Sub-Zero 424FS Planning Information page 5

Planning Information
Wine Storage Model 424FS
W I N E S H E L F W O O D F A C I N G
1
19 / "
WIDTH
2 (495)
FRONT VIEW
Dimensions in parentheses are in
millimeters unless otherwise specified.
5
/ "
8
(16)
7
/ "
64
(3)
1
1 / "
2 (38)
27
/ "
32
5
/ "
(21) 64
(2)
23
/ "
64
(9)
9
/ "
16 (14)
F U L L - S C A L E T E M P L A T E
Use the full-scale illustration above as a template if you
choose to replace the natural cherry wood facing with
wood more complementary to your design and surround-
ing cabinetry.
Maximum Thickness
SIDE VIEW
5
