in-line or remote blower will be required. Refer to Wolf Cooktop Ventilation Recommendations at the end of this section.
  • Page 4 Planning Information Model I H 4227 Cooktop Island Hood " (1195) MAXIMUM HEIGHT OF HOOD 27" (686) (2.4 m – 2.7 m) FLOOR TO CEILING HEIGHT *8' (2.4 m) ceilings will not allow for a 30" (762) maximum height above the countertop. Based on a 36" (914) high countertop, an 8' (2.4 m) ceiling will allow for a maximum height above the countertop of 26 D I M E N S I O N S Overall Width of Hood...
  • Page 5 IMPORTANT NOTE: Wolf Pro ventilation hoods should be used with Wolf dual fuel ranges, gas ranges, sealed burner rangetops and gas range- tops. The Wolf cooktop island hood comes with a telescopic chimney flue extension that allows you to reach a ceiling height of 8' (2.4 m) to 9'...
  • Page 6 C O O K T O P H O O D P L A C E M E N T The Wolf cooktop island ventilation hood comes with a telescopic chimney flue that allows you to reach a ceiling height of 8' (2.4 m) to 9' (2.7 m) with a finished look.
  • Page 7 Model I H 4227 Cooktop Island Hood D U C T I N G C O N S I D E R A T I O N S The Wolf cooktop island hood is shipped without the blower assembly. Internal, in-line or remote blower assemblies are available.
  • Page 8 Internal, in-line and remote blower assemblies are available as sales acces- sories through your Wolf dealer. Wolf internal, in-line and remote blowers are for use with Wolf cooktop hoods, downdraft systems and Pro ventilation hoods and hood liners.
  • Page 9 215* *Use these requirements to determine total CFM when installing multiple cooktops or modules. CFM recommendations are based on total Btu/hr output. Wolf recommends 1 CFM per 100 Btu/hr (.03 kW). Additional CFM may be required for long duct runs.
