GENOA2D24G-2L+
User Manual
Version 1.0
Published March 2023
Copyright©2023 ASRock Rack INC. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GENOA2D24G-2L+ and is the answer not in the manual?

Questions and answers

Related Manuals for ASROCK GENOA2D24G-2L+

Summary of Contents for ASROCK GENOA2D24G-2L+

  • Page 1 GENOA2D24G-2L+ User Manual Version 1.0 Published March 2023 Copyright©2023 ASRock Rack INC. All rights reserved.
  • Page 2 (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 ASRock Rack follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock Rack product is in line with global environmental regulations. In addition, ASRock Rack disclose the relevant in- formation based on regulation requirements.

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Unique Features Motherboard Layout Onboard LED Indicators I/O Panel Block Diagram Chapter 2 Installation Screw Holes Pre-installation Precautions Installing the CPU Installation of Memory Modules (DIMM) Jumper Setup Onboard Headers and Connectors ATX PSU Power Connections Dr.
  • Page 5 3.1.2 Navigation Keys Main Screen 3.2.1 Mother Board Information 3.2.2 Processor Information 3.2.3 Memory Information Advanced Screen 3.3.1 CPU Configuration 3.3.2 Chipset Configuration 3.3.3 Storage Configuration 3.3.4 NVMe Configuration 3.3.5 ACPI Configuration 3.3.6 USB Configuration 3.3.7 Super IO Configuration 3.3.8 Serial Port Console Redirection 3.3.9 H/W Monitor 3.3.10 PCI Subsystem Settings 3.3.11 AMD CBS...
  • Page 6 3.4.1 Key Management Server Mgmt 3.5.1 BMC Network Configuration 3.5.2 System Event Log 3.5.3 BMC Tools Event Logs Boot Screen Exit Screen Chapter 4 Software Support Download and Install Operating System Download and Install Software Drivers Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures Technical Support Procedures Returning Merchandise for Service...

  • Page 7: Chapter 1 Introduction

    In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. Find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com For any technical supports, please visit the website for specific information about the using model.

  • Page 8: Specifications

    1.2 Specifications GENOA2D24G-2L+ Physical Status Form Factor Proprietary Dimension 16.9" x13.8" Processor System Supports AMD EPYC™ 9004 (with AMD 3D V-Cache™ Technology) and 97x4 series processors Socket Dual Socket SP5 (LGA 6096) Thermal Design 450-500W Power (TDP) Chipset System on Chip System Memory Supported DIMM 12+12 DIMM slots (1DPC)
  • Page 9 System BIOS Type AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM Features ASRock Rack Instant Flash, ACPI 6.4 and about compliance wake up events, SMBIOS 3.5.0 and above, Plug and Play(PnP) Internal Connectors/Headers PSU Connector 6 Micro-Hi (8-pin, ATX 12V), 1 Micro-Fit (4-pin, ATX PSU...
  • Page 10 HSBP SMbus Header PMbus Header IPMB Header Clear CMOS 1 (contact pads) USB 3.2 (Gen1) 2 (19-pin, 2 USB3.2 Gen1) Header LED Indicators Standby Power LED 1 (5VSB) 80 Debug Port LED Fan Fail LED BMC Heartbeat LED 1 Support OS Microsoft®...

  • Page 11: Unique Features

    . With this utility, press the <F6> key during the POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to the USB flash drive, floppy disk or hard drive, then updating the BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 12: Motherboard Layout

    1.4 Motherboard Layout 35.1 cm (13.8 in) DDR5_R1 PSU_SMB1 12VCON1 12VCON2 12VCON3 DDR5_Q1 BMC_SMB1 ATX4PIN1 DDR5_P1 FAN6 MCIO17 BMC_SMB2 DDR5_O1 CASEOPEN1 FAN5 DDR5_N1 BMC_SMB3 BMC_SMB4 MCIO20 MCIO18 DDR5_M1 USB3_7_8 MCIO19 USB3.2 Gen1 Ports FAN4 (USB3_1_2) COM1 USB3.2 Gen1 Ports (USB3_3_4) CPU1 ASPEED AST2600...
  • Page 13 GENOA2D24G-2L+ Description PSU SMBus Header (PSU_SMB1) ATX 12V Power Connector (12VCON1) Micro-Fit Power Connector (ATX4PIN1) ATX 12V Power Connector (12VCON2) Chassis Intrusion Header (CASEOPEN1) ATX 12V Power Connector (12VCON3) System Fan Connector (FAN4) Mini Cool Edge IO Connector (MCIO19) Mini Cool Edge IO Connector (MCIO20) 3 x 288-pin DDR5 DIMM Slots (DDR5_N1, DDR5_P1, DDR5_R1)* 3 x 288-pin DDR5 DIMM Slots (DDR5_M1, DDR5_O1, DDR5_Q1)* Mini Cool Edge IO Connector (MCIO17)
  • Page 14 Description Mini Cool Edge IO Connector (MCIO2) 3 x 288-pin DDR5 DIMM Slots (DDR5_H1, DDR5_J1, DDR5_L1)* Mini Cool Edge IO Connector (MCIO10) Mini Cool Edge IO Connector (MCIO9) System Fan Connector (FAN3) ATX 12V Power Connector (12VCON6) ATX 12V Power Connector (12VCON5) USB 3.2 Gen1 Header (USB3_5_6) ATX 12V Power Connector (12VCON4) System Power Connector (BP_PWR1)
  • Page 15 GENOA2D24G-2L+ Description NCSI Header (NCSI1) Front VGA Header (FRNT_VGA1) COM Port Header (COM1) USB 3.2 Gen1 Header (USB3_7_8) BMC SMBus Header (BMC_SMB4) BMC SMBus Header (BMC_SMB3) System Fan Connector (FAN5) BMC SMBus Header (BMC_SMB2) System Fan Connector (FAN6) BMC SMBus Header (BMC_SMB1) * For DIMM installation and configuration instructions, please see p.20 (Installation of Memory Modules (DIMM)) for more details.

