2 Product overview

The new DMC instrument panel displays are studied for applications where flexibility of information and high
performance are needed.
Two variant of display are available: DMC Advanced Display (touch screen, advanced graphic camera view, high graphic
performance) and DMC Lite Display (compact and cost effective).
The DMC displays are compatible with all DMC controller's software variants.
Both displays show a basic set of information and have common features:
•
Stated Of Charge indication
•
Fault Code and Subcode (warning and error status of controllers)
•
Drive Hour Counter
•
Mileage
•
Vehicle speed or RPM display (Lite display has further options)
•
Fault logger
•
Information Page
•
Basic warning and error Icons
DMC Lite Display is indicated for basic vehicle application where the compact size and cost effectiveness are very
important.
DMC Advanced Display is meant to be a real vehicle Dashboard.
On DMC Advanced display the following advanced features are available.
•
Rear view PAL camera connection
•
Battery power bar graph indicator
•
Charger indication
•
Lights icons (active according to digital input signals)
•
Direction lights indicator icons (active according to digital input signals)
•
Data and Time
•
Service Timer
•
Touch screen
•
Status information detailed up to 8 DMC controllers
•
Icons for Controller and Battery warning and error.
•
Monitoring of 12-24V auxiliary supply or battery.
Both display can indicate warning and error message of Battery BMS compatible with DMC controllers.

2.1 Display variants

Available models
Model Nr.
SV125-0001
SV250-0001
SV125-0101
SV250-0101
SV125-3001
SV250-3001
SV500-3001
ST125-0001
ST250-0001
ST125-3001
ST250-3001
ST500-3001
DMC Advanced Display and Lite Display Manual – V1.1 Page 6 (28)
CAN protocol
DMC Lite Display
CAN Open Compatible
CAN Open Compatible
DMC CAN
DMC CAN
CAN Open
CAN Open
CAN Open
DMC Advanced Display
CAN Open Compatible
CAN Open Compatible
CAN Open
CAN Open
CAN Open
Details
125 Kbit/s baudrate
250 Kbit/s baudrate
125 Kbit/s baudrate
250 Kbit/s baudrate
125 Kbit/s baudrate
250 Kbit/s baudrate
500 Kbit/s baudrate
125 Kbit/s baudrate
250 Kbit/s baudrate
125 Kbit/s baudrate
250 Kbit/s baudrate
500 Kbit/s baudrate
