SICK Ruler E150 Reference Manual

1 Safety
Q U I C K S TA R T
b Read the entire Quickstart before using the device.
Ruler E b Connection, assembly, and settings must be performed by
competent technicians.
b Do not connect external I/O signals to the device while it is
3D vision
powered. This may damage the device.
b Do not use the device in areas with risk for explosion.
b Safe operation has a dependency on the selected laser
EN
class of the device (see
section
Manual.
2 Product Specification
Ruler E is a high-speed 3D camera that can measure up to
10,000 shape profiles/s. The device is factory calibrated
and measurements are provided in a metric scale (mm). The
camera can also provide gray scale and laser scatter informa-
tion at the same time.
Ruler E has an in-built light source (laser). It is designed for
rough industrial environments, and is protected by a robust
IP65 housing. It is available in several variants (see
options for different fields-of-view, laser power, window material,
heating elements for cold environments, and laser scatter
measurements.
Ruler E serves as a data streamer, from which the measure-
ment data is transferred through a Gigabit Ethernet connec-
tion to a PC for further processing. The Ruler can be started,
stopped and configured by applications running on the PC.
Note that the 3D Camera Development software is required
to build such applications. Ruler E is intended to be the vision
component in a machine vision system.
The ISM Radio Frequency Classification is Group 1, Class A
(EN55011).
a
3 Connections
Ruler E is connected to a 24 V DC power supply, and to a
PC running Windows 7/XP equipped with a Gigabit Ethernet
network board.
b The power supply is connected to the Power I/O connector
(M12 connector).
b The Gigabit Ethernet board in the PC is connected to the
Gigabit Ethernet connector, either directly or through an
Ethernet switch.
b I/O signals that are used, for example pulse trigger signals
from encoders or an enable signal from a photoelectric
switch, are connected to the Power I/O and the Encoder
connector respectively (M12 connectors).
4 System Requirements
b PC
Australia Norway
b Ethernet
Phone +61 (3) 9457 0600 Phone +47 67 81 50 00
cable
1800 33 48 02 – tollfree
Poland
Austria Phone +48 22 539 41 00
5 Installation
Phone +43 (0) 2236 62288-0
Romania
Belgium/Luxembourg Phone +40 356-17 11 20
a
Phone +32 (0) 2 466 55 66
Russia
Brazil Phone +7 495 283 09 90
Phone +55 11 3215-4900
Singapore
Canada Phone +65 6744 3732 a
Phone +1 905.771.1444
Slovakia
Czech Republic Phone +421 482 901 201
b Install the Gigabit Ethernet board
Phone +420 2 57 91 18 50
Slovenia Development software
Chile Phone +386 591 78849
b Mount the Ruler in respect to the defined field-of-view
Phone +56 (2) 2274 7430
South Africa
and other equipment to be used by the vision system such
China Phone +27 (0)11 472 3733
as encoder and photoelectric switch.
Phone +86 20 2882 3600
South Korea
b If I/O signals are used, such equipment may be connected
Denmark Phone +82 2 786 6321
to the Power I/O via a T-junction
Phone +45 45 82 64 00
Spain
Encoder is connected directly to the Ruler.
Finland Phone +34 93 480 31 00
b Connect the Gigabit Ethernet connector on the Ruler to a
Phone +358-9-25 15 800
Sweden
dedicated Gigabit network, or directly to the Gigabit network
France Phone +46 10 110 10 00
connector on the PC using a Gigabit Ethernet cable
Phone +33 1 64 62 35 00
Switzerland
b Connect an unpowered 24 V DC power supply
Germany Phone +41 41 619 29 39
Phone +49 (0) 2 11 53 01 I/O connector on the Ruler.
Taiwan
Hong Kong Phone +886-2-2375-6288 b Switch on the power supply.