  • Page 16: Onboard Led Indicators

    1.5 Onboard LED Indicators Item Status Description LED_FAN3 FAN3 failed SB_PWR1 Green STB PWR ready LED_FAN1 FAN1 failed LED_FAN2 FAN2 failed BMC_LED1 Green BMC heartbeat LED LED_FAN4 FAN4 failed LED_FAN5 FAN5 failed LED_FAN6 FAN6 failed...

  • Page 17: I/O Panel

    GENOA2D24G-2L+ 1.6 I/O Panel No. Description No. Description USB 3.2 Gen1 Ports (USB3_1_2) NMI Button (NMI_BTN) USB 3.2 Gen1 Ports (USB3_3_4) HDD/System Fault LED (HDD_SYS_LED) VGA Header (VGA1) IPMI LAN Header (IPMI_LAN1)* UID Switch (UID1) 1G LAN RJ-45 Port (LAN1, shared NIC)** Power Switch/LED (PWR_BTN1) 11 1G LAN RJ-45 Port (LAN2)** Reset Button (RST_BTN)
  • Page 18 **There is an LED on each side of 1G LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port 1G LAN Port (LAN1, LAN2) LED Indications Activity / Link LED Speed LED Status Description...

  • Page 19: Block Diagram

    GENOA2D24G-2L+ 1.7 Block Diagram...

  • Page 20: Chapter 2 Installation

    Chapter 2 Installation This is a Proprietary form factor (18.93” x13.78”) motherboard. Before installing the motherboard, study the configuration of the chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries and motherboard damages.

  • Page 21: Installing The Cpu

    GENOA2D24G-2L+ 2.3 Installing the CPU 1. Before inserting the CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 23 GENOA2D24G-2L+ Carr ier Frame with CPU Rail Frame Please make sure that the carrier frame with CPU is closely attached to the rail frame while inserting it. Install the carrier frame with CPU. Don’t separate them.
  • Page 25 GENOA2D24G-2L+ Set your torque wrench to 1.54 in-lb. One fourth a turn each time. Tighten the screws in a sequential order 1 > 2 > 3 > 4 > 5 > 6. Loosen the screws in a reverse order. 10-4 10-2 10-5 10-6...

  • Page 26: Installation Of Memory Modules (Dimm)

    2.4 Installation of Memory Modules (DIMM) This motherboard provides twenty-four 288-pin DDR5 (Double Data Rate 5) DIMM slots in two groups, and supports Single Channel Memory Technology. CPU1 CPU0 DDR5_M1, N1, O1, P1, Q1, R1 DDR5_A1, B1, C1, D1, E1, F1 DDR5_S1, T1, U1, V1, W1, X1 DDR5_G1, H1, I1, J1, K1, L1 1.
  • Page 27 GENOA2D24G-2L+ Recommended Memory Configurations...

