  • Page 1 O P E R A T I N G I N S T R U C T I O N S Visionary-B Two 3D machine vision...
  • Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK Subject to change without notice...

  • Page 3: Table Of Contents

    Changing the IP address using GigE_Streamer_Basic ......Changing the IP address using SICK AppManager......... 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...
  • Page 4 12.1 Declarations of conformity and certificates..........12.2 Licenses....................O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK Subject to change without notice...

  • Page 5: About This Document

    {S/N} corresponds to the serial number of the product, see type label (if indicated). 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...
  • Page 6 Certificates (e.g., declaration of conformity) • Other publications • Software • Accessories O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK Subject to change without notice...

  • Page 7: Safety Information

    SensorApps are installed using the SICK AppManager. 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...

  • Page 8: Improper Use

    • To receive security updates, update the product to the latest firmware. O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK Subject to change without notice...

  • Page 9: Qualification Of Personnel

    • knowledge of the applicable regulations and standards 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...

  • Page 10: Product Description

    QR code with a link to the product and more information Product ID Type designation ß O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK Subject to change without notice...

  • Page 11: Product Overview

    O (all) (Green) Data transmission: API channel active 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...

  • Page 12: Sick Appspace

    (3D point cloud) is created from the image overlay, comparable to human spatial vision. O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK...
  • Page 13 Figure 4: Camera image left Figure 5: Camera image right 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...
  • Page 14 Alternatively, it is possible to process the acquired data internally. O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK...

  • Page 15: Interface Standards

    Complementary information Further information is available at https://www.automate.org/a3-content/vision-stand‐ ards. 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...

  • Page 16: Mounting

    O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK...

  • Page 17: Mounting The Product

    Further topics • Pin assignment • Dimensional drawing 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...

  • Page 18: Electrical Installation

    If necessary: low-impedance and current-carrying equipotential bonding between ■ areas with different ground potentials O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK Subject to change without notice...
  • Page 19 This measure achieves a high degree of resistance to electromagnetic interference. 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...
  • Page 20 For smaller installations with only slight potential differences, insulated mounting of the device and peripheral devices may be an adequate solution. O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK...

  • Page 21: Calculation Rule

    Steady state of the voltage supply • Supported cables: M12, 17-pin 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...

  • Page 22: Cable Reserve On System Plug

    Experience has shown that 200 to 300 mm of cable reserve on the device is ideal. O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK...

  • Page 23: Pin Assignment

    2 SENS In 2 Digital input 2 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...
  • Page 24 Further topics • Information on interfaces: Technical data O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK Subject to change without notice...

  • Page 25: Configuration

    Run the installation file (EXE). Follow the instructions. 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...

  • Page 26: Installing Sick Appstudio

    To display the user interface, enter the IP address of the device in the web browser. O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK...

  • Page 27: Programming The Device

    To optimize the device for the application, adjust the following parameters. 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...
  • Page 28 O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK...
  • Page 29 Downloads > Software > ZIP file. 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...

  • Page 30: Changing The Ip Address Using Gige_Streamer_Basic

    Click on Edit IP address. Enter an IP address. O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK Subject to change without notice...

  • Page 31: Maintenance

    Clean the viewing window at regular intervals and in the event of contamination. 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...

  • Page 32: Troubleshooting

    SICK AG. Interference with or modifications to the device on the part of the customer will invalidate any warranty claims against SICK AG. O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK...

  • Page 33: Decommissioning

    SICK will be glad to help you dispose of these products on request. 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...

  • Page 34: Technical Data

    1.5 A Protection class Enclosure rating IP67, IP69, IP6X9K  O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK Subject to change without notice...

  • Page 35: Dimensional Drawing

    Approx. 1300 mm, at 25 m Approx. 2800 mm, at 37 m 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...

  • Page 36: Interfaces

    Sick AppStudio, Sick AppManager, SOPASair software Operating system Windows, Linux O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK Subject to change without notice...

  • Page 37: Ambient Data

    5 minutes with a 24 V supply voltage applied. After the warm-up time, restart the device by briefly interrupting the power supply. 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...

  • Page 38: Accessories

    {S/N} corresponds to the serial number of the product, see type label (if indicated). O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two 8028562/2023-12-07 | SICK...

  • Page 39: Annex

    For license texts, see www.sick.com/licensetexts. Printed copies of the license texts are also available on request. 8028562/2023-12-07 | SICK O P E R A T I N G I N S T R U C T I O N S | Visionary-B Two Subject to change without notice...
