Basic Function/Radio MP3-CD/CD Player
Manual programming
Basic functions
1 Tune to your desired station (see Tuning to
Switching on/off the set
radio stations).
1 To switch on, press POWER.
➜ Display lights up.The system will switch to 2 Press PROG to activate programming.
➜ Display: PROG flashes.
the last selected source.
3 Press ALBUM/PRESET +/-
2 To switch off, press POWER again.
(ALBUM/PRESET 3, 4 on the remote
➜ Display lights off.
control ) once or more to allocate a number
Adjusting volume and sound
(from 1 to 25).
Adjust the sound with the VOLUME and
4 Press PROG to confirm.
DBB controls.
5 Repeat steps 1-4 to store other stations.
Helpful hints:
Digital tuner
– You can erase a preset station by storing
Tuning to radio stations
another frequency in its place.
1 Press repeatedly SOURCE (or TUNER
Autostore
on the remote control) to select FM or
MW.
Autostore automatically starts programming
➜ "TUNER" is displayed briefly, then the
radio stations from preset 1. Any previous
radio station frequency, waveband and, if
presets e.g. manually programmed will be
programmed, a preset number are shown
erased.
(See 2).
1 Press repeatedly SOURCE (or TUNER
2 Press and hold ∞ or § until the frequency in
on the remote control) to select FM or
the display starts running.
MW.
➜ The radio automatically tunes to a station
of sufficient reception. Display shows 2 Press PROG until "AUTO" flashes.
➜ Available stations are programmed (MW
" SEARCH" during automatic tuning.
or FM). After all stations are stored, the
3 Repeat step 2 if necessary until you find the
first autostore preset station will then
desired station.
automatically play.
To tune to a weak station, press ∞ or §
•
briefly and repeatedly until you have found
optimal reception.
To listen to a preset or autostore
station
To improve radio reception:
Press the ALBUM/PRESET +/-
• For FM, extend, incline and turn the
(ALBUM/PRESET 3, 4 on the remote
telescopic aerial. Reduce its length if the signal
control ) buttons once or more until the
is too strong.
desired preset station is displayed.
• For MW, the set uses a built-in aerial. Direct
this aerial by turning the whole set.
Programming radio stations
You can store 15 FM and 10 MW radio
stations in the memory manually or
automatically (Auto store).
Auxiliary connection
DOCK
Notes:
Playing iPod using
By using the buttons ( 2;, ¡1, 2™ and
–
AZ1330D
VOLUME ) on the AZ1330D and its remote
control, the following disc playback features are
By connecting the iPod to your AZ1330D,
available: Play/Pause, selecting next/previous track,
you can listen to the sound of the docked
fast forwarding/rewinding and changing volume.
player through the powerful speakers of the
The buttons ( 2;, ¡1, 2™ and VOLUME ) on
Hi-Fi system.
–
the AZ1330D and its remote control can work
Compatible portable player
only with playback of the audio contents stored
• Most Apple iPod models with 30-pin dock
on the docked player.
connector as follows:
20GB, 40GB, 20/30GB photo, 40/60GB Charging iPod battery using the dock
photo, 30GB video, 60/80GB video, mini and
In the power-on and standby mode of
nano.
AZ1330D, you can charge the iPod when
docking.
Dock adaptor
Helpful hints:
Before plugging your player in the dock, snap
the suitable dock adaptor into the dock to – In DOCK and CD mode, if AZ1330D is in the
provide a snug fit for the player to be docked. STOP position for 15 minutes, it will auto switch
to standby.
Selecting the correct dock adaptor
• For the iPod dock, 8 dock adaptors of
Connecting an external device
different type, as indicated at the back of the
adaptor, are included to fit the following iPod: You can listen to the sound of the connected
20GB, 40GB, 20/30GB photo, 40/60GB
external device through your AZ1330D's
photo, 30GB video, 60GB video, miniand nano.
speakers.
1 Press repeatedly SOURCE (or AUX on the
Playing Apple iPod using AZ1330D
remote contorl) to select AUX mode.
1 Snap the compatible iPod into the dock
2 Use the supplied line-in cable to connect
connector.
AZ1330D's AUX jack (3.5 mm, located on
• AZ1330D will auto switch to DOCK source
the top panel) to an AUDIO OUT or
(See 7).
headphone jack on an external equipment
2 For iPod, the connected player will play
(such as CD player, VCR or iPod).
automatically.
MP3-CD/CD Player
➜ " NO DISC" will be displayed if CD is not
About MP3
loaded.
The music compression technology MP3
3 Press / to open the disc door.
(MPEG1 Audio Layer 3) significantly reduce
4 Insert a disc with the printed side facing up
the digital data of an audio CD while
and press the disc door gently to close.
maintaining CD quality sound.
