DMC InfoSOSA IS731-4 Instruction Manual

4.3” touchscreen display

Advertisement

Quick Links

InfoSOSA™ Series
4.3" Touchscreen Display
IS731-4
Model: IS731-4WQ1-D05
Instruction Manual
DMC Co., Ltd.
https: //www.dush.co.jp/english/
- 1 -
20A4A4-00005E-2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InfoSOSA IS731-4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DMC InfoSOSA IS731-4

  • Page 1 InfoSOSA™ Series 4.3” Touchscreen Display IS731-4 Model: IS731-4WQ1-D05 Instruction Manual DMC Co., Ltd. https: //www.dush.co.jp/english/ - 1 - 20A4A4-00005E-2...
  • Page 2: Table Of Contents

    Table of Contents Introduction ............................3 Notes ..............................3 Precautions for Safe Use ........................3 Warnings .............................. 4 Cautions .............................. 5 Handling of LCD Panels ........................6 Handling of Batteries ........................... 6 Handling of Image Files ........................6 IS731 Series Products ........................... 7 General Specification...........................
  • Page 3: Introduction

    ■ DMC shall not be held liable in any way for damages or losses, nor be held responsible for any claims by a third party as a result of using this product.
  • Page 4: Warnings

    Warnings WARNING Warnings for Design Designing switches that might cause human injuries and/or property damage on the touch screen is strictly prohibited. Unintentional output signals due to malfunction of the main body, units, and/or cables, etc. can cause serious injuries. Design the system so that switches with major functions are equipped on other devices. Designing safety related switches on the InfoSOSA is prohibited.
  • Page 5: Cautions

    Warnings for Wiring For wiring and installation, please refer to the manual and specifications in order to conduct it correctly. It may cause fires and/or electric shocks. Before installing the power cable, make sure power is not being supplied from power source. It may cause electrical shock.
  • Page 6: Handling Of Lcd Panels

    Handling of LCD Panels (1) The LCD display contains skin-irritating materials. If liquid materials flow out due to damage and comes in contact with skin, wash the area under running water for at least 15 minutes. If it gets into the eyes, wash under running water and consult a doctor.
  • Page 7: Is731 Series Products

    IS731 Series Products General Specification Model Specification Distinction* Display size Resolution Rated voltage Maximum support language IS731-4WQ1-D05 4.3” WQVGA 5VDC 1 language (480×272) *1 language (Maximum of 1 system font language can be used.) Packaged Contents Below items are included in the package. Please make sure there no missing items before use. Although all efforts have been made to assure the quality and packaging before shipment, if you notice any damages or missing items, please notify us before use.
  • Page 8: Part Names And Their Functions

    Part Names and Their Functions Main Unit ■ Front Side Angle -Use when mounting to devices. -Tighten screws on sides to install and adjust height Display/ Touch Screen -Connected to GND (Signal Display screen images, input GND) inside the unit. by touchscreen.
  • Page 9: Installation And Wiring

    Installation and Wiring Installation • Make sure that power is not applied when installing and/or wiring. • Refer to the panel opening example and the attached outline diagrams when designing the chassis. • Design the chassis so that there will be no contorting or deformation when installing. •...
  • Page 10: Panel Mounting Procedures

    (1) Align the hole of the unit angle with the stud bolts of the panel in 4 locations and tighten the nuts. Nuts Stud Bolts (2) Adjust the height of the touch screen (LCD) with the angle. ■ Panel Opening Example Design and arrange the design so that the touch screen is a little inward (about 0.3mm recommended) from the sheet side so that the sheet side does not push the touch screen.
  • Page 11: Wiring Procedure

    Wiring Procedure Please follow the Instructions of each number when wiring. Apply power after all wirings are done; do not attempt to do the wiring with the power on. All wirings do not need to be connected; connect only the ones necessary for the application to be used. (2) USB Mini-B Cable (1) Power Cable To 5V DC Power...
  • Page 12: Connecting Unit To Power

    ■ Connecting to 5V DC Power Use a Power Cable to connect to 5V DC. Power Cable Unit 5V DC Power 《Power Specification》 ■ 5VDC±5% 《Power Cable Specification》 ■ Compatible connector housing: PAP-02V-S (Japan Solderless Terminal) Contact pin: SPHD-001T-P0.5、SPHD-002T-P0.5 ■ Pin Assignment Pin No Signal...
  • Page 13: Connecting To Communication Cable

    Connect to Serial port (SIO1:RS232C, SIO2:RS422/485) of the host. Connect to a PC if downloadscreen data. SIO1 can be used for host communication and download screen data. SIO2 can be used for host communication. Host SIO1: RS232 Communication Unit SIO2: RS422/485 Communication *Applying Ferrite Core to the communication cable is recommended for noise and static measures.
  • Page 14: Connecting To Battery

    Connect if battery backup of RTC is necessary. *There are two battery interfaces. If a battery is connected to either of them, backup is possible. If you do not need to back up, you do not need to connect a battery. 《Battery Port 1》...
  • Page 15: Connecting Design Sheet Key Tail

    Connect the Design sheet key tail to the connector by below procedure. (1) Open the holding lid by sliding to the direction as below by hand. (Side view) (2) Hold the tail so the conductive side of the tail is placed downwards and the reinforcement plates are upwards.
  • Page 16: Mounting Conditions

    Mounting Conditions • When mounting, be sure to have enough room between the unit, structure and part and also consider the operation temperature. • Be sure that the ambient operating temperature and the ambient humidity are within their designated ranges. (Ambient operating temperature indicates the temperature of both the display side and inside the cabinet.) Inside the cabinet Display side...
  • Page 17: Starting The Infososa

    Starting the InfoSOSA Make sure all the wirings are complete and turn ON the 5V DC power. A starting beep will sound. Download the screen data to the unit. For downloading instructions, please refer to the “IS731 Series Start-up Guide”. Starting the Development Tool (InfoSOSA Builder) InfoSOSA will need to be installed to set and edit screens of the InfoSOSA.
  • Page 18: Maintenance

    Maintenance Display Maintenance If the surface of the display or the frame becomes dirty, wipe clean with a soft cloth dampened with thinned neutral detergent and wrung dry. Use of thinner, organic solvents and strong acidic solvents are prohibited. Regular Inspections Please conduct an inspection on a regular basis to use the InfoSOSA in its best condition.
  • Page 19: Warranty And Repairs

    (4) Any replacement of consumables. (5) If the product is repaired, remodeled, modified, or disassembled by a party other than DMC. This warranty covers only the product itself. And damages driven by the failure of our product and repairs and/or replacements done on-site will not be covered.
  • Page 20: Production Discontinuance

    (3) We will take utmost care of your data stored in our product but please be sure to delete any confidential data beforehand. (4) Repairs will be made in our factory in principle and shipping cost will be borne by the customer. (5) All ownership of the repaired parts will belong to DMC. - 20 - 20A4A4-00005E-2...
  • Page 21: Others

    URL: https: //www.dush.co.jp/english/ This product and document are protected by the copyright law. Photocopying, duplicating, reproducing, and modifying of this product or document in part or by whole is prohibited. Copyright(C) 2024 DMC Co., Ltd. All Rights Reserved - 21 - 20A4A4-00005E-2...

This manual is also suitable for:

Infososa is731-4wq1-d05
