DMX PROTOCOL

6 CHANNELS

CHANNEL FUNCTION
CH1 R dimming
CH2 G dimming
B dimming
CH3
CH4 W dimming
A dimming
CH5
UV dimming
CH6
10 CHANNELS
CHANNEL FUNCTION
Master Dimmer
CH1
CH2 R dimming
CH3 G dimming
CH4 B dimming
W dimming
CH5
CH6 A dimming
CH7 UV dimming
CH8 Master strobe
CH9 Function selection
Function speed
CH10
DESCRITPION
Red dimming, from dark to bright
Green dimming, from dark to bright
Blue dimming, from dark to bright
White dimming, from dark to bright
Amber dimming, from dark to bright
UV dimming, from dark to bright
DESCRITPION
RGBWAUV master dimmer, from dark to bright
Red dimming, from dark to bright
Green dimming, from dark to bright
Blue dimming, from dark to bright
White dimming, from dark to bright
Amber dimming, from dark to bright
UV dimming, from dark to bright
RGBWAUV master strobe, from slow to fast
No function
0 - 50
51 - 100 15 kinds of color output, controlled by CH10
101 - 150 Color jumping
Color Gradual change
151 - 200
Color Pulse change
201 - 250
251 - 255 Sound control
Function speed from slow to fast
(When color output, it is color selection)
P.17
