Page 2
Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.
CONTENTS 1 SAFETY INSTRUCTIONS ................. 4 1.1 General Safety Warnings ....................4 1.2 Installation warnings .......................8 1.3 Electrical information (For UK type plug) ................8 1.4 During Usage........................9 2 DESCRIPTION OF THE APPLIANCE ............. 10 2.1 Dimensions ........................11 3 USING THE APPLIANCE ................12 3.1 Information on Less Frost Technology ................12 3.2 Thermostat Setting .......................12 3.3 Temperature Settings Warnings ...................12...
1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings Read this user manual carefully. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
Page 5
natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your fridge away from open flames or heat sources and ventilate the room where the appliance is located for a few minutes.
Page 6
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 7
To avoid contamination of food, please respect the following instructions: • Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance. • Clean regularly surfaces that can come in contact with food and accessible drainage systems •...
1.2 Installation warnings • Clearance of at least 150 mm is required at the top of your appliance. Do not place Before using your freezer for the first time, anything on top of your appliance. please pay attention to the following points: •...
Old and Out-of-order Fridges • If your old fridge or freezer has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers contain isolation material and refrigerant with CFC.
2 DESCRIPTION OF THE Notes: • Please read the instruction manual APPLIANCE carefully before installing and using your appliance. We are not responsible for the This appliance is not intended to be used damage occurred due to misuse. as a built-in appliance. •...
2.1 Dimensions Overall dimensions 838,0 540,0 615,0 the height, width and depth of the appliance without the handle. Overall space required in use 658,5 Space required in use 1109,,5 988,0 the height, width and depth of the 640,0 appliance including the handle, plus the space necessary for free 712,8 circulation of the cooling air, plus...
3 USING THE APPLIANCE 3.3 Temperature Settings Warnings • The ambient temperature, temperature of 3.1 Information on Less Frost the freshly stored food and how often the Technology door is opened affects the temperature in the freezer compartment. If required, Thanks to the wrap around evaporator, change the temperature setting.
4 FOOD STORAGE ST (subtropical): This refrigerating appliance is intended to be used at ambient • The freezer is used for storing frozen temperatures ranging from 16 °C to 38 °C. food, freezing fresh food, and making ice N (temperate): This refrigerating appliance cubes.
Page 14
• The maximum amount of fresh food (in kg) that can be frozen in 24 hours is indicated on the appliance label. • Use the fast freezing shelf to freeze home cooking (and any other food which needs to be frozen quickly) more quickly because of the freezing shelf’s greater freezing power.
Page 15
The table below is a quick guide to show you the most efficient way to store the major food groups in your freezer compartment. Maximum storage time Meat and fish Preparation (months) Steak Wrap in foil 6 - 8 Wrap in foil 6 - 8 Lamb meat Wrap in foil...
Maximum storage time Vegetables and Fruits Preparation (months) Strawberry and Wash and hull 8 - 12 Blackberry Add 10 % of sugar to the container Cooked fruits Wash and hull the stems 8 - 12 Plum, cherry, sourberry Maximum storage time Thawing time at room Thawing time in oven (months)
6 SHIPMENT AND • For the removal of heavy ice deposits, disconnect the appliance from the REPOSITIONING mains supply, empty the contents into cardboard boxes and wrap in thick 6.1 Transportation and Changing blankets or layers of paper to keep cool. Positioning Defrosting will be most effective if carried out when the freezer is nearly empty...
7 BEFORE CALLING AFTER- • If a problem persists after you have followed all the above instructions, SALES SERVICE please consult the nearest authorised service centre. If your freezer is not working properly, there may be a minor problem. Check the •...
8 TIPS FOR SAVING ENERGY 9 TECHNICAL DATA 1. Install the appliance in a cool, well- The technical information is situated in ventilated room, but not in direct sunlight the rating plate on the internal side of the and not near a heat source (such as a appliance and on the energy label.
7 or 10 years, based on the type of component, from the placing on the market of the last unit of the model. Visit our website to: Republic of Ireland & Northern Ireland www.nordmende.ie Great Britain www.nordmende.co EN - 20...
