  • Page 1 WID70003 Model 703 User Manual Revision 2 Tru-Test Model 703 User Manual...
  • Page 2 Copyright Limited, 1997 TRU-TEST No part of this document may be photocopied or reproduced without the prior written consent of Limited. TRU-TEST...

  • Page 3: Table Of Contents

    Contents Contents About This Manual ...........1 System Overview ............3 Installation ..............6 Calibration..............7 Operation ..............8 Safety ..............8 Keypad ..............8 Display ..............9 Switching On............10 Live Mode ............10 Set Keys ...............11 Weighing..............11 Switching Off............11 Automatic Power Off ...........12 Changing Units of Measurement ......12 Setup Mode ..............13 Zeroing ..............17 Power Up Zero .............17...
  • Page 4 Contents Clearing a Tare.............22 Example use of Tare and Zero ......22 Fleece (Fine Weight) Mode........23 Setting Resolution............24 Entering Tag (ID) Numbers ........25 Entering Tag Prefixes (Pretag)......25 Clearing Tag Prefixes (Pretag)......26 Entering Individual Animal Tags......26 Making Corrections..........28 Entering Condition Codes ........29 Making Corrections..........30 Recording ..............31 Manual Recording..........31...
  • Page 5 Clearing the Gain Reference File Number ...56 Weight Gain Drafting ..........58 Weight Gain Drafting Check List ......59 Weight Gain Statistics..........60 Tag Number Checking..........62 Setting Up for Tag Checking .......62 Printing Reports ............64 Reports Available..........66 Global (all files) Reports........71 TRU-TEST MP400 Printer ........71...
  • Page 6 Contents TRU-TEST Citizen Model Printer .......72 Group Weighing Mode ...........73 Accumulating Group Weights......73 Making Corrections..........74 Displaying Statistics..........74 Displaying Records ..........75 Printing Reports ...........75 Using the Indicator as a Calculator .......76 Using the Indicator as a Notepad......78 Quick Reference Section .........79 Typical Weighing Session ........79...
  • Page 7 Contents Autoranging ............123 USA Model Indicators ..........124 FCC Warning .............124 Weights and Measures Versions ......126 Model 703 Specifications ........127 Index ...............132...

  • Page 9: About This Manual

    Measures on page 126. In this manual, the term "Loadbar" is used to mean "Loadbar, Suspension Cell or Produce Platform". Model 703 Indicator has dual purpose keys with TRU-TEST different labels on top and bottom. In this manual, only the relevant part of the key label is shown.
  • Page 10 About This Manual TRU-TEST Model 703 Agricultural Weighing System...

  • Page 11: System Overview

    System Overview System Overview System Overview 700 Series is an advanced and versatile TRU-TEST agricultural weighing system. It has been designed with the benefit of many years of animal weighing experience and is used by farm management professionals and agricultural scientists the world over.
  • Page 12 An internal rechargeable battery is available which allows the Indicator to be conveniently independent of any external power supply. • Model 703 can be connected to a TRU-TEST printer to print results or to a computer for TRU-TEST storing and further processing data.
  • Page 13 System Overview • FLEECE (FINE WEIGHT) Mode for better precision at low weights. • Records TAG (ID) numbers along with animal weights. • Stores up to 7600 animal records in up to 99 files. • Provides statistics on recorded data. •...

  • Page 14: Installation

    Ensure that it is located securely. Install the Loadbars or Suspension Cells according to the manual which comes with them ( Loadbars TRU-TEST Manual). Run the Loadbar cables to the Indicator, making sure they are protected from damage.

  • Page 15: Calibration

    230 or 115 volts AC to 13.8 volts DC at 600mA. (NOT suitable if a 12V printer is connected). Use only the power cable supplied by . Plug it TRU-TEST in to the socket marked 12V DC on the Indicator and tighten the retaining collar by hand only. Calibration The Indicator automatically identifies and calibrates itself to the Loadbars connected to it.

  • Page 16: Operation

    Operation Operation Operation Operating the Model 703 is straightforward and TRU-TEST logical. Many functions are performed with a single key press. Safety To avoid damage, never load the scale further if the overload message appears on the display. Keypad The Indicator comes ready to use with default options set by the factory.

  • Page 17: Display

    0.5kg or 1.0kg division size. The division size close to zero (base resolution) depends on the Loadbars fitted. (See your Loadbars Manual.) TRU-TEST The division size automatically changes at particular weight limits to reflect the accuracy of the scale. (See Autoranging on page 122.)

  • Page 18: Switching On

    Operation Switching On If there is no internal battery, connect the 12 volt supply, red lead to the positive terminal, black to negative. Press . Display shows: Message showing that this is not a Weights and Measures approved version for trade use: The scale zeroes itself automatically (if Power Up Zero is On, see page 17).