  • Page 28: Jumper Setup

    2.5 Jumper Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins.

  • Page 29: Onboard Headers And Connectors

    GENOA2D24G-2L+ 2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header Connect the power switch, PLED+ PLED-...
  • Page 30 Auxiliary Panel Connector This header supports multiple (18-pin AUX_PANEL1) functions on the front panel, (see p.6, No. 48) including front panel SMB, internet status indicator. A. Front panel SMBus connecting pin (6-1 pin FPSMB) This header allows user to connect SMBus (System Management Bus) equipment. It can be used for communication between peripheral equipment in the system, which has slower transmission rates, and power management equipment.
  • Page 31 GENOA2D24G-2L+ USB 3.2 Gen1 Headers Besides four default USB 3.2 IntA_PA_D+ IntA_PA_D- (19-pin USB3_5_6) Gen1 ports on the I/O panel, IntA_PA_SSTX+ (see p.6, No. 42) IntA_PA_SSTX- there are two USB 3.2 Gen1 (19-pin USB3_7_8) IntA_PA_SSRX+ headers on this motherboard. IntA_PA_SSRX- Vbus (see p.6, No.
  • Page 32 Serial General Purpose These headers support Serial SCLOCK SLOAD Input/Output Headers Link interface for onboard (7-pin SATA_SGPIO1) SATA connections. (see p.6, No. 45) (7-pin SATA_SGPIO2) (see p.6, No. 57) SDATAOUT (7-pin SATA_SGPIO3) (see p.6, No. 51) (7-pin SATA_SGPIO4) (see p.6, No. 54) (7-pin SATA_SGPIO5) (see p.6, No.
  • Page 33 GENOA2D24G-2L+ Liquid Crystal Module This header is used for LCM_RX LCM_TX Header extended Liquid Crystal +5VSB (4-pin LCM1) Module(LCM) on the front (see p.6, No. 49) panel of a server system. System Fan Connectors Please connect fan cables to (6-pin FAN1) the fan connectors and match (see p.6, No.
  • Page 34 Micro-Fit ATX 4Pin The motherboard provides ATX_PWROK Power Connector one 4-pin power/signal (4-pin ATX4PIN1 (ATX ATX_+5VSB PSON# connector which is a required 24pin-to-4pin)) input for ATX power source. (see p.6, No. 3) When using ATX power, it is necessary to use a 24pin-to- 4pin power cable to connect between the 24pin power connector of PSU and the...
  • Page 35 GENOA2D24G-2L+ PSU SMBus PSU SMBus monitors the ALERT SMBCLK +3VSB (PSU_SMB1) status of the power supply, fan (see p.6, No. 1) and system temperature. SMBDATA Backplane PCI Express This header is used for the hot CPU_HP_SCL Hot-Plug Connector plug feature of HDDs on the CPU_HP_SDA (5-pin CPU_ HSBP1) backplane.
  • Page 36 MCIO Connectors These connectors are used for (MCIO1) the PCIE or SATA devices. (see p.6, No. 34) * MCIO9, 10 support PCIe only while installing 2 processors (MCIO2) (see p.6, No. 35) (MCIO9) (see p.6, No. 38) (MCIO10) (see p.6, No. 37) (MCIO17) (see p.6, No.
  • Page 37 GENOA2D24G-2L+ MCIO1 Pin Definition (CPU0 P2 [7:0]) Defeinition Pin Defeinition RX_DP7 TX_DP7 RX_DN7 TX_DN7 RX_DP6 TX_DP6 RX_DN6 TX_DN6 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP5 TX_DP5 RX_DN5 TX_DN5 RX_DP4 TX_DP4 RX_DN4 TX_DN4 RX_DP3 TX_DP3 RX_DN3 TX_DN3 RX_DP2 TX_DP2 RX_DN2 TX_DN2 BP_TYPE SCL2 WAKE#...
  • Page 38 MCIO2 Pin Definition (CPU0 P2 [15:8]) Defeinition Pin Defeinition RX_DP15 TX_DP15 RX_DN15 TX_DN15 RX_DP14 TX_DP14 RX_DN14 TX_DN14 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP13 TX_DP13 RX_DN13 TX_DN13 RX_DP12 TX_DP12 RX_DN12 TX_DN12 RX_DP11 TX_DP11 RX_DN11 TX_DN11 RX_DP10 TX_DP10 RX_DN10 TX_DN10 BP_TYPE SCL2 WAKE# SDA2...
  • Page 39 GENOA2D24G-2L+ MCIO3 Pin Definition (CPU0 P3 [7:0]) Defeinition Pin Defeinition RX_DP7 TX_DP7 RX_DN7 TX_DN7 RX_DP6 TX_DP6 RX_DN6 TX_DN6 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP5 TX_DP5 RX_DN5 TX_DN5 RX_DP4 TX_DP4 RX_DN4 TX_DN4 RX_DP3 TX_DP3 RX_DN3 TX_DN3 RX_DP2 TX_DP2 RX_DN2 TX_DN2 BP_TYPE SCL2 WAKE#...
  • Page 40 MCIO4 Pin Definition (CPU0 P3 [15:8]) Defeinition Pin Defeinition RX_DP15 TX_DP15 RX_DN15 TX_DN15 RX_DP14 TX_DP14 RX_DN14 TX_DN14 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP13 TX_DP13 RX_DN13 TX_DN13 RX_DP12 TX_DP12 RX_DN12 TX_DN12 RX_DP11 TX_DP11 RX_DN11 TX_DN11 RX_DP10 TX_DP10 RX_DN10 TX_DN10 BP_TYPE SCL2 WAKE# SDA2...
  • Page 41 GENOA2D24G-2L+ MCIO5 Pin Definition (CPU0 P1 [7:0]) Defeinition Pin Defeinition RX_DP7 TX_DP7 RX_DN7 TX_DN7 RX_DP6 TX_DP6 RX_DN6 TX_DN6 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP5 TX_DP5 RX_DN5 TX_DN5 RX_DP4 TX_DP4 RX_DN4 TX_DN4 RX_DP3 TX_DP3 RX_DN3 TX_DN3 RX_DP2 TX_DP2 RX_DN2 TX_DN2 BP_TYPE SCL2 WAKE#...
  • Page 42 MCIO6 Pin Definition (CPU0 P1 [15:8]) Defeinition Pin Defeinition RX_DP15 TX_DP15 RX_DN15 TX_DN15 RX_DP14 TX_DP14 RX_DN14 TX_DN14 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP13 TX_DP13 RX_DN13 TX_DN13 RX_DP12 TX_DP12 RX_DN12 TX_DN12 RX_DP11 TX_DP11 RX_DN11 TX_DN11 RX_DP10 TX_DP10 RX_DN10 TX_DN10 BP_TYPE SCL2 WAKE# SDA2...
