- Page 1 DAIKIN ROOM AIR CONDITIONER OPERATION MANUAL MODELS Operation Manual English Handset Wireless FCFV50A FCFV60A FCFV85A FCFV100A FCFV125A 3P661416-2 B www.ttair.co.th | Tel : 02-385-0728 | E-mail : sales@ttair.co.th | LINE ID : @ttair...
-
Page 2: Table Of Contents
CONTENTS READ BEFORE OPERATION Safety precautions Remote Controller Overview Preparation Before Operation OPERATION COOL DRY Operation STREAMER Operation ECO+ Operation POWERFUL Operation SLEEP Operation LED Operation TIMER Operation Fault Diagnosis MAINTENANCE How to clean the air fi lter How to clean the suction grille How to clean top panel and remote controller PM2.5 Replacement... -
Page 3: Safety Precautions
Safety precautions Read the precautions in this manual This appliance is filled with R32. carefully before operating the unit. • After reading, keep this manual in a convenient place so that you can refer to it whenever necessary. If the equipment is transferred to a new user, be sure also to hand over the manual. - Page 4 • Be sure to install an earth leakage breaker. Failure to install an earth leakage breaker may result in electric shocks or fi re. • Only connect the air conditioner to the specifi ed power supply circuit. Power suppliers other than the one specifi...
- Page 5 For power supply, be sure to use a separate power circuit dedicated to the air conditioner. System relocation. • Consult your Daikin dealer about remodelling and relocation. www.ttair.co.th | Tel : 02-385-0728 | E-mail : sales@ttair.co.th | LINE ID : @ttair...
-
Page 6: Remote Controller Overview
REMOTE CONTROLLER OVERVIEW IR Signal Transmitter • To enable signal transmission, direct the transmitter to the indoor Display (LCD) unit. Note that in condition • Display the current where there is an obstacle settings. that blocks between the (This illustration shows transmitter and the indoor the full display of the unit, signal transmission... -
Page 7: Preparation Before Operation
PREPARATION BEFORE OPERATION Accessories The following accessories are included. Remote Controller Drywall screw Battery Holder To set the batteries 1. Release the battery cover at the back of the remote controller. 2. Insert two dry batteries (LR03:AAA). 3. Set the battery cover as before. Position correctly! Disposal Requirements... - Page 8 PREPARATION BEFORE OPERATION To operate the remote controller • Aim the transmitter of the remote controller at the receiver of the indoor unit. • Ensure there is no blockage such as curtain between the indoor unit and the remote controller, signal transmission will be unsuccessful.
- Page 9 PREPARATION BEFORE OPERATION To set the clock 1. Press button. °C • blinks. 2. Press to set the clock to present time. • Holding down button rapidly increases or decreases the time display. 3. Press button. • stop blinking, the present time will be displayed.
-
Page 10: Operation
COOL FAN DRY OPERATION To start operation 1. Press button to start the unit operation. °C 2. Press button to choose the desired operation mode. • Each pressing on the button advances the available operating mode in sequence below: COOL To stop operation 3. - Page 11 To change temperature setting 4. Press button. °C • The temperature segments on LCD display shall change whenever button is pressed. Operating Mode COOL DRY & FAN Set Temperature 16°C - 30°C Not applicable Range • Press simultaneously on to change the temperature display unit in Celcius (°C) or Fahrenheit (°F).
- Page 12 To change fan speed setting 5. Press button. °C • Each pressing on the button advances the fan speed mode in sequence. • In COOL mode: LOW FAN MEDIUM FAN HIGH FAN QUIET FAN AUTO FAN • In FAN mode: LOW FAN MEDIUM FAN HIGH FAN...