  • Page 19: Set Keys

    Operation Set Keys The set keys are the white coloured bottom half of some keys on the keypad. They are used to set parameters such as tare weight or draft limits. • To activate the set keys, press • Press the appropriate set key. •...

  • Page 20: Automatic Power Off

    Operation Automatic Power Off Model 703 automatically switches Off after 30 TRU-TEST minutes if no change in weight or key press is detected. This conserves battery life when the scale is not being used. Automatic Power Off can be disabled if required. Contact your Service Centre for details.

  • Page 21: Setup Mode

    Setup Mode Setup Mode Setup Mode Setup Mode allows you to change various parameters and options which affect the operation of the Indicator, for example, the units of measurement or the print option. You can also display the battery voltage and the model number of the Indicator.
  • Page 22 Setup Mode Print (Report) Options Tag / ID Report. See Printing Reports on page 64. Diagnostic Information Battery voltage. See Battery Charging on page 97. Model, language and software. For detailed information see Service on page 110. Fleece (Fine Weight) Mode Fleece (Fine Weight) Mode On.
  • Page 23 Setup Mode Auto Zero Auto Zero On. (Also On Net and Off options.) See Auto Zero on page 17. Group Mode Group Mode On. (Also Off option.) See Group Mode on page 73. Automatic Weight Recording Auto Record On. (Also Off option.) See Auto Recording on page 32.
  • Page 24 Setup Mode Resolution Resolution 0.5kg. See Resolution on page 24. Units kg units. lb units. Baud Baud rate 9600. See Technical Information on page 112. Protocol Hon-Hoff protocol. See Technical Information on page 112.

  • Page 25: Zeroing

    Zeroing Zeroing Zeroing To compensate for any build up of dirt on the weighing platform, the Model 703 has three methods of TRU-TEST zeroing the scale: • Power Up Zero • Automatic Zero • Manual Zero Power Up Zero The scale normally zeroes itself on power up, i.e. when it is turned On.

  • Page 26: Automatic Zero

    Zeroing Automatic Zero Model 703 normally re-zeroes automatically TRU-TEST when a load is taken off. However, this feature can be changed. The options are: "Off" Automatic zeroing disabled. "On" Automatic zeroing occurs when the Gross weight is near zero. "On Net" Automatic zeroing occurs when the Net weight is near zero.

  • Page 27: Manual Zero

    Zeroing • Weights more than 2% (of capacity) from the span calibrated zero may show "ZEro oL" (zero overload). • Automatic zero tracking on Net weight maybe disabled. (See Weights And Measures Versions on page 126). Manual Zero If Automatic Zeroing is Off, the scale should be manually zeroed occasionally.

  • Page 28: Taring

    Taring Taring subtracts the container weight so that the display reads a Net weight. The Model 703 can automatically Tare TRU-TEST an empty container which is placed on the scale, or you can enter the container weight using the keyboard (see Setting a Tare on page 21).

  • Page 29: Setting A Tare

    Taring When a tared container is removed from the Loadbars, the display shows the negative of the container's weight: To display Gross weight, the Tare must be cleared (see Clearing A Tare on page 22). If the Power Up Zero function is Off, then any Tare or Set Tare is retained even when the Indicator is switched Off.

  • Page 30: Clearing A Tare

    Taring Weights And Measures Versions • may be disabled. Set Tare (See Weights And Measures Versions on page 126). Clearing a Tare To clear a Tare: • Press Note: clearing the Tare does not zero the scale. Example use of Tare and Zero Taring and zeroing are useful in situations such as produce weighing, for example weighing potatoes in bins.

  • Page 31: Fleece (Fine Weight) Mode

    300kg (660lb) with weight changes as small as 0.1kg (0.2lb). Weight changes as small as 0.05kg (0.1lb) can be measured using a single Loadbar system (see the Loadbars TRU-TEST manual). To view or change Fleece Mode setting, see Setup Mode on page 13.

  • Page 32: Setting Resolution

    Setting Resolution Setting Resolution Setting Resolution The base resolution (or division size) is automatically set by the Loadbar connected. The displayed (and printed) resolution can be manually set to a coarser value if desired. Four different settings are available starting from the base resolution of the Loadbars connected (eg.

  • Page 33: Entering Tag (Id) Numbers

    Entering Tag (ID) Numbers Entering Tag (ID) Numbers Entering Tag (ID) Numbers Model 703 Indicator stores animal weights in a TRU-TEST memory file along with a tag (ID) number and condition code (see Entering Condition Codes on page 29) or group count (see Group Weighing Mode on page 73).

  • Page 34: Clearing Tag Prefixes (Pretag)

    Entering Tag (ID) Numbers Key in the tag prefix (digits appear on the left) Press A tag prefix can also be useful when generating automatic tag numbers. It can be used to set the start number to 00,00,0100 for example. You can reset the automatic tags to begin from 00,00,0001 by clearing the tag prefix or by clearing any file.