  • Page 43 GENOA2D24G-2L+ MCIO7 Pin Definition (CPU0 P0 [7:0]) Defeinition Pin Defeinition RX_DP7 TX_DP7 RX_DN7 TX_DN7 RX_DP6 TX_DP6 RX_DN6 TX_DN6 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP5 TX_DP5 RX_DN5 TX_DN5 RX_DP4 TX_DP4 RX_DN4 TX_DN4 RX_DP3 TX_DP3 RX_DN3 TX_DN3 RX_DP2 TX_DP2 RX_DN2 TX_DN2 BP_TYPE SCL2 WAKE#...
  • Page 44 MCIO8 Pin Definition (CPU0 P0 [15:8]) Defeinition Pin Defeinition RX_DP15 TX_DP15 RX_DN15 TX_DN15 RX_DP14 TX_DP14 RX_DN14 TX_DN14 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP13 TX_DP13 RX_DN13 TX_DN13 RX_DP12 TX_DP12 RX_DN12 TX_DN12 RX_DP11 TX_DP11 RX_DN11 TX_DN11 RX_DP10 TX_DP10 RX_DN10 TX_DN10 BP_TYPE SCL2 WAKE# SDA2...
  • Page 45 GENOA2D24G-2L+ MCIO9 Pin Definition (CPU0 G3 [7:0]) Defeinition Pin Defeinition RX_DP7 TX_DP7 RX_DN7 TX_DN7 RX_DP6 TX_DP6 RX_DN6 TX_DN6 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP5 TX_DP5 RX_DN5 TX_DN5 RX_DP4 TX_DP4 RX_DN4 TX_DN4 RX_DP3 TX_DP3 RX_DN3 TX_DN3 RX_DP2 TX_DP2 RX_DN2 TX_DN2 BP_TYPE SCL2 WAKE#...
  • Page 46 MCIO10 Pin Definition (CPU0 G3 [15:8]) Defeinition Pin Defeinition RX_DP15 TX_DP15 RX_DN15 TX_DN15 RX_DP14 TX_DP14 RX_DN14 TX_DN14 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP13 TX_DP13 RX_DN13 TX_DN13 RX_DP12 TX_DP12 RX_DN12 TX_DN12 RX_DP11 TX_DP11 RX_DN11 TX_DN11 RX_DP10 TX_DP10 RX_DN10 TX_DN10 BP_TYPE SCL2 WAKE# SDA2...
  • Page 47 GENOA2D24G-2L+ MCIO11 Pin Definition (CPU1 P2 [7:0]) Defeinition Pin Defeinition RX_DP7 TX_DP7 RX_DN7 TX_DN7 RX_DP6 TX_DP6 RX_DN6 TX_DN6 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP5 TX_DP5 RX_DN5 TX_DN5 RX_DP4 TX_DP4 RX_DN4 TX_DN4 RX_DP3 TX_DP3 RX_DN3 TX_DN3 RX_DP2 TX_DP2 RX_DN2 TX_DN2 BP_TYPE SCL2 WAKE#...
  • Page 48 MCIO12 Pin Definition (CPU1 P2 [15:8]) Defeinition Pin Defeinition RX_DP15 TX_DP15 RX_DN15 TX_DN15 RX_DP14 TX_DP14 RX_DN14 TX_DN14 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP13 TX_DP13 RX_DN13 TX_DN13 RX_DP12 TX_DP12 RX_DN12 TX_DN12 RX_DP11 TX_DP11 RX_DN11 TX_DN11 RX_DP10 TX_DP10 RX_DN10 TX_DN10 BP_TYPE SCL2 WAKE# SDA2...
  • Page 49 GENOA2D24G-2L+ MCIO13 Pin Definition (CPU1 P3 [7:0]) Defeinition Pin Defeinition RX_DP7 TX_DP7 RX_DN7 TX_DN7 RX_DP6 TX_DP6 RX_DN6 TX_DN6 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP5 TX_DP5 RX_DN5 TX_DN5 RX_DP4 TX_DP4 RX_DN4 TX_DN4 RX_DP3 TX_DP3 RX_DN3 TX_DN3 RX_DP2 TX_DP2 RX_DN2 TX_DN2 BP_TYPE SCL2 WAKE#...
  • Page 50 MCIO14 Pin Definition (CPU1 P3 [15:8]) Defeinition Pin Defeinition RX_DP15 TX_DP15 RX_DN15 TX_DN15 RX_DP14 TX_DP14 RX_DN14 TX_DN14 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP13 TX_DP13 RX_DN13 TX_DN13 RX_DP12 TX_DP12 RX_DN12 TX_DN12 RX_DP11 TX_DP11 RX_DN11 TX_DN11 RX_DP10 TX_DP10 RX_DN10 TX_DN10 BP_TYPE SCL2 WAKE# SDA2...
  • Page 51 GENOA2D24G-2L+ MCIO15 Pin Definition (CPU1 P1 [7:0]) Defeinition Pin Defeinition RX_DP7 TX_DP7 RX_DN7 TX_DN7 RX_DP6 TX_DP6 RX_DN6 TX_DN6 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP5 TX_DP5 RX_DN5 TX_DN5 RX_DP4 TX_DP4 RX_DN4 TX_DN4 RX_DP3 TX_DP3 RX_DN3 TX_DN3 RX_DP2 TX_DP2 RX_DN2 TX_DN2 BP_TYPE SCL2 WAKE#...
  • Page 52 MCIO16 Pin Definition (CPU1 P1 [15:8]) Defeinition Pin Defeinition RX_DP15 TX_DP15 RX_DN15 TX_DN15 RX_DP14 TX_DP14 RX_DN14 TX_DN14 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP13 TX_DP13 RX_DN13 TX_DN13 RX_DP12 TX_DP12 RX_DN12 TX_DN12 RX_DP11 TX_DP11 RX_DN11 TX_DN11 RX_DP10 TX_DP10 RX_DN10 TX_DN10 BP_TYPE SCL2 WAKE# SDA2...
  • Page 53 GENOA2D24G-2L+ MCIO17 Pin Definition (CPU1 P0 [7:0]) Defeinition Pin Defeinition RX_DP7 TX_DP7 RX_DN7 TX_DN7 RX_DP6 TX_DP6 RX_DN6 TX_DN6 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP5 TX_DP5 RX_DN5 TX_DN5 RX_DP4 TX_DP4 RX_DN4 TX_DN4 RX_DP3 TX_DP3 RX_DN3 TX_DN3 RX_DP2 TX_DP2 RX_DN2 TX_DN2 BP_TYPE SCL2 WAKE#...
  • Page 54 MCIO18 Pin Definition (CPU1 P0[15:8]) Defeinition Pin Defeinition RX_DP15 TX_DP15 RX_DN15 TX_DN15 RX_DP14 TX_DP14 RX_DN14 TX_DN14 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP13 TX_DP13 RX_DN13 TX_DN13 RX_DP12 TX_DP12 RX_DN12 TX_DN12 RX_DP11 TX_DP11 RX_DN11 TX_DN11 RX_DP10 TX_DP10 RX_DN10 TX_DN10 BP_TYPE SCL2 WAKE# SDA2 PERST_BUF2_N...
  • Page 55 GENOA2D24G-2L+ MCIO19 Pin Definition (CPU1 G1 [7:0]) Defeinition Pin Defeinition RX_DP7 TX_DN7 RX_DN7 TX_DP7 RX_DP6 TX_DN6 RX_DN6 TX_DP6 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP5 TX_DN5 RX_DN5 TX_DP5 RX_DP4 TX_DN4 RX_DN4 TX_DP4 RX_DP3 TX_DN3 RX_DN3 TX_DP3 RX_DP2 TX_DN2 RX_DN2 TX_DP2 BP_TYPE SCL2 WAKE#...
  • Page 56 MCIO20 Pin Definition (CPU1 G1[15:8]) Defeinition Pin Defeinition RX_DP15 TX_DN15 RX_DN15 TX_DP15 RX_DP14 TX_DN14 RX_DN14 TX_DP14 BP_TYPE SCL1 WAKE# SDA1 PERST_BUF1_N PRSNT_N RX_DP13 TX_DN13 RX_DN13 TX_DP13 RX_DP12 TX_DN12 RX_DN12 TX_DP12 RX_DP11 TX_DN11 RX_DN11 TX_DP11 RX_DP10 TX_DN10 RX_DN10 TX_DP10 BP_TYPE SCL2 WAKE# SDA2 PERST_BUF2_N...