➜ The disc scanning of MP3-CD may run
• Getting MP3 files: you can either download
longer than audio CD.
legal music files from the internet to your ➜ Display: The total number of tracks
computer hard disc, or create such files by
appears (and album number for
MP3/WMA) (see 4).
converting audio CD files in your computer
through appropriate encoder software. 5 Press 2; to start playback.
➜ First the song title of the track scrolls
(128kbps bit rate or higher is recommended
across the display, then the track number
for MP3 files.)
and the elapsed playing time are displayed.
• burn the music files
Creating a MP3 CD:
For MP3-CD/ WMA only:
from your computer hard disc on a CDR or
➜ The current track number (TRK) and
CDRW using your CD burner.
album number (ALB) will be displayed
Helpful hints:
interchangeably.
6 To pause playback press 2;.
– Make sure that the file names of the MP3 files
end with .mp3 or .wma. ➜ Display: 2 and the elapsed playing time
flash.
– Number of albums: maximum 100.
– Number of tracks: maximum 999. 7 Press 2; again to resume playback.
– The length of file names affects the number of
8 To stop playback, press 9.
tracks for playback. With shorter file names,
more files can be burned on a disc.
Helpful hints:
The disc playback will also stop when:
– you open the disc compartment door;
Playing a disc
– you select FM, MW, AUX or DOCK;
This player plays Audio Discs including
– the disc has reached the end of the playback.
CD-R/ CD-RW, MP3 CD and WMA. Do not
try to play a CD-ROM, CD-I, CDV,VCD,
DVD or computer CD. Selecting a different track
• Press ∞ or § once or repeatedly until the
IMPORTANT!
desired track number appears in the display.
CDs encoded with copyright protection
•
technologies by some record companies may For MP3-CD/WMA: First press
ALBUM/PRESET +/- ( ALBUM/
be unplayable by this product.
PRESET 3, 4 on the remote control ) once
DRM-protected WMA disc is not supported.
•
or more to find your album.
1 Press repeatedly SOURCE (CD on the
• In the pause/stop position, press 2; to start
remote control) to select CD source.
playback.
➜ Display shows flashing "READ" if CD
source is selected (see 3).
Safety & Maintenance
(See 8)
Safety information CD player and CD handling
• Place the set on a hard, flat and stable surface
• If the CD player cannot read CDs correctly,
so that the system does not tilt.
use a cleaning CD to clean the lens before
• Where the MAINS plug or an appliance cou- taking the set to repair.
pler is used as the disconnect device, the dis-
• The lens of the CD player should never be
connet device shall remain readily operable.
touched!
• Do not expose the set, batteries, CDs to
• Sudden changes in the surrounding
humidity, rain, sand or excessive heat caused
temperature can cause condensation on the
by heating equipment or direct sunlight.
lens of your CD player. Playing a CD is then
• The apparatus shall not be exposed to
not possible. Do not attempt to clean the
dripping or splashing.
lens but leave the set in a warm environment
• Adequate ventilation with a minimum gap of
until the moisture evaporates.
15 cm between the ventilation holes and
• Always close the CD door to avoid dust on
surrounding surfaces is necessary to prevent
the lens.
heat build-up.
• To clean the CD, wipe in a straight line from
• The ventilation should not be impeded by
the center towards the edge using a soft,
covering the ventilation openings with items,
lint-free cloth. Do not use cleaning agents as
such as newspapers, table-cloths, curtains, etc.
they may damage the disc.
• No objects filled with liquids, such as vases,
• Never write on a CD or attach any stickers
shall be placed on the apparatus.
to it.
• No naked flame sources, such as lighted
candles, should be placed on the apparatus.
• The mechanical parts of the set contain
self-lubricating bearings and must not be oiled
or lubricated.
• To clean the set, use a dry cloth. Do not use
any cleaning agents containing alcohol,
ammonia, benzene or abrasives as these may
harm the housing.
Environmental information
All unnecessary packaging material has been omitted.The packaging can be easily separated
into three materials: cardboard, polystyrene and plastic.
Your set consists of materials which can be recycled if disassembled by a
specialized company. Please observe the local regulations regarding the
disposal of packaging, dead batteries and old equipment.
MP3-CD/CD Player
To erase a program
Finding a passage within a
You can erase a program by:
track
pressing 9 (twice during playback or once in
–
1 During playback, press and hold down
the stop position);
∞ or §.
– selecting FM, MW, AUX or DOCK;
➜ The disc is played at high speed and low
– pressing POWER to power off;
volume.
– opening the disc door.
2 When you recognize the passage you want,
➜ "PROGRAM CLEAR" scrolls across the
release ∞ or §.
display once, and "PROG" disappears.
➜ Normal playback resumes.
