WAVE
Vibe
™
OWNER'S MANUAL
707.822.9570 // marimbaone.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the WAVE Vibe and is the answer not in the manual?

Questions and answers

Related Manuals for Marimba One WAVE Vibe

Summary of Contents for Marimba One WAVE Vibe

  • Page 1 WAVE Vibe ™ OWNER’S MANUAL 707.822.9570 // marimbaone.com...
  • Page 3 ASSEMBLY INSTRUCTIONS & OWNER'S MANUAL FOR ASSEMBLY, A large open space with carpet (or a blanket to cover the floor) YOU WILL NEED: An assistant to help you with assembly CAREFULLY UNPACK YOUR CRATE Compare the seven components as shown on this page. Harp Bass Frame Center Support...
  • Page 4 ARRANGE FRAME COMPONENTS In a large open space with carpeting (or a blanket), arrange the frame components. Treble Frame Bass Frame Girder LOOSEN KNOBS Turn knobs counterclockwise. Bass Frame Treble Frame OPEN WAVE-LOCK LEVERS Push WAVE-lock levers into open position. Bass Frame Treble Frame Rev.

  • Page 5: Center Support

    CENTER SUPPORT LIFT DIAGONAL BRACE ATTACH DIAGONAL BRACE Have assistant hold bass frame upright. Lower slot onto clamp rod. Lift brace into open position. diagonal brace SECURE DIAGONAL BRACE ATTACH GIRDER PLATE Push WAVE-lock lever into Lower girder plate notches onto frame knobs. closed position.
  • Page 6 HARP PREPARE HARP Slide latches into open and secured position. Open There are four latches. Two on each headboard. Secured POSITION HARP With an assistant, align headboard sockets over frame posts. Post CONNECT HARP AND FRAME SECURE HARP TO FRAME Gently lower harp onto posts.
  • Page 7 PEDAL INSERT PEDAL BOLT REMOVE PARTS Slide bolt through hole on the bass end (left side) of the Remove knob, threaded center support. wheel, metal washer, and the black plastic washer. Bass SECURE PEDAL TIGHTEN KNOBS Place black plastic washer, metal washer, Adjust tension using both wheel and threaded wheel, and knob onto bolt in the threaded knob.
  • Page 8 RESONATORS POSITION TREBLE END INSERT RESONATORS First, position treble end of resonators Insert resonators into the onto treble end headboard. treble headboard. Bass Treble LIFT BASS END INSERT RESONATORS Lift bass end of resonators above top Insert resonators into slots on edge of bass headboard.
  • Page 9 KEYBOARDS SECURE TREBLE END POSITION NATURAL KEYBOARD Slide cord around corner jacks on Hold cords, push pedal down with foot, treble end. lay keyboard onto rails 1 and 2. Treble Treble treble end close-up POSITION BARS ON RAILS Place bars between rail jacks. Rail Jacks Set cord into slots on rail jacks.

  • Page 10: Tension Knob

    DAMPING PRESSURE TENSION KNOB TENSION KNOB The tension knob is set at the factory for full damping pressure. Turn clockwise for less damping pressure and counter-clockwise for more dampening pressure. ADJUSTING THE SUSTAIN AT THE BASS OR TREBLE ENDS OF INSTRUMENT The damper bar is set at the factory for even damping across the keyboard.

  • Page 11: Height Adjustment

    HEIGHT ADJUSTMENT RAISING/LOWERING YOUR VIBRAPHONE Locate the Izzy Height Gently lift or push down Close levers when desired Adjustment™ clamp on to raise or lower. height is achieved. the frame. Always adjust the height of the marimba with rails, resonators and bars installed. Rev.
  • Page 12 USING THE MOTOR CONTROL BOX SPEED CONTROL SLIDER ON/OFF SWITCH FAN RUN/STOP SWITCH Fan Rotation Speed Power On/Off Run/Stop TO TURN POWER ON ON/OFF SWITCH Push On/Off Switch to ON position. TO MAKE FANS ROTATE Turn Run/Stop Switch to RUN and use the slider to control fan speed.
  • Page 13 AFTER ASSEMBLY CARE & MAINTENANCE bar cord tension moving the vibraphone cleaning bar cord tension Over time, as you play your instrument, the cord that suspends the bars may loosen and need to be adjusted. To increase tension in the bar cord, use the cleats behind the springs to take up slack in the cord.

  • Page 14: Warranty

    MARIMBA ONE WARRANTS ONLY TO THE ORIGINAL PURCHASER THAT THIS INSTRUMENT IS FREE FROM DEFECTS IN MATERIALS AND/OR WORKMANSHIP AS FOLLOWS: 1.  During a period of twelve (12) months from the date of receiving your instrument, Marimba One will ®...