  • Page 57: Atx Psu Power Connections

    GENOA2D24G-2L+ 2.7 ATX PSU Power Connections This motherboard support ATX power input. Please refer to the table below for the required connections between the motherboard and the power supply. ATX PSU DC-IN (via a 24pin-to-4pin Converter Cable) 12V 8pin 12V 8pin ATX 4pin The following diagram illustrates how to connect the bundled ATX 24pin-to-4pin converter cable.

  • Page 58: Dr. Debug

    2.8 Dr. Debug Dr. Debug is used to provide code information, which makes troubleshooting even easier. Please see the diagrams below for reading the Dr. Debug codes. Code Description 0x10 PEI_CORE_STARTED 0x11 PEI_CAR_CPU_INIT 0x15 PEI_CAR_NB_INIT 0x19 PEI_CAR_SB_INIT 0x31 PEI_MEMORY_INSTALLED 0x32 PEI_CPU_INIT 0x33 PEI_CPU_CACHE_INIT...
  • Page 59 GENOA2D24G-2L+ 0x63 DXE_CPU_INIT 0x68 DXE_NB_HB_INIT 0x69 DXE_NB_INIT 0x6A DXE_NB_SMM_INIT 0x70 DXE_SB_INIT 0x71 DXE_SB_SMM_INIT 0x72 DXE_SB_DEVICES_INIT 0x78 DXE_ACPI_INIT 0x79 DXE_CSM_INIT 0x90 DXE_BDS_STARTED 0x91 DXE_BDS_CONNECT_DRIVERS 0x92 DXE_PCI_BUS_BEGIN 0x93 DXE_PCI_BUS_HPC_INIT 0x94 DXE_PCI_BUS_ENUM 0x95 DXE_PCI_BUS_REQUEST_RESOURCES 0x96 DXE_PCI_BUS_ASSIGN_RESOURCES 0x97 DXE_CON_OUT_CONNECT 0x98 DXE_CON_IN_CONNECT...
  • Page 60 0x99 DXE_SIO_INIT 0x9A DXE_USB_BEGIN 0x9B DXE_USB_RESET 0x9C DXE_USB_DETECT 0x9D DXE_USB_ENABLE 0xA0 DXE_IDE_BEGIN 0xA1 DXE_IDE_RESET 0xA2 DXE_IDE_DETECT 0xA3 DXE_IDE_ENABLE 0xA4 DXE_SCSI_BEGIN 0xA5 DXE_SCSI_RESET 0xA6 DXE_SCSI_DETECT 0xA7 DXE_SCSI_ENABLE 0xA8 DXE_SETUP_VERIFYING_PASSWORD 0xA9 DXE_SETUP_START 0xAB DXE_SETUP_INPUT_WAIT 0xAD DXE_READY_TO_BOOT 0xAE DXE_LEGACY_BOOT...
  • Page 61 GENOA2D24G-2L+ 0xAF DXE_EXIT_BOOT_SERVICES 0xB0 RT_SET_VIRTUAL_ADDRESS_MAP_BEGIN 0xB1 RT_SET_VIRTUAL_ADDRESS_MAP_END 0xB2 DXE_LEGACY_OPROM_INIT 0xB3 DXE_RESET_SYSTEM 0xB4 DXE_USB_HOTPLUG 0xB5 DXE_PCI_BUS_HOTPLUG 0xB6 DXE_NVRAM_CLEANUP 0xB7 DXE_CONFIGURATION_RESET 0xF0 PEI_RECOVERY_AUTO 0xF1 PEI_RECOVERY_USER 0xF2 PEI_RECOVERY_STARTED 0xF3 PEI_RECOVERY_CAPSULE_FOUND 0xF4 PEI_RECOVERY_CAPSULE_LOADED 0xE0 PEI_S3_STARTED 0xE1 PEI_S3_BOOT_SCRIPT 0xE2 PEI_S3_VIDEO_REPOST...
  • Page 62 0xE3 PEI_S3_OS_WAKE 0x50 PEI_MEMORY_INVALID_TYPE 0x53 PEI_MEMORY_NOT_DETECTED 0x55 PEI_MEMORY_NOT_INSTALLED 0x57 PEI_CPU_MISMATCH 0x58 PEI_CPU_SELF_TEST_FAILED 0x59 PEI_CPU_NO_MICROCODE 0x5A PEI_CPU_ERROR 0x5B PEI_RESET_NOT_AVAILABLE 0xD0 DXE_CPU_ERROR 0xD1 DXE_NB_ERROR 0xD2 DXE_SB_ERROR 0xD3 DXE_ARCH_PROTOCOL_NOT_AVAILABLE 0xD4 DXE_PCI_BUS_OUT_OF_RESOURCES 0xD5 DXE_LEGACY_OPROM_NO_SPACE 0xD6 DXE_NO_CON_OUT 0xD7 DXE_NO_CON_IN...
  • Page 63 GENOA2D24G-2L+ 0xD8 DXE_INVALID_PASSWORD 0xD9 DXE_BOOT_OPTION_LOAD_ERROR 0xDA DXE_BOOT_OPTION_FAILED 0xDB DXE_FLASH_UPDATE_FAILED 0xDC DXE_RESET_NOT_AVAILABLE 0xE8 PEI_MEMORY_S3_RESUME_FAILED 0xE9 PEI_S3_RESUME_PPI_NOT_FOUND 0xEA PEI_S3_BOOT_SCRIPT_ERROR 0xEB PEI_S3_OS_WAKE_ERROR...