Phone +852 2153 6300
Thailand
For detailed installation instructions, see the Ruler E Refer-
Hungary Phone +66 2 645 0009
ence Manual that can be found on the 3D Camera Develop-
Phone +36 1 371 2680
Turkey
ment software CD, or downloaded from:
India Phone +90 (216) 528 50 00
visionsupport.sick.com
Phone +91-22-6119 8900
United Arab Emirates
6 Service and Maintenance
Israel Phone +971 (0) 4 88 65 878
Phone +972-4-6881000
United Kingdom The Ruler E contain no user serviceable parts inside. The
Italy Phone +44 (0)17278 31121 warranty of the device will be void if opened.
Phone +39 02 27 43 41
USA
a
Japan Phone +1 800.325.7425
Phone +81 3 5309 2112
Vietnam
Malaysia Phone +65 6744 3732
b Check screw connections and connectors at regular
Phone +603-8080 7425
intervals.
Mexico
b Clean the housing with a soft cloth, dry or dampened with a
Phone +52 (472) 748 9451
mild water diluted cleaning agent without powder additives.
Netherlands
Phone +31 (0) 30 229 25 44 In case of unit failure, please contact SICK or a SICK represen-
tative that delivered the unit for further instructions.
New Zealand
Phone +64 9 415 0459
7 Further Information
0800 222 278 – tollfree Detailed addresses and further
locations at www.sick.com
For more information on the Ruler E, please refer to the
Ruler E Reference Manual.
For support issues, please visit the online support on:
supportportal.sick.com.
8012569/ZZQ0 ∙ 2018-06 More product information is also available on:
All rights reserved. Subject to change without prior notice.
AG | Waldkirch | Germany | www.sick.com www.sick.com
A
Laser Safety
The legal regulations on laser safety for the laser class
of Ruler E must be adhered to.
Ruler E class 3B
). Carefully study the Laser safety is equipped with a Class 3B laser according to EN/
E
and the safety instructions in Ruler E Reference IEC 60825-1:2014 and EN/IEC 60825-1:2007. It
A
complies with 21 CFR 1040.10 except for deviations
pursuant to Laser Notice No. 50, dated June 24, 2007.
It cannot be considered as a stand-alone unit and must
only be used as part of a laser system which incorpo-
rates additional features depending on class 3B.
a Danger: Ruler E 3B has to be considered danger-
ous to retinas if exposed. The classification to
class 3B leads to the necessity of additional
safety requirements which have to be fulfilled.
b The user has to name a laser safety officer (follow
) with
E
national standards).
b A key-box with a removable key
should not be possible to power-on the laser unit.
b A connector readily available for connecting a remote
emergency stop and/or remote barrier interlock.
b A beam attenuator and an emission indicator must be
available in the system.
b The device must be integrated into a setup with
adequate optical encapsulation according to laser
safety regulations (safety interlock and casing).
Ruler E class 2 (2M)
is equipped with a Class 2 laser according to EN/IEC
Warning: Class A equipment is intended to be used in
60825-1:2014 (2M according to EN/IEC 60825-1:2007).
an industrial environment.
It complies with 21 CFR 1040.10 except for deviations
pursuant to Laser Notice No. 50, dated June 24, 2007.
C
CAUTION: Class 2 (2M) lasers emit visible radia-
a
tion in the wavelength range from 400 nm to 700
nm where eye protection is normally afforded by
aversion responses including the blink reflex.
However, viewing of the output is hazardous if the
user employs optical instruments within the beam or
suppresses aversion responses intentionally. Temporary
irritating optical influence (glare, flash blindness,
after-image) on the human eye can not be excluded, in
particular in combination with low ambient light level.
b Do not stare into beam.
b Do not view the laser beam directly with optical
instruments like magnifying glasses.
b Do not aim the laser beam of the device at the eyes of
a person.
Recommended: Windows XP Pro 32/64 bit or
For both laser classes
Windows 7 32/64 bit, at least 4 GB memory,
Gigabit Ethernet network card supporting jumbo
b Reconsider newest laser safety regulations.
frames. b Do not open the housing of the device.
