One Vibe
OWNER'S MANUAL
707.822.9570 // marimbaone.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the One Vibe and is the answer not in the manual?

Questions and answers

Related Manuals for Marimba One One Vibe

Summary of Contents for Marimba One One Vibe

  • Page 1 One Vibe OWNER’S MANUAL 707.822.9570 // marimbaone.com...
  • Page 2 ASSEMBLY INSTRUCTIONS & OWNER'S MANUAL FOR ASSEMBLY, A large open space with carpet (or a blanket to cover the floor) YOU WILL NEED: An assistant to help you with assembly CAREFULLY UNPACK YOUR CRATE Compare the seven components as shown on this page. Bass Center Support Harp...

  • Page 3: Center Support

    CENTER SUPPORT UNFOLD LEGS IDENTIFY BASS END OF CENTER SUPPORT Position yourself with the bass end on your left and treble end on your right, with Bass end is engraved with the letter legs facing you. Pull legs toward you. B on bottom of the center support.
  • Page 4 ATTACH ARMS REPEAT FOR TIGHTEN OTHER ARM KNOB Rotate arm and slide notch onto bolt. PEDAL REMOVE PARTS INSERT PEDAL BOLT Remove knob, threaded Slide bolt through center hole on center support. wheel, metal washer, and one black plastic washer. Retain SECURE PEDAL TIGHTEN KNOBS...
  • Page 5 ATTACH STRAP TO PEDAL PLACE HARP IN UPRIGHT Insert strap clip into slot on pedal. POSITION RESONATORS IDENTIFY NATURAL RESONATOR BANK The natural resonator bank has a plug inside every tube. The accidental resonators are missing a plug in every 3rd or 4th tube. POSITION TREBLE END OF INSERT RESONATORS NATURAL RESONATORS...
  • Page 6 LIFT BASS END INSERT RESONATORS Lift bass end of resonators above top Insert resonators into slots on edge of bass headboard. bass headboard. Bass Bass Bass IDENTIFY ACCIDENTAL RESONATOR BANK Repeat steps 19 through 22. CHECK FIT Push down on the resonators on the treble end to make sure they are fully in place. MAGNETIC DRIVE SYSTEM Once the resonators are placed DO NOT...
  • Page 7 KEYBOARDS POSITION NATURAL KEYBOARD SECURE TREBLE END Hold cords, push pedal down with foot, Slide cord around corner jacks on lay keyboard onto rails 1 and 2. treble end. Bass Treble Treble treble end close-up POSITION BARS ON RAILS Place bars between rail jacks. Rail Jacks Set cord into slots on rail jacks.

  • Page 8: Tension Knob

    DAMPING PRESSURE TENSION KNOB TENSION KNOB The tension knob is set at the factory for full damping pressure. Turn clockwise for less damping pressure and counter-clockwise for more dampening pressure. ADJUSTING THE SUSTAIN AT THE BASS OR TREBLE ENDS OF INSTRUMENT The damper bar is set at the factory for even damping across the keyboard.

  • Page 9: Height Adjustment

    HEIGHT ADJUSTMENT RAISING/LOWERING YOUR VIBRAPHONE Locate the Izzy Height Gently lift or push down Close levers when desired Adjustment™ clamp on to raise or lower. height is achieved. the frame. Always adjust the height of the marimba with rails, resonators and bars installed. Rev.
  • Page 10 Push On/Off Switch to ON position. TO MAKE FANS ROTATE Turn Run/Stop Switch to RUN and use the slider to control fan speed. The One Vibe fans always stop in the 12 o’clock/vertical position when you turn the Run/Stop Switch to STOP. FAN RUN/STOP SWITCH...
  • Page 11 AFTER ASSEMBLY CARE & MAINTENANCE bar cord tension moving the vibraphone cleaning bar cord tension Over time, as you play your instrument, the cord that suspends the bars may loosen and need to be adjusted. To increase tension in the bar cord, use the cleats behind the springs to take up slack in the cord.

  • Page 12: Warranty

    MARIMBA ONE WARRANTS ONLY TO THE ORIGINAL PURCHASER THAT THIS INSTRUMENT IS FREE FROM DEFECTS IN MATERIALS AND/OR WORKMANSHIP AS FOLLOWS: 1.  During a period of twelve (12) months from the date of receiving your instrument, Marimba One will ®...