  • Page 64: Identification Purpose Led/Switch

    2.9 Identification purpose LED/Switch With the UID button, it is able to locate the server that is working on from behind a rack of servers. Unit Identification When the UID button on the purpose LED/Switch front or rear panel is pressed, (UID1) the front/rear UID blue LED indicator will be truned on.

  • Page 65: Dual Lan And Teaming Operation Guide

    GENOA2D24G-2L+ 2.10 Dual LAN and Teaming Operation Guide Dual LAN with Teaming enabled on this motherboard allows two single connections to act as one single connection(s) for twice the transmission bandwidth, making data transmission more effective and improving the quality of transmission of distant images. Fault tolerance on the dual LAN network prevents network downtime by transferring the workload from a failed port to a working port.

  • Page 66: Ssd Module Installation Guide

    2.11 M.2 SSD Module Installation Guide The M.2 Socket (M2_1/M2_2, Key M) supports either a M.2 SATA3.6.0 Gb/s module or a M.2 PCI Express moduel up to Gen3x4 (8Gb/s x4). Installing the M.2 SSD Module Step 1 Prepare a M.2 SSD module and the screw.
  • Page 67 GENOA2D24G-2L+ Step 3 Move the standoff based on the module type and length. Skip Step 3 and 4 and go straight to Step 5 if using the default nut. Otherwise, release the standoff by hand. Step 4 Peel off the yellow protective film on the nut to be used.

  • Page 68: Chapter 3 Uefi Setup Utility

    Chapter 3 UEFI Setup Utility 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure the system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. Run the UEFI SETUP UTILITY when starting up the computer. Please press <F2> or <Del> during the Power- On-Self-Test (POST) to enter the UEFI SETUP UTILITY;...

  • Page 69: Navigation Keys

    GENOA2D24G-2L+ 3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...

  • Page 70: Main Screen

    3.2 Main Screen Once entering the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The Main screen provides system overview information and allows user to set the system time and date.

  • Page 71: Mother Board Information

    GENOA2D24G-2L+ 3.2.1 Mother Board Information Press <Enter> to view the information of the motheboard. 3.2.2 Processor Information Press <Enter> to view the information of the processor.

  • Page 72: Memory Information

    3.2.3 Memory Information Press <Enter> to view the information of the memory.

  • Page 73: Advanced Screen

    GENOA2D24G-2L+ 3.3 Advanced Screen In this section, set the configurations for the following items: CPU Configuration, Chipset Configuration, Storage Configuration, NVMe Configuration, ACPI Configuration, USB Configuration, Super IO Configuration, Serial Port Console Redirection, H/W Monitor, PCI Subsystem Settings, AMD CBS, AMD PBS, PSP Firmware Versions, Network Stack Configuration, Driver Health, Tls Auth Configuration and Instant Flash.

  • Page 74: Cpu Configuration

    3.3.1 CPU Configuration SVM Mode Enable or disable CPU Virtualization. Node 0 Information View Information related to Node 0. Node 1 Information View Information related to Node 1.

  • Page 75: Chipset Configuration

    GENOA2D24G-2L+ 3.3.2 Chipset Configuration Onboard VGA Use this to enable or disable the Onboard VGA function. Onboard LAN Use this to enable or disable the Onboard LAN function. MCIO Mode Selection Select SATA or PCIE work in MCIO port. MCIO7/8/17/18 Mode Selection Select SATA or PCIE work in MCIO7/8/17/18 port.
  • Page 76 PCIE HotPlug Select this item to configure PCIE HotPlug globally. MCIO1/2/3/4/5/6/7/8/9/10/11/12/13/14/15/16/17/18/19/20 HotPlug Enable or disable MCIO1/2/3/4/5/6/7/8/9/10/11/12/13/14/15/16/17/18/19/20 HotPlug. PCIE ASPM Selec this item to configure the PCIE ASPM. PCI-E ASPM Support (Global) Select this item to disable ASPM Support in all PCIE root ports.

