Summary of Contents for Legend LK1-121-03
- Page 1 INSTALLATION GUIDE MOTION-SENSOR CEILING LIGHTS TWO LIGHT KIT: LK1-121-02 THREE LIGHT KIT: LK1-121-03 FOUR LIGHT KIT: LK1-121-04...
- Page 2 Tools Required for Mercedes Sprinters: - T25 Torx bit - T30 Torx bit Other Optional Tools - Cutting pliers (these may be needed, depending on your preferred attachment method for the wires) Page 2 of 36 Legend Light Kit Install Guide v2.2...
-
Page 3: Table Of Contents
Ford Transit Electrical Feed Loom Installation………………………………………..……Page 4 Ram Promaster Electrical Feed Loom Installation……………………………..…..Page 6 Mercedes Sprinter Electrical Feed Loom Installation…………………………………Page 8 LK1-121-02 (2 Light Kit) Installation………………………………………………..………………Page 11 LK1-121-03 (3 Light Kit) Installation…………………………………………………..……………Page 18 LK1-121-04 (4 Light Kit) Installation……………………………………………….………………Page 26 Troubleshooting Tips…………………………………………………………….…………………………Page 36 ________________________________________________________ Step 1: Install electrical feed loom cable. -
Page 4: Ford Transit Electrical Feed Loom Installation
Transit, this is found on the left-hand side of the driver’s seat base. Step 2b: Locate the live 12V feed. This will be either of the middle pins, circled below. In most cases, it is the bottom pin. Verify with a multimeter. Page 4 of 36 Legend Light Kit Install Guide v2.2... - Page 5 Step 2c: Attach the ground (BLUE) cable as shown below, with one of the included M6x1 Nyloc nuts. Step 2d: Re-attach the plastic cover bracket, as shown. Page 5 of 36 Legend Light Kit Install Guide v2.2...
-
Page 6: Ram Promaster Electrical Feed Loom Installation
________________________________________________________________ RAM PROMASTER FEED LOOM INSTALLATION: Step 3a: Remove the plastic cover protecting the battery. On the Ram Promaster, this is found underneath the driver’s floor mat, as shown below. Page 6 of 36 Legend Light Kit Install Guide v2.2... - Page 7 Step 3b: Attach the ground (BLUE) cable to the battery ground terminal as shown below; use the existing nut. Step 3c: Attach the live (ORANGE) cable to the live terminal as shown below; use the existing nut. Page 7 of 36 Legend Light Kit Install Guide v2.2...
-
Page 8: Mercedes Sprinter Electrical Feed Loom Installation
Step 4a: Locate the battery. In the Mercedes Sprinter this is under the driver side floor pan. Using Torx T25 and T30 bits, remove the floor pan and battery cover. Page 8 of 36 Legend Light Kit Install Guide v2.2... - Page 9 Step 4b: Attach the ground (BLUE) cable to the battery holding case as shown below. Using the existing Torx bolt. Step 4c: Attach the live (ORANGE) cable to the live terminal as shown below. Use the existing nut. Page 9 of 36 Legend Light Kit Install Guide v2.2...
- Page 10 Step 4d: Replace battery cover and floor. PROCEED TO STEP 5 BELOW. Step 5: Proceed to light system installation instructions. For 2 Light Kits (LK1-121-02) turn to page 11. For 3 Light Kits (LK1-121-03) turn to page 18. For 4 Light Kits (LK1-121-04) turn to page 26. Page 10 of 36...
-
Page 11: Lk1-121-02 (2 Light Kit) Installation
NOTE: The installation should only require 1 of these; an extra cable has been included as a spare. 2x 3-meter Rappid Cable (SSC3MF) 1x T-Connector (SSMFT) 1x Hole Template 2x M6x1 Nyloc Nuts Page 11 of 36 Legend Light Kit Install Guide v2.2... - Page 12 COMPONENT OVERVIEW: Page 12 of 36 Legend Light Kit Install Guide v2.2...
- Page 13 3. (If the ceiling liner is 120” long, the lights should be spaced 40” apart.) - If no ceiling liner is being installed, you will need the Legend standalone brackets. These are attached to the ceiling supports with self-tapping screws, which are included in the standalone kits.
- Page 14 Note: if the single 3m cable is not long enough to reach the first light, use the included extra 1.5m cable. Step 2: Plug in the T-Connector to the end of the 3-meter cable. Ensure that the housings have clicked together. Page 14 of 36 Legend Light Kit Install Guide v2.2...
- Page 15 Step 4: Connect a 3-meter Rappid cable to the T-Connector and run it to the next light location. Page 15 of 36 Legend Light Kit Install Guide v2.2...
- Page 16 Step 5: Ensure that the cables can reach the desired light locations, then secure them to the vehicle side frame and ceiling cross beams using your preferred method. Legend recommends tuck tape or similar. Step 6: Install ceiling liner, if applicable.
