- Page 1 TOP EVO TOP 291E(R)(/S) Linear hydraulic operator TOP 391E(R)(/S) INSTRUCTIONS FOR INSTALLATION TOP 441E(R)(/S)
-
Page 2: Technical Drawings
TOP EVO TECHNICAL DRAWINGS TOP291E(R)(/S) TOP 391E - TOP 441E(R)(/S) 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 Time (h) Time (h) - Page 3 TOP EVO BAC Limit Electric lock 291E(R)(/S) 391E(R)(/S) 441E(R)(/S) TOP291E(R)(/S) TOP391E(R)(/S) TOP441E(R)(/S) Leaf weight (Kg) TOP291E TOP291ER - TOP291ER/S TOP391E TOP391ER - TOP391ER/S TOP441E 1265 TOP441ER - TOP441ER/S 1250...
- Page 4 TOP EVO β TOP 291E 90° TOP 291E 110° TOP 291ER-ER/S 90° TOP 291ER-ER/S 105° >55 >80 TOP 391E 90° TOP 391E 110° TOP 391ER-ER/S 90° TOP 391ER-ER/S 105° TOP 441E 90° 1243 TOP 441E 110° 1243 >65 >100 TOP 441ER-ER/S 90°...
- Page 5 TOP EVO 20 mm 100/120...
- Page 6 TOP EVO BROWN GREY BLACK YELLOW-GREEN BROWN OPENING GREY BLACK CLOSING YELLOW-GREEN...
- Page 7 TOP EVO...
- Page 8 TOP EVO PRESSURE ADJUST CLOSE OPEN...
- Page 9 TOP EVO...
- Page 10 TOP EVO Thank you for choosing GI.BI.DI. READ CAREFULLY THESE INSTRUCTIONS BEFORE PROCEEDING WITH INSTALLATION. WARNINGS: This product has been tested by GI.BI.DI. for full compliance with the requirements of the directives in force. GI.BI.DI. S.r.l. reserves the right to change the technical data without prior notice in relation to product development.
-
Page 11: Installation Warnings
TOP EVO INTRODUCTION TOP EVO operator allows the automation of swinging gates. The automation is composed by an operator with arm, that transmits the movement to the leaf, and by a built-in hydraulic control unit. TOP EVO operators are interchangeable with previous TOP versions, see chapter 8. INSTALLATION WARNINGS •... -
Page 12: Warnings For The User
TOP EVO WARNINGS FOR THE USER In the event of an operating fault or failure, cut the power upstream of the control unit and call Technical Service. Periodically check the good functioning of the safety devices. Any repair must be carried out by specialised personnel using original and certified materials. The product must not be used by children and persons with reduces physical, sensorial or mental capacities, or without experience and knowledge. - Page 13 Hydraulic slowdown Rod speed 10 mm/s 20 mm/s Rod maximum stroke 290 mm 265 mm Hydraulic oil GBD PH-03 Operating temperature from -20°C to +60°C Thermal protection 100°C Leaf maximum lenght 3.5 m 2c Hydraulic lock granted for leaf 2.0 m...
-
Page 14: Technical Data
Hydraulic slowdown Rod speed 10 mm/s 20 mm/s Rod maximum stroke 290 mm 265 mm Hydraulic oil GBD PH-03 Operating temperature from -20°C to +60°C Thermal protection 100°C Leaf maximum lenght 4.5 m 2c Hydraulic lock granted for leaf 2.0 m... - Page 15 Hydraulic slowdown Rod speed 10 mm/s 20 mm/s Rod maximum stroke 440 mm 425 mm Hydraulic oil GBD PH-03 Operating temperature from -20°C to +60°C Thermal protection 100°C Leaf maximum lenght 6 m 2c Hydraulic lock granted for leaf 2.0 m...
-
Page 16: Application Diagram
TOP EVO 3 - MAXIMUM OPERATING CURVE The operating time based on the desired operating frequency can be derived from the graphs 2a and 2b . 4 - APPLICATION DIAGRAM The maximum leaf lenght related to the weight can be derived from the graph 2c . 5 - DIMENSIONS Refer to figure 6 PRELIMINARY WARNINGS... - Page 17 TOP EVO 7 END STOPS OF THE LEAVES ON THE GROUND For the correct operation of the actuator, use the end stops both in opening and closing. The end stops of the leaves must prevent the actuator rod from arriving to the limit switch and must be positioned so as to keep a stroke room of the rod of about 5-10 cm, in order to avoid any possible operation anomaly.
- Page 18 TOP EVO 10 OPERATOR INSTALLATION 1 - Check the fixing point most suitable for the front bracket of the operator [5] and mark it. 2 - Indicate the point on the pillar with a spirit level to fix the rear bracket [5]. 3 - Find the fixing point of the rear bracket in function of quotas A-B [4].
- Page 19 TOP EVO 11 MANUAL MANOEUVRE (UNLOCKING DEVICE) Unlocking device with hexagonal key [11]: Turn the cover À and lift it, turn the unlocking key Á anti-clockwise by 2 turns and carry out the manual manoeuvre. To reset turn the key Á clockwise until it stops without forcing it, replace the cover into its original position. Unlocking device with personalised key [12]: Push the cover Â...
- Page 20 TOP EVO 14 ELECTROLOCK MOUNTING [14a] [14b] Refers to pictures . The electrolock must be installed on leaves longer than 2.5 m. À Electrolock. Á Electrolock fixing plate. Â Bolt hooker. Ã Bolt hooking rabbet. Ä Bolt. Å Key cylinder (on request). Æ...
- Page 21 TOP EVO EU Declaration of conformity GI.BI.DI. S.r.l. The manufacturer: Via Abetone Brennero, 177/B, 46025 Poggio Rusco (MN) ITALY declares that the products: HYDRAULIC OPERATORS TOP 291E(R)(/S)-391E(R)(/S)-441E(R)(/S) are in conformity with the following Directives: •2014/30/UE; •2014/35/UE; and that the following harmonised standards have been applied: •EN 61000-6-2:2005;...
- Page 22 TOP EVO NOTE / NOTES / NOTES / NOTAS...
- Page 23 TOP EVO NOTE / NOTES / NOTES / NOTAS...
- Page 24 GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B 46025 Poggio Rusco (MN) - ITALY Tel. +39.0386.52.20.11 Fax +39.0386.52.20.31 E-mail: info@gibidi.com Numero Verde: 800.290156 w w w . g i b i d i . c o m...