Selecting different play
Programming tracks
modes (See 6)
You may store up to 20 tracks in the desired
sequence. If you like, store any track more
You can select and change the various play
than once.
modes before or during playback, and
1 In the stop position, press ∞ or § to select
combine play modes with PROG.
your desired track number.
REP – plays the current track continuously.
• For MP3-CD/WMA: First press
ALBUM/PRESET +/- ( ALBUM/PRE- REP ALL – plays the entire disc/program
SET 3, 4 on the remote control ) once or
continuously.
more to find your album.
SHUF – plays all tracks in random order.
2 Press PROG to store desired track.
REP ALL SHUF – plays all tracks in
➜ Display shows "PRO 2" , indicating the
random order continuously.
programmed location (See 5).
1 To select play modes, press MODE on the
• If you attempt to program without first
selectig a track, display will show "SELECT set (REPEAT or SHUFFLE on the remote
TRACK" briefly, then the total track number contorl) once or more.
and playing time.
2 Press 2; to start playback if in the stop
3 Repeat steps 1 to 2 to select and store all
position.
desired tracks.
➜ Shuffle play will start automatically soon
4 Press 2; to play the program.
after shuffle mode is selected.
➜ "PROG" is dispalyed during program
3 To select normal playback, press MODE on
playback.
the set (REPEAT or SHUFFLE on the
To review your program remote control) repeatedly until the various
In the stop position, press and hold PROG 3 play modes are no longer displayed.
– You can also press 9 to cancel your play
seconds.
➜ The display shows all the stored tracks
modes.
(and album numbers for MP3) in
sequence. Helpful hints:
– Shuffle (SHUF and REP ALL SHUF) play is
Helpful hints:
not available in the program mode.
– Display shows "NO PROG" if no track is
programmed.
– If you try to store more than 20 tracks, no
track can be stored and the display will show
"PROGRAM FULL".
Troubleshooting
If a fault occurs, first check the points listed below before taking the set for repair.
If you are unable to remedy a problem by following these hints, consult your dealer or service centre.
WARNING:
Do not open the set as there is a risk of electric shock. Under no cir-
cumstances should you try to repair the set yourself, as this will inval-
idate the guarantee.
No sound/ power The disc skips tracks
– Disc damaged or dirty
– Volume not adjusted
• Replace or clean disc
• Adjust the VOLUME
– Shuffle or program is active
– Power cord not securely connected
• Switch off shuffle/program
• Connect the AC power cord properly
– Batteries dead/ incorrectly inserted
• Insert (fresh) batteries correctly Sound skips during MP3 playback
– Disc contains non-audio files
– MP3 file made at compression level exceeding
• Insert a suitable disc or press ∞ or § once or
320kbps
more skip to an audio track, instead of the data
• Use a lower compression level to record CD
files.
tracks into MP3 format
Display does not function properly/No – Disc damaged or dirty
reaction to operation of any of the • Replace or clean disc.
controls
Note:
– Electrostatic discharge
DRM-protected WMA disc is not supported.
• Switch off and unplug the set. Reconnect after a
few seconds. Dock operation
– The menu navigation or photo playback of the
no indication
docked player cannot be carried out through the
– No disc inserted
buttons on AZ1330D or its remote control.
• Insert a suitable disc
• The buttons on AZ1330D and its remote control
– Disc badly scratched or dirty
can control playback of audio contents only.To
• Replace/clean CD (See Maintenance)
navigate the menu, use the controls on the
– CD-R(W) is blank or the disc is not finalized.
docked player.
• Use a finalized CD-R(W)
– Some buttons on AZ1330D and its remote
– Laser lens steam up
control have no function.
• Wait until lens has cleared.
• The buttons ( 2;, ¡1, 2™ and VOLUME )
function only.
Note:
Make sure the CD is not encoded with
Copyright protection technologies, as some
do not conform to the Compact
Disc standard.
AUSTRALIA -
Philips Manufacturers Warranty for Australia only
These warranty conditions are valid for the Care Centre for free replacement of faulty accessories.
following consumer electronics products:
8.
This Manufacturers Warranty is neither transferable
Colour Televisions, Projection TV, Plasma &
nor valid in countries other than Australia.
LCD TV, Video Cassette Recorders, CD
Recorders & Players, DVD Players, DVD This warranty does not cover:
Recorders, DVD Recorders with HDD, Audio
a) Mileage or travel outside the normal service area
Systems, Home Theatre systems, Digital Set
covered by selected Authorised Service Centre.
Top Box & Portable Audio products.
b) Service costs arising from failure to correctly
The benefits given to the purchaser by this
adjust the controls of the product or to observe the
warranty are in addition to all other rights
instructions, or inspections that reveal that the
and remedies which the purchaser has in product is in normal working order.
respect of the product under the Trade
c) Product failures caused by misuse, neglect,
Practices Act or other Commonwealth or
accidental breakage, transit damage, inexpert repairs
State Law.
or modification by un-authorised persons, external
Philips Consumer Electronics warrants its products to fires, lightning strikes, floods, vermin infestation or
the purchaser as follows and subject to the stated liquid spillage.
conditions.
d) Cleaning of video or audio heads.
