The LEDs are multi-color to convey different types of status conditions as shown in the following chart:
LED Name
PWR
(DC Power)
RADIO-1
(master)
(remote)
(all)
RADIO-2
(if equipped)

2.4 Grounding Considerations

To minimize the chance of damage to the unit and its connected equipment, a safety ground (NEC Class 2
compliant) is recommended, which bonds the chassis, antenna system(s), power supply and connected
data equipment to a single-point ground, keeping all ground leads as short as possible.
Normally, the unit is adequately grounded if mounted with the flat brackets to a well-grounded metal
surface. If the unit is not mounted to a grounded surface, it is recommended that a safety ground wire be
attached to the screw provided on the bottom corner of the enclosure, in the recessed flat area.
Alternatively, a safety ground wire may be attached to one of the mounting bracket screws.
The use of a lightning protector is recommended where the antenna cable enters the building; Bond the
protector to the tower ground, if possible. All grounds and cabling must comply with applicable codes
and regulations. One source for lightning protection products may be found online at
http://www.protectiongroup.com/PolyPhaser.

2.5 Mounting Options

The unit may be mounted with flat mounting brackets or an optional 35 mm DIN rail attachment.
MDS 05-7280A01, Rev. A
Table 2-4. Description of LED Status Indicators
LED State
Off
Solid Green
Flashing Red
(0.5s ON/ 0.5s OFF)
Flashing Green
(0.5s ON/ 0.5s OFF)
Fast Alternating
(Red/Yellow/Green)
Off
Solid Green + flicker
Solid Color + flicker on data
[Color based on RSSI]
Green:
Yellow:
Violet:
Red:
Flashing Red
(1.0s ON/1.0s OFF)
Multi-Color (rotating)
(1.0s ON per color)
Off
MDS TransNEXT Technical Manual
Description
No power to unit.
Unit is powered, no problems detected.
Alarm indication.
Unit is being programmed.
Unit is booting up.
Interface disabled.
Radio-1 will flicker on data.
Radio-1 is synchronized to a master.
LED will flicker on data.
RSSI >= -70 dBm
-70 dBm < RSSI <= -85 dBm
-85 dBm < RSSI <= -100 dBm
RSSI < -100 dBm
Remote radio is not synchronized.
Radio is in setup mode.
Interface disabled.