Up to 70 m using CAT 6 cables.
Danger: The laser may be activated as soon as
a
For longer distances or tough environments,
the Ruler E is powered on. Avoid direct exposure
opto cables can be used.
to the laser beam. Avoid looking at the laser
reflection.
B
Ruler E is a laser product, and operation using procedures
Ensure that all laser safety requirements for the
other than those specified herein may result in hazardous
appropriate laser class system are fulfilled (see and
A
radiation exposure.
Ruler E Reference Manual).
b During installation and alignment operations appropriate
Ensure that the Ruler is unpowered during the installa-
eye protection should be used.
tion process.
b To sustain these specific laser classes no maintenance is
and the 3D Camera necessary.
a
on the PC. Important: Should the Ruler E be included into a system/
b
,
F
B
or a terminal box .
c d
.
e
to the Power
f
Warning: To avoid hazardous radiation exposure, the
power to the laser unit of the Ruler must be turned off
before maintenence is performed
casing, so that the laser safety notice signs are hidden,
additional signs must be placed beside the exit aperture
of the laser beam on the system/casing. Additional signs
are not included in the delivery.
Class 2 – "Caution"
. Without the key it
d
LASER RADIATION - DO NOT STARE
INTO BEAM OR USE WITH MAGNIFIERS
CLASS 2 LASER PRODUCT
Class 3B – "Danger"
WARNING - LASER RADIATION
AVOID DIRECT EXPOSURE TO BEAM
CLASS 3B LASER PRODUCT
b
a
External warning
lamps and
d
remote interlock
g
f
90 ... 260 VAC 24 VDC
c
Photo switch
Encoder
C
POWER I/O CONNECTOR ENCODER CONNECTOR
6
5
7
4
1
3
8
2
Pin Signal Remark Pin Signal
1 In1 Enable (24 V) 1 In_A+
2 Power 24 VDC power supply 2 In_B+
3 Out1 Reserved (do not 3 In_B-
connect)
4 In_A-
4 In2 Reset (24 V)
5 AUX GND Encoder ground (<100 mA)
5 TRA TRA RS-485
6 –
6 TRB TRB RS-485
7 In4
7 GND Ground
8 Out2
8 In3 Laser power supply
(24 VDC)
1 3
Gigabit Ethernet
2 4
Encoder (M12, 8 pin)
I/O signal levels Low
Class B outputs (24 V) 0 ... +2.5 V
Device inputs (24 V) 0 ... +2.0 V
Differential signal Input voltage range Input differential
Threshold voltage
RS-485 –7 ... +12 V ±200mV
RS-422 (Encoder) –7 ... +12 V ±200mV
D
Ruler E600 Ruler E1200
(Ruler-E2xxx) (Ruler-E1xxx)
1
3
e
1
Image sensor
2 Laser unit
3
Fastening threads (M8 x 15 mm)
HEATING CONNECTOR
(Ruler-Ex2xx)
4
2
5
5
3
3
6
2
1
7
8
1 4
Remark Pin Signal Remark
1 Power 24 VDC power supply
Phase 1, RS-422 +
Phase 2, RS-422 + 2 GND Ground
Phase 2, RS-422 - 3 GND Ground
Phase 1, RS-422 - 4 Power 24 VDC power supply
5 Out_A Temperature control
Reserved
Monitor Enable (24 V)
Reserved (do not connect)
3
2
4
Power I/0 (M12, 8 pin)
1
Heating (by option) (M12, 5 pin)
High Remark
(U - 2.5 V) ... U Max output current: 100 mA (in total)
supply supply
Reset, Enable, Monitor
+7.0 ... U
supply Pulldown 30 kΩ.
Differential driver Remark
output (min)
±2,0V Termination 100 Ω
---- Termination 100 Ω
All models
2
Ruler E150
(Ruler-E4xxx)
1 2
3