  • Page 77: Storage Configuration

    GENOA2D24G-2L+ 3.3.3 Storage Configuration SATA Hot Plug Use this item to enable or disable the SATA Hot Plug Function.

  • Page 78: Nvme Configuration

    3.3.4 NVMe Configuration The NVMe Configuration displays the NVMe Driver and Device information. Launch NVMe driver Use this item to enable or disable launch NVMe driver.

  • Page 79: Acpi Configuration

    GENOA2D24G-2L+ 3.3.5 ACPI Configuration PCIE Devices Power On Allow the system to be waked up by a PCIE device and enable wake on LAN. Ring-In Power On Allow the system to be waked up by onboard COM port modem Ring-In Signals. RTC Alarm Power On Allow the system to be waked up by real time clock alarm.

  • Page 80: Usb Configuration

    3.3.6 USB Configuration This displays the USB Controllers and USB Devices information.

  • Page 81: Super Io Configuration

    GENOA2D24G-2L+ 3.3.7 Super IO Configuration Serial Port 1 Configuration Use this item to set parameters of Serial Port 1 (COM1). Serial Port Use this item to enable or disable the Serial Port (COM). Change Settings Use this item to select an optimal setting for Super IO Device. SOL Configuration Use this item to set parameters of SOL.

  • Page 82: Serial Port Console Redirection

    3.3.8 Serial Port Console Redirection COM1 / SOL Console Redirection Use this item to enable or disable Console Redirection. If this item is set to enable allowing to select a COM Port to be used for Console Redirection. Console Redirection Settings Use this option to configure Console Redirection Settings, and specify how the computer and the host computer to which are connected exchange information.
  • Page 83 GENOA2D24G-2L+ Bits Per Second Use this item to select the serial port transmission speed. The speed used in the host computer and the client computer must be the same. Long or noisy lines may require lower transmission speed. The options include [9600], [19200], [38400], [57600] and [115200]. Data Bits Use this item to set the data transmission size.
  • Page 84 Out-of-Band Mgmt Port Microsof t Windows Emergency Management Services (EMS) allows for remote management of a Windows Server OS through a serial port. Terminal Type EMS Use this item to select the preferred terminal emulation type for out-of-band management. It is recommended to select [VT-UTF8]. Option Description VT100...

  • Page 85: H/W Monitor

    GENOA2D24G-2L+ 3.3.9 H/W Monitor In this section, it allows user to monitor the status of the hardware on the system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage.

  • Page 86: Pci Subsystem Settings

    3.3.10 PCI Subsystem Settings Re-Size BAR Support Enable or disable this item to Re-Size BAR supported upon the sysem has resizable BAR capable PCIe Devices. SR-IOV Support If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO Virtualization Support.

  • Page 87: Amd Cbs

    GENOA2D24G-2L+ 3.3.11 AMD CBS CPU Common Options Use this item to configure CPU Common options. DF Common Options Use this item to configure DF Common options. UMC Common Options Use this item to configure UMC Common options. NBIO Common Options Use this item to configure NBIO Common options.

  • Page 88: Amd Pbs

    3.3.12 AMD PBS Use this item to configure AMD CPM RAS related settings. RAS Periodic SMI Control Use this to enable or disable Periodic SMI for polling [MCA Threshold] error. SMI Threshold This limits the number of [MCA Threshold and Deferred Error SMI source] per a unit time.
  • Page 89 GENOA2D24G-2L+ PCIe UnCorr GHES Notify Type This specifies the notification type for PCIe uncorrected errors. PCIe Root Port Corr Err Mask Reg Use this to initialize the PCIe AER corrected error mask register of root port. PCIe Root Port UnCorr Err Mask Reg Use this to initialize the PCIe AER uncorrected error mask register of root port.

  • Page 90: Psp Firmware Versions

    3.3.13 PSP Firmware Versions The PSP Firmware Verions displays the version information of ABL, PSP BootLoader, SMU FW, SEV FW, PHY FW, MPIO FW, TF MPDMA FW, PM MPDMA FW, GMI FW, RIB FW, SEC FW, PMU FW, EMCR FW and uCode B0.

  • Page 91: Network Stack Configuration

    GENOA2D24G-2L+ 3.3.14 Network Stack Configuration Network Stack Use this item to enable or disable UEFI Network Stack. IPv4 PXE Support Use this to enable or disable IPv4 PXE boot support. If disabled, IPv4 PXE boot support will not be available. IPv4 HTTP Support Use this to enable or disable IPv4 HTTP boot support.
  • Page 92 Media detect count Number of times the presence of media will be checked. Use either +/- or numeric keys to set the value.

  • Page 93: Driver Health

    GENOA2D24G-2L+ 3.3.15 Driver Health Inter(R) PRO/1000 7.4.36 PCI-E Healthy Provides Health Status for the Drivers/Controllers.

  • Page 94: Tls Auth Configuration

    3.3.16 Tls Auth Configuration Server CA Configuration Press <Enter> to configure Server CA. Enroll Cert Press <Enter> to enroll cert. Delete Cert Press <Enter> to delete cert. Client Cert Configuration...

  • Page 95: Instant Flash

    GENOA2D24G-2L+ 3.3.17 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI up- datetool allows user to update system UEFI without entering operating systems first like MSDOS or Windows®. Just save the new UEFI file to the USB flash drive, floppy disk or hard drive and launch this tool, then update the UEFI only in a few clicks without prepar- ing an additional floppy diskette or other complicated flash utility.