-
Page 13: Streamer Operation
STREAMER OPERATION To switch on the STREAMER operation 1. Press button. °C • will be displayed on the LCD. To switch off the STREAMER operation 2. Press button. • will disappear from the LCD. www.ttair.co.th | Tel : 02-385-0728 | E-mail : sales@ttair.co.th | LINE ID : @ttair... -
Page 14: Eco+ Operation
ECO+ OPERATION To start ECO+ operation 1. Press button. °C • will be displayed on the LCD. To cancel ECO+ operation 2. Press button. • will disappear from the LCD. The previous setting used before ECO+ operation will be resumed. ECO + Notes on ECO+ operation •... -
Page 15: Powerful Operation
POWERFUL OPERATION To start POWERFUL operation 1. Press button. °C • will be displayed on the LCD. • POWERFUL operation ends in 20 minutes. The previous setting used before POWERFUL operation will be resumed. To cancel POWERFUL operation 2. Press button. -
Page 16: Sleep Operation
SLEEP OPERATION To start SLEEP operation 1. Press button. SLEEP °C • will be displayed on the LCD. • LED Indication lights of unit will be dimmed down. To cancel SLEEP operation 2. Press button. SLEEP • will disappear from the LCD. The previous setting used before SLEEP operation will be resumed. -
Page 17: Led Operation
LED OPERATION To change or switch off the indication display on the indoor unit 1. Press button. °C • Each pressing on the button changes the indication display on the indoor unit. • For example, Light blue press Cool mode default Indication lights off Notes on indoor unit indication display For operating mode status indication display:... -
Page 18: Timer Operation
TIMER OPERATION To use OFF TIMER operation • Ensure the clock setting is set to present time (refer to method to set the clock under preparation before °C operation). 1. Press button. • will be displayed on the LCD and blinks. 2. - Page 19 To use ON TIMER operation • Ensure the clock setting is set to present time (refer to method to set the clock under preparation before °C operation). 1. Press button. • will be displayed on the LCD and blinks. 2. Press to set the on timer setting.
-
Page 20: Fault Diagnosis
FAULT DIAGNOSIS To perform error code diagnosis 1. Press and hold button for 5 seconds. • blinks. 2. Press to check on the error code. • Press on the button until a long "beep" acknowledgement heard from the indoor unit. To exit from error code diagnosis 3. - Page 21 Error code defi nition Error Code Meaning Normal Hardware error (Tact switch pin short) Indoor drain pump abnormal Indoor heat exchanger (1) thermistor short / open Indoor room thermistor short / open Compressor overload www.ttair.co.th | Tel : 02-385-0728 | E-mail : sales@ttair.co.th | LINE ID : @ttair...
-
Page 22: Maintenance
MAINTENANCE (For Service Personnel) ONLY A QUALIFIED SERVICE PERSON IS ALLOWED TO PERFORM MAINTENANCE WARNING CAUTION • Do not use fl ammable gas such as hair • Do not wash the air conditioner with water. sprays and insecticides near the air It may cause electric shocks or a fi... -
Page 23: How To Clean The Air Filter
HOW TO CLEAN THE AIR FILTER 1. Open the suction grille. 3. Clean the air filter. A) Using a vacuum cleaner • Use tooling such as test pan to open all three grille fi xture cover. B) Washing with water •... -
Page 24: How To Clean The Suction Grille
HOW TO CLEAN THE SUCTION GRILLE 1. Open the suction grille. 5. Reattach the suction grille. • Refer to Item No.1 of "HOW TO Safety String CLEAN THE AIR FILTER" section. 2. Remove the strings of the suction 40° grille. •... -
Page 25: How To Clean Top Panel And Remote Controller
HOW TO CLEAN TOP PANEL AND REMOTE CONTROLLER • Wipe with soft cloth gently so as to not damage any insulation on the surface. • When it is diffi cult to remove stains, use water or neutral detergent. NOTES • Do not use water of 50°C or higher. It may cause discoloration and deformation. •... -
Page 26: Not Malfunction Of The Air Conditioner
NOT MALFUNCTION OF THE AIR CONDITIONER The following symptoms do not • A “Pishi-pishi” squeaking sound indicate air conditioner malfunction. is heard when the air conditioner is in operation or after the stop of 1. THE AIR CONDITIONER DOES NOT operation. -
Page 27: Troubleshooting
TROUBLESHOOTING Please check before requesting 3. The air conditioner operates but it service. does not sufficiently cool or heat • Check if the air inlet or outlet of 1. If the air conditioner does not outdoor or indoor unit is blocked by operate at all. - Page 28 4. Operation was performed or stopped although the ON/OFF button was not pressed. • Are you sure that the ON/OFF timer operation is not used? Turn off the ON/OFF timer. Please refer to "TIMER Operation". • Are you sure that any remote control device is not connected? If the problem is not solved after checking the above points, please do not try to...
