  • Page 1 R I L L O D U L E NSTALLATION NSTRUCTIONS...
  • Page 2 800-332-9513 Website: wolfappliance.com ® WOLF is a registered trademark of Wolf Appliance Company, LLC As you follow these instructions, you will notice WARNING and CAUTION symbols. This blocked information is important for the safe and efficient installation of Wolf equip- ment.
  • Page 3 IMPORTANT NOTE: Installation and service must be performed by a qualified installer or service agency. Warranty service must be performed by a Wolf authorized service center. Installation of the grill module must meet the minimum clearance requirements for safe operation. Refer to Site Preparation on page 4.
  • Page 4 G R I L L M O D U L E S I T E P R E P A R A T I O N IMPORTANT NOTE: Installation of the Wolf electric grill module must meet the following location requirements. All dimensions listed are minimum requirements for safe operation.
  • Page 5 S P E C I F I C A T I O N S The illustrations below provide the overall dimensions, finished cut-out dimensions and electrical placement for the Wolf electric grill module. The grill module is designed to fit a standard 24"...
  • Page 6 G R I L L M O D U L E M U LT I P L E C O O K TO P IMPORTANT NOTE: If the grill module is to be used with a combination of additional cooktop...
  • Page 7 V E N T I L AT I O N O P T I O N S IMPORTANT NOTE: It is recommended that you operate the Wolf electric grill module with either a Wolf cooktop or Pro ventilation hood or hood liner. Contact your Wolf dealer for details.
  • Page 8 Maximum Connected Load 2.8 kW at 240 V AC 2.1 kW at 208 V AC The Wolf electric grill module requires a separate, grounded 3-wire 240/208 V AC, 60 Hz, 15 amp service with its own circuit breaker. The module is provided with a 4' (1.2 m) flexible 3-wire conduit that makes a connection to a junction box.
  • Page 9 Foam strip B E F O R E O P E R A T I N G Read the entire Wolf Grill Module Use & Care Information included with the module. Impor- tant safety, service and warranty information is contained within the book.
  • Page 10 M O D U L E R E M OVA L IMPORTANT NOTE: Removal of the grill module should only be performed by a Wolf authorized service center technician. If removing the grill module is necessary for cleaning or service, first disconnect the electric supply.
  • Page 11 Neither this book nor any information or images contained herein may be copied or used in whole or in part without the express written permission of Wolf Appliance Company, LLC, an affiliate of Sub-Zero Freezer Company, Inc. ©Wolf Appliance Company, LLC all rights reserved.
  • Page 12 W O L F A P P L I A N C E C O M PA N Y, L L C P. O. B OX 4 4 8 4 8 M A D I S O N , W I 5 3 7 4 4 8 0 0 - 3 3 2 - 9 5 1 3 W O L FA P P L I A N C E .
