5.1 Checking the trigger catch
Check the trigger catch (Fig. 1/Item H) each time
before using. The trigger catch must move freely
without catching. The spring on the trigger catch
must return the trigger catch to the released initial
position. Never use the equipment if the trigger
catch is not working.
1. Disconnect the equipment from the air supply.
2. Remove the staples/nails from the magazine
(Fig. 1/Item E).
3. Check that the trigger and the trigger catch
can move up and down freely.
4. Connect the equipment to the air supply.
5. Press the trigger catch against the workpiece
without pressing the trigger. The equipment
should not operate. Never use the equip-
ment if it operates without the trigger being
pressed. Risk of injury!
6. Remove the equipment from the workpiece.
The trigger catch must return to the released
initial position. Press the trigger. The equip-
ment should not operate. Never use the
equipment if it operates. Risk of injury!
7. Press the trigger and press the trigger catch
against the workpiece. The equipment opera-
tes.
8. Press the trigger catch against the workpiece
and press the trigger; the equipment opera-
tes.
5.2 Loading staples and nails
•
When you fill the magazine (Fig. 1/Item E),
make sure that you hold the equipment in
such a way that the muzzle is pointed neither
at you or anyone else.
•
To fill the magazine, press the magazine lever
(Fig. 1/Item C) and slide back the magazine
cover (Fig. 1/Item D) as far as it will go.
•
Insert the staples as shown in (Fig. 3) or the
nails as shown in (Fig. 4).
•
Do not insert more than one complete stick
of staples/nails, otherwise the magazine will
be overfilled and you will not be able to close
it again. Slide the magazine cover forward
again until it snaps into place.
•
The level indicator (Fig. 5/Item F) shows the
number of loaded staples / nails if less than
50 are loaded.
Anl_TC_PN_50_GB_Korea.indb 10
Anl_TC_PN_50_GB_Korea.indb 10
GB
6. Operation
6.1 Operation/Operating pressure
•
Connect the pneumatic stapler/nailer to the
compressed air connection (Fig.1/Item B).
•
Set the swivel air outlet (Fig.1/Item K) to the
desired position.
•
Before starting the stapler, switch on the com-
pressor and set the operating pressure on the
pressure reducer to 4 bar.
•
The knurled screw (Fig. 6/Item G) for precis-
ion adjustment must be approximately in the
middle position between Item 1 and 2. To do
so, turn open the knurled screw three revolu-
tions, starting from Position 1.
•
For the purpose of setting the operating
pressure it is advisable to use a test workpi-
ece which is similar in structure and material
thickness to the workpieces to be joined.
•
To staple/nail, place the pneumatic stapler/
nailer against the workpiece. Pull the trigger
lever (Fig. 1/Item A) once and release it again
after each shot.
•
If the nail or the staple goes in too deep, re-
duce the operating pressure on the pressure
reducer by 0.5 bar.
•
If the nail or the staple does not go in deep
enough or projects, increase the operating
pressure on the pressure reducer by 0.5 bar.
•
Place the stapler/nailer against the test work-
piece again and fire.
•
Depending on results, keep changing the
operating pressure in 0.5 bar increments until
the depth that the staples or nails are driven
in is roughly correct. For precision adjustment
(Section 6.2), use the knurled screw.
•
The equipment also has an automatic mode.
If you keep the trigger lever pressed, the stap-
les/nails will be shot automatically when the
pneumatic stapler/nailer is placed against the
workpiece.
•
To prevent faults, make sure that you do not
staple at the same point twice.
Danger!
If a staple or nail becomes jammed in the feed
shaft, always immediately depressurize the equip-
ment fi rst (remove the compressed air supply
hose), open the magazine shaft and only then re-
move the cover plates (Fig. 8/Item I/J) by undoing
the screws with the supplied hex key (Fig. 2/Item
N) (Fig. 7/8). Remove the jammed staples, clean
the shaft if necessary, and close again in reverse
order.
- 10 -
