Product description:
Door-combined step for
mounting under the
vehicle floor
Type: X3
Installation manual
Technical Details:
Legislation: The product complies with the conditions of Directive 98/37/EC ("Machinery Directive")
Tel: +1 519.688.1043 | Fax: +1 866.223.2256 | i n f o @ l e g e n d f l e e t . c o m |
Vehicle type:
MB Sprinter 2006 until now
VW Crafter 2006 until
2017
Rear-wheel drive
Wheelbase: L2 / L3 / L4
Wheelbase
:
middle - 3665 mm /
long - 4325 mm
New Article-No.:
101315
101608
Load capacity:
350 kg
Schutz
Rampen
Steps
Old article No.:
X3-1000MS.1
X3-1200MS.1
Sicherheit
Dachträger
www.legendsoftheroad.com
Advertisement
Table of Contents
Related Manuals for Legend 101315
Summary of Contents for Legend 101315
- Page 1 Vehicle type: Product description: New Article-No.: Old article No.: MB Sprinter 2006 until now Door-combined step for 101315 X3-1000MS.1 VW Crafter 2006 until mounting under the X3-1200MS.1 101608 2017 vehicle floor Rear-wheel drive Type: X3 Wheelbase: L2 / L3 / L4...
-
Page 2: Foreword
The use of other parts therefore cancels the liability for the resulting consequences. X3 series | door-combined step for LEGEND FLEET SOLUTIONS 2 | 18 mounting under the vehicle floor... -
Page 3: Table Of Contents
4.2 MOUNTING TO SLIDING DOOR ................14 5. USE OF STEP .......................... 18 6. CARE/MAINTENANCE ......................18 7. DISPOSAL ..........................18 8. CUSTOMER SERVICE ......................18 X3 series | door-combined step for 3 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor... -
Page 4: Safety
When extending and retracting the step, there must be no persons on it. There is a risk of jamming/crushing during transport and assembly. Therefore, secure the step with suitable aids during transport. X3 series | door-combined step for 4 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor... -
Page 5: Step
The step has a non-slip surface. To increase safety, it is provided with rounded outer edges. 2.2 CONSTRUCTION Frame construction Operating lever Buffer Stop Tread anti-slip surface X3 series | door-combined step for 5 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor... -
Page 6: Vehicle Specific Mounting Kit
• Model: 518 / 515 / 315 • Wheelbase: middle & long DOOR MOUNTING KIT MB SPRINTER (165-00-0041AD.1) MOUNTING KIT MB SPRINTER (160 -13-106AD.1) X3 series | door-combined step for 6 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor... -
Page 7: Overview Door Mounting Kit Mb Sprinter (165-00-0041Ad.1)
ISO 7380-M6 x16 – 16N Flat head screw ISK ISO 7089-6 Washer DIN912 M6x8-8.8 Cap screw with ISK NLDF6 Locking Plate DOOR MOUNTING KIT MB SPRINTER “EXPLOSION” X3 series | door-combined step for 7 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor... -
Page 8: Overview Mounting Kit Mb Sprinter (160-13-106Ad.1)
Hexagon nuts with clamping part DIN 985-M10-10 VZ Hexagon nuts with clamping part DIN 933-M8X50-8.8 VZ Hexagon head screw Wiehl-M131677 Spacer sleeve 25 mm X3 series | door-combined step for 8 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor... -
Page 9: Pre-Assembl Mounting Kit
3. PRE-ASSEMBLY MOUNTING KIT Pre-assemble the holders as shown: X3 series | door-combined step for 9 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor... -
Page 10: Installation
Align the step under the vehicle and secure it against accidental tipping or falling! The step must be aligned parallel to the vehicle. X3 series | door-combined step for 10 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor... - Page 11 1x Distance sleeve 25 mm 1x Sleeve 1x screw M10x100 1x washer 10.5 1x Nut self. M10 X3 series | door-combined step for 11 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor...
- Page 12 4. INSTALLATION Details of position 2 (rear left bracket) 1x sleeve 1x screw M10x80 1x washer 10.5 1x Nut self. M10 X3 series | door-combined step for 12 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor...
- Page 13 Please note to reseal drilled holes with suitable means! Then screw the mounting brackets to the sill. 4x screw M6x20 4x washer 6.5 4x Nut self. M6 X3 series | door-combined step for 13 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor...
-
Page 14: Montage An Schiebetür
1. Mounting connecting rod to actuating lever 1x ISK screw M6x20 1x centring piece 1x clip bearing 1x nut self. M6 1x NLDF6 1x M6x6 screw X3 series | door-combined step for 14 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor... - Page 15 4. INSTALLATION Mounting door connection plate to connecting rod 1x ISK screw M6x20 1x centring piece 1x clip bearing 1x nut self. M6 X3 series | door-combined step for 15 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor...
- Page 16 Then drill 3 x Ø6.5 mm holes at the marked points. Please note to reseal drilled holes with suitable means! 3x ISK flat head screw M6x16 3x washer 6.5 3x nut self. M6 X3 series | door-combined step for 16 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor...
- Page 17 To finish, a plastic cover cap can be fitted to the door connection plate using the clips. Subsequently, the installation should be checked and the function tested. X3 series | door-combined step for 17 | 18 LEGEND FLEET SOLUTIONS mounting under the vehicle floor...
-
Page 18: Use Of Step
The manufacturer accepts no liability for damage caused by improper execution of disposal. 8. CUSTOMER SERVICE The customer service of LEGEND Fleet Solutions is at your disposal for ordering spare parts, for maintenance and repair work and for problems and questions.