1 Year Free Repair Service - at Philips ASC
e) Inadequate receiving antennae.
Colour Television, Plasma Television, LCD Television, f) Replacement of worn or used batteries or other
Projection Televsion, DVDR/VCR Combo, DVD consumables.
Recorders with Hard Drive, LCD Projectors, Wireless
g) Consumer products used in commercial applications
Audio Systems, Audio Systems, Home Theatre
(This warranty is limited to 3 months only).
Systems & Digital Set-Top-Box.
h) Second hand products.
1 Year free Replacement – at your Retailer
The conditions contained in this warranty
Portable Audio, MP3 Infotainment products, Video
card replace and override the provision of
Cassette recorders, DVD Player, DVD/VCR Combo
the Philips World-Wide Guarantee for
Player, DVD Recorder without HDD & Portable
products purchased in Australia and used in
DVD/LCD players. Australia.
Conditions of Repair Warranty Service is provided through more than 100
accredited Authorised Service Centres throughout
1.
All claims for warranty service should be made to
Australia. For direct contact with the nearest
your nearest Philips Authorised Service Centre or the
recommended Authorised Service Centre in capital
Philips Technology Care Centre. Reasonable evidence
& regional cities/towns
of date of purchase must be provided.
Authorised Service Centre Network
2.
This warranty extends only to defects in material or
workmanship occurring under normal use of the product
1300 361 392
when operated in accordance with the instructions.
Customer suppor t is provided in Australia by our
3. If a replacement product is supplied under the repair
trained call centre staff. For assistance with product
policy it is warranted, under this warranty, for the
features and specifications, please call
remainder of the warranty of the original purchased
Technology Care Centre
product only.
4.
Home service is provided only within the normal 1300 363 391
service area of one of our recommended Authorised
Please record the following information for
Service Centres (ASC). It will be provided for
your records and keep in a safe place.
television receivers only with a screen side of 67cms
We recommend retaining your purchase
or above (product includes CRT, LCD TV, PTV, and
receipt to assist with any warranty claim.
Plasma TV). Televisions with screen side less than
67cms and all other products types are to be taken or
Model number :....................................................
sent by the consumer to the workshop of your
nearest Authorised Service Centre, at the Consumer's Serial number :....................................................
expense.
Date of purchase:....................................................
5.
This Manufacturers Warranty is limited to 3 months
for the above listed Consumer Electronics products if Retailer:....................................................
used in commercial applications.
Philips Consumer Electronics
6.
Philips may, at its discretion choose to replace rather
a division of Philips Electronics Australia Limited
than repair any product covered by this warranty.
ABN 24 008 445 743,
7.
Product accessories are covered by the same
Level 1, 65 Epping Road NORTH RYDE NSW 2113.
warranty period. Please contact the Philips Technology
st
Warranty valid for all new products purchased after 1 January 2007
NEW ZEALAND -
Guarantee and Service for New Zealand
Thank-you for purchasing this quality Philips product.
Philips New Zealand Ltd guarantees this product against defective components and faulty
workmanship for a period of 12 months. Any defect in materials or workmanship occurring
within 12 months from the date of purchase subject to the following conditions will be rectified
free of charge by the retailer from whom this product was purchased.
Conditions
1. The product must have been purchased in New Zealand.As proof of purchase, retain the
original sales docket indicating the date of purchase.
2. The guarantee applies only to faults caused by defective components, or faulty workmanship
on the part of the manufacturer.
3. The guarantee does not cover failures caused by misuse, neglect, normal wear and tear,
accidental breakage, use onthe incorrect voltage, use contrary to operating instructions,
or unauthorised modification to the product or repair by an unauthorised technician.
4. Reasonable evidence (in the form of a sales docket) must be supplied to indicate that the
product was purchased no more than 12 months prior to the date of your claim.
5. In the event of a failure, Philips shall be under no liability for any injury, or any loss or
damage caused to property or products other than the product under guarantee.
This guarantee does not prejudice your rights under common law and statute,
and is in addition to the normal responsibilities of the retailer and Philips.
How to claim
Should your Philips product fail within the guarantee period, please return it to the
retailer from whom it was purchased. In most cases the retailer will be able to
satisfactorily repair or replace the product.
However, should the retailer not be able to conclude the matter satisfactorily, or if you
have other difficulties claiming under this guarantee, please contact
The Guarantee Controller
Philips New Zealand Ltd.
4 P.O. Box 41.021
Auckland
3 (09) 84 94 160
fax 3 (09) 84 97 858
