Planning Information
Undercounter Model UC-24C
W I N E S H E L F W O O D F A C I N G
1
19 / "
2 (495)
FRONT VIEW
Dimensions in parentheses are in
millimeters unless otherwise specified.
5
/ "
8
(16)
7
/ "
64
(3)
1
1 / "
2 (38)
27
/ "
32
5
/ "
64
(21)
(2)
23
/ "
64
(9)
9
/ "
16 (14)
F U L L - S C A L E T E M P L A T E S
The full-scale illustrations on this page and the following
page enable you to understand some of the unique situa-
tions you may face as you design the Undercounter units
into homes. These templates can be easily photocopied or
used in your tracings.
W I N E S H E L F W O O D F A C I N G
For Model UC-24C, use the full-scale illustration above as
a template if you choose to replace the natural cherry
wood facing with wood more complementary to your
design and surrounding cabinetry.
Maximum Thickness
SIDE VIEW