  • Page 96: Security

    3.4 Security This section allows user to set or change the supervisor/user password for the system. For the user password item is allowed user to clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility.
  • Page 97 GENOA2D24G-2L+ Install Default Secure Boot Keys Please install default secure boot keys if it’s the first time to use secure boot. Clear Secure Boot Keys This force system to setup Mode-Clear all Secure Boot Variables. Change takes effect after reboot.

  • Page 98: Key Management

    3.4.1 Key Management In this section, expert users can modify Secure Boot Policy variables without full authenti- cation. Factory Key Provision Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode. Install Default Secure Boot Keys Please install default secure boot keys if it’s the first time to use secure boot.
  • Page 99 GENOA2D24G-2L+ Platform Key (PK) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, External, Mixed Key Exchange Keys (KEK) Enroll Factory Defaults or load certificates from a file: 1.
  • Page 100 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, External, Mixed Forbidden Signatures (dbx) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2.
  • Page 101 GENOA2D24G-2L+ b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, External, Mixed...

  • Page 102: Server Mgmt

    3.5 Server Mgmt Wait For BMC Wait For BMC response for specified time out. BMC starts at the same time when BIOS starts during AC power ON. It takes around 255 seconds to initialize Host to BMC interfaces. FRB-2 Timer Use this item to enable or disable FRB-2 timer (POST timer) FRB-2 Timer Timeout Use this to define the FRB-2 Time Expiration between 1 to 30 value.
  • Page 103 GENOA2D24G-2L+ OS Wtd Timer Policy Configure how the system should respond if the OS Boot Watchdog Timer expires. If the OS Boot Watchdog Timer is disabled, this item is not available. BMC Network Configuration Use this to configure BMC network parameters. System Event Log Press <Enter>...

  • Page 104: Bmc Network Configuration

    3.5.1 BMC Network Configuration Bonding Setting Select this item to enabled or disabled bonding. Please enable all lan channel first when want to enable bonding. Lan channel (Failover) Manual Setting IPMI LAN If [No] is selected, the IP address is assigned by DHCP. If using a static IP address, toggle to [Yes], and the changes take effect after the system reboots.
  • Page 105 GENOA2D24G-2L+ The default login information for the IPMI web interface is: Username: admin Password: admin For more instructions on how to set up remote control environment and use the IPMI man- agement platform, please refer to the IPMI Configuration User Guide or go to the Support website at: http://www.asrockrack.com/support/faq.asp VLAN Enable or disable Virtual Local Area Network.

  • Page 106: System Event Log

    3.5.2 System Event Log SEL Components Change this to enable or disable event logging for error/progress codes during boot. Erase SEL Use this to choose options for earsing SEL. When SEL is Full Use this to choose options for reactions to a full SEL. Log EFI Status Codes Use this item to disable the logging of EFI Status Codes or log only error code or only progress code or both.

  • Page 107: Bmc Tools

    GENOA2D24G-2L+ 3.5.3 BMC Tools KCS Control Select this KCS interface state after POST end. If [Enabled] us selected, the BMC will remain KCS interface after POST stage. If [Disabled] is selected, the BMC will disable KCS interface after POST stage Restore AC Power Loss This allows user to set the power state after an unexpected AC/power loss.

  • Page 108: Event Logs

    3.6 Event Logs Change Smbios Event Log Settings Use this item to configure the Smbios Event Log Settings. When entering the item, the screen displays following sub-items: Smbios Event Log Use this item to enable or disable all features of the SMBIOS Event Logging during system boot.
  • Page 109 GENOA2D24G-2L+ Log EFI Status Code Enable or disable the logging of EFI Status Codes as OEM reserved type E0 (if not already converted to legacy). Convert EFI Status Codes to Standard Smbios Type Enable or disable the converting of EFI Status Codes to Standard Smbios Types (Not all may be translated).

  • Page 110: Boot Screen

    3.7 Boot Screen In this section, it will display the available devices on the system for user to configure the boot settings and the boot priority. Boot Option #1/#2/#3/#4/#5/#6 Use this to set the system boot order. UEFI Application Boot Priorities Specifies the Boot Device Priority sequence from available UEFI Application.

  • Page 111: Exit Screen

    GENOA2D24G-2L+ 3.8 Exit Screen Save Changes and Exit When selecting this option, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When selecting this option, the following message “Discard changes and exit setup?”...

  • Page 112: Chapter 4 Software Support

    Please download the operating system from the OS manufacturer. Please refer to the OS documentation for more instructions. * Please download the Intel® SATA Floppy Image driver from the ASRock Rack’s website (www.asrockrack.com) to the USB drive while installing OS in SATA RAID mode.

  • Page 113: Chapter 5 Troubleshooting

    GENOA2D24G-2L+ Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot the system. Always unplug the power cord before adding, removing or changing any hardware components. Failure to do so may cause physical injuries and damages to motherboard components.
  • Page 114 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether the power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to the related problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...

  • Page 115: Technical Support Procedures

    GENOA2D24G-2L+ 5.2 Technical Support Procedures If the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Contact information 2. Model name, BIOS version and problem type. 3. System configuration. 4. Problem description. Contact ASRock Rack’s technical support at: http://www.asrockrack.com/support/tsd.asp...
  • Page 116 Contact Information If it needs to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at http://www.asrockrack.com; or contact the dealer for further information. For technical questions, please submit a support request form at https://event.asrockrack.com/tsd.asp...
