Pin descriptions for RS-485 are given in Table 2-3. COM1 Port Pin Details (RS-485).
3.3.7.10
com1.rtu ["on" or "off"]
This attribute enables the embedded RTU simulator poll detection and response. Default is "off".
When set to "on" this enables devices in a network to be polled using standard GE MDS polling utilities.
3.3.7.11
com1.rtuid [0-80]
This attribute assigns an address/ID to the local radios embedded RTU simulator. Default is "0".
Ippl settings
The Ippl attribute group contains settings associated with IP/Payload. IP/Payload as originally introduced
in the GE MDS SD licensed radio series. IP/Payload acts like a terminal server with the serial port side
routed as over-the-air streaming traffic.
NOTE
VRC fields for this attribute group are reserved for future application and not currently used.
>cfg get ippl
{
enabled: "off",
mode: "udp",
talk_on_vrc: 1,
listen_to_vrc: 1,
local_ip_port: 30011,
ip_peer_addr: 192.168.1.1
ip_peer_port: 30011,
connection_timeout: 0,
keepAlive: "off"
}
3.3.8.1 ippl.enabled ["on" or "off"]
This attribute enables IP/Payload. Default is "off".
3.3.8.2 ippl.mode ["udp", "tcp-client", or "tcp-server"]
This attribute enables the operational mode "udp" or "tcp" and for tcp indicates if the radio should act as a
server or client.
3.3.8.3 ippl.local_ip_port [0-65000]
This attribute specifies the local_ip_port for TCP server use it. It is not used when ippl.mode is not equal
to "tcp_server". The corresponding IP address is the value from eth.ipaddr. The default port is 0.
3.3.8.4 ippl.ip_peer_addr [xxx.xxx.xxx.xxx]
This attribute specifies the IP peer address for UDP and TCP client use. It is not applicable for TCP
server. The value is specific in IPv4 dot decimal format. The default is 192.168.1.1.
3.3.8.5 ippl.ip_peer_port [0-65000]
This attribute specifies the IP peer port for UDP and TCP client use. It is not applicable for TCP server.
The default port is 30011.