- Page 17 Step 10: Secure the lights to the ceiling. If ceiling liner is installed, use the screws included with the lights. If installing on the standalone brackets, use the self tappers included in the bracket package. THIS COMPLETES THE INSTALLATION. Page 17 of 36 Legend Light Kit Install Guide v2.2...
-
Page 18: Lk1-121-03 (3 Light Kit) Installation
NOTE: The installation should only require 3 of these; an extra cable has been included as a spare. 2x 3-meter Rappid Cable (SSC3MF) 2x T-Connector (SSMFT) 1x Hole Template 2x M6x1 Nyloc Nuts Page 18 of 36 Legend Light Kit Install Guide v2.2... - Page 19 COMPONENT OVERVIEW: Page 19 of 36 Legend Light Kit Install Guide v2.2...
- Page 20 20” from the end, then each subsequent light 40” apart. This usually gives the best light coverage. - If no ceiling liner is being installed, you will need the Legend standalone brackets. These are attached to the ceiling supports with self-tapping screws, which are included in the standalone kits.
- Page 21 Note: if the single 3m cable is not long enough to reach the first light, use the included extra 1.5m cable. Step 2: Plug in the T-Connector to the end of the 3-meter cable. Ensure that the housings have clicked together. Page 21 of 36 Legend Light Kit Install Guide v2.2...
- Page 22 Step 4: Connect a 1.5-meter Rappid cable to the T-Connector. Ensure that the housings have clicked together. This will run to the next T-Connector. Page 22 of 36 Legend Light Kit Install Guide v2.2...
- Page 23 This cable will connect to a light, so ensure that it can reach the corresponding light location and is on the correct side of the nearest ceiling joist. Page 23 of 36 Legend Light Kit Install Guide v2.2...
- Page 24 Step 8: Ensure that the cables can reach the desired light locations, then secure them to the vehicle side frame and ceiling cross beams using your preferred method. Legend recommends tuck tape or similar. Step 9: Install ceiling liner, if applicable.
- Page 25 Step 13: Secure the lights to the ceiling. If ceiling liner is installed, use the screws included with the lights. If installing on the standalone brackets, use the self tappers included in the bracket package. THIS COMPLETES THE INSTALLATION. Page 25 of 36 Legend Light Kit Install Guide v2.2...
-
Page 26: Lk1-121-04 (4 Light Kit) Installation
NOTE: The installation should only require 5 of these; an extra cable has been included as a spare. 2x 3-meter Rappid Cable (SSC3MF) 3x T-Connector (SSMFT) 1x Hole Template 2x M6x1 Nyloc Nuts Page 26 of 36 Legend Light Kit Install Guide v2.2... - Page 27 COMPONENT OVERVIEW: Page 27 of 36 Legend Light Kit Install Guide v2.2...
- Page 28 20” from the end, then each subsequent light 40” apart. This usually gives the best light coverage. - If no ceiling liner is being installed, you will need the Legend standalone brackets. These are attached to the ceiling supports with self-tapping screws, which are included in the standalone kits.
- Page 29 Note: if the single 3m cable is not long enough to reach the first light, use the included extra 1.5m cable. Step 2: Plug in the T-Connector to the end of the 3-meter cable. Ensure that the housings have clicked together. Page 29 of 36 Legend Light Kit Install Guide v2.2...
- Page 30 Step 4: Connect a 1.5-meter Rappid cable to the T-Connector. Ensure that the housings have clicked together. This will run to the next T-Connector. Page 30 of 36 Legend Light Kit Install Guide v2.2...
- Page 31 This cable will connect to a light, so ensure that it can reach the corresponding light location and is on the correct side of the nearest ceiling joist. Page 31 of 36 Legend Light Kit Install Guide v2.2...
- Page 32 This will run to the next T-Connector. Step 8: Plug in the third T-Connector to the end of the 1.5-meter cable. Ensure that the housings have clicked together. Page 32 of 36 Legend Light Kit Install Guide v2.2...
- Page 33 Step 10: Connect a 3-meter Rappid cable to the T-Connector and run it to the next light location. Page 33 of 36 Legend Light Kit Install Guide v2.2...
- Page 34 Step 11: Ensure that the cables can reach the desired light locations, then secure them to the vehicle side frame and ceiling cross beams using your preferred method. Legend recommends tuck tape or similar. Step 12: Install ceiling liner, if applicable.
- Page 35 Step 16: Secure the lights to the ceiling. If ceiling liner is installed, use the screws included with the lights. If installing on the standalone brackets, use the self tappers included in the bracket package. THIS COMPLETES THE INSTALLATION. Page 35 of 36 Legend Light Kit Install Guide v2.2...
-
Page 36: Troubleshooting Tips
7. Using an electrical multimeter on continuity mode, check the fuse. If there is no continuity, the fuse is faulty/blown and should be replaced. 8. If none of these steps resolves the issue, contact Legend Fleet at 1-519- 688-1043, and ask to speak with Warwick.
