Termix VMTD-IV MIX - 5 Series DS Fully insulated

Schematic description - Termix VMTD-IV MIX UFH

Mounting rail Domestic
Hot Water
01
Domestic
Cold Water
01 69B
Heat Network
Supply
01
01
Heat Network
Return
01 41
L
Your HIU may look different from the HIU shown
01 Isolation valve
02 Single check valve
07 Thermostatic valve, HTG
09 Strainer
10 Circulator pump
14 Sensor pocket, energy meter
21 To be ordered separately
LGB53541
B
39
74
62B 63
14 09
24 Delivered loose with unit
31 Differential pressure controller
39 Connection closed
41 Spacer piece, energy meter
48 Air vent, manual
60 Thermostat
62B Pressure absorber with non-return valve
48
07 69
31
M
M
24
48 60
10
T
02
09 14
63 Filter
69 On/Off valve
69B Customer delivered on/off valve
74 IHPT controller, DHW
B Heat exchanger, DHW
M Electrical wiring box
© Danfoss | 2023.04| 13
Heating
Supply
21
Heating
Return