  • Page 35: Making Corrections

    Entering Tag (ID) Numbers There is a faster method of entering tags; you can key in the digits of the tag directly then press TAG ( ID ). This saves having to press ENTER each time. (You can enter the tag number while the scale is determining the animal's weight.) The Tag Entered (ID Entered) pointer turns On when a tag is entered and turns Off again when the weight is recorded.
  • Page 36 Entering Tag (ID) Numbers If ENTER has been pressed, you can: • View the tag you have entered by pressing (ID). • If it is okay, press to return to live mode. • If not okay, re-enter the tag. If you have already pressed RECORD to store the data in memory, you can quickly delete the last record: •...

  • Page 37: Entering Condition Codes

    Entering Condition Codes Entering Condition Codes Entering Condition Codes In addition to a tag number (see Entering Tag Numbers on page 25), each animal can have a code number representing its condition. Condition codes are useful as a means of marking stock condition, performance or animals to be sold.

  • Page 38: Making Corrections

    Entering Condition Codes Making Corrections If incorrect digits have been typed, but you have not yet pressed ENTER, you can: • Delete digits one at a time by pressing If ENTER has been pressed, you can: • View the code you have entered by pressing •...

  • Page 39: Recording

    Recording Recording Recording Model 703 can store up to 7600 animal records TRU-TEST (weight, tag and condition code). The data is retained in memory until cleared, even when the Indicator is switched Off. The records can be displayed one at a time on the display screen or printed out as a report using the TRU-TEST printer.

  • Page 40: Automatic Weight Recording

    If not, press CLEAR to force the Recorded pointer Off. Automatic Weight Recording Model 703 is capable of totally hands off TRU-TEST operation. In this mode the Indicator effectively presses the RECORD key itself when there is a stable weight on the platform.
  • Page 41 Recording The Indicator has several sophisticated safeguards to prevent malfunctions during Auto Record operations. However, if the Recorded pointer fails to turn Off when a new animal of the same weight quickly follows onto the platform, press the CLEAR key. On Tag (ID) - Setting for Electronic Tag (EID) Recognition As well as "OFF"...

  • Page 42: Turbo Setting

    Recording Turbo Setting If the Stable pointer is not On when you press the RECORD key, a message is displayed and the weight is not recorded. Using the Turbo Setting, you can change the speed of response of the Stable pointer so that it comes On faster for rapid throughput of animals or slower for greater accuracy.

  • Page 43: Displaying Statistics

    Displaying Statistics Displaying Statistics Displaying Statistics Model 703 Indicator has five keys to display TRU-TEST statistics about the animal records held in the current file. If you are using multiple files, first select the file required (see Scanning Files on page 46) then use the following keys: Minimum weight recorded.

  • Page 44: Displaying Records

    Displaying Records The global file (file 0) is a special file that allows you to do statistics and print reports on all data in all files. You cannot record or edit data in file zero. Press to select the global file. Display statistics or print reports as normally done for any other file.
  • Page 45 Displaying Records • Press to see the corresponding weight (W) • Press to see the corresponding condition code (or group count, see Group Mode on page 73) • Press again for gain (if gain file set). • Press at any stage to return to live mode.

  • Page 46: Deleting Records

    Deleting Records Deleting Records Deleting Records Warning: when the DELETE key is pressed, the record is totally lost and cannot be recovered. You can delete any record (tag, weight and condition code or group count) as follows: to find the unwanted record. (See Displaying Records on page 36, or Searching Records on page 42).

  • Page 47: Editing Records

    Editing Records Editing Records Editing Records Model 703 allows editing (changing) of data TRU-TEST stored in memory. Records which have been edited are marked with an * on all printed reports. Display the tag, weight or condition code (or group...

  • Page 48: Inserting Records

    Inserting Records Inserting Records Inserting Records Model 703 Indicator allows manual insertion of TRU-TEST complete animal records into the memory file. This allows animals to be added which were missed out during weighing. It also allows the Indicator to be used as a notepad (see page 78).
  • Page 49 Indicator automatically prints the entire record (as it does when the RECORD key is pressed). This function can be disabled if required, consult your Service Centre. TRU-TEST Weights And Measures Versions • The Insert function may be disabled. (See Weights And Measures Versions on page 126).

  • Page 50: Searching Records

    Searching Records Searching Records Searching Records You can search through the records in memory to find a particular tag (ID): Press , display shows: Key in the tag number required. Press If the Indicator finds the tag number in memory, it displays: Then the tag is displayed.

  • Page 51: Searching For Minimum Or Maximum Weight

    Searching Records Press to enter a new tag number Press to return to Live Weighing Mode. Searching for Minimum or Maximum Weight To search the current file for the maximum weight recorded: • Press The record is found and you can display the tag number or weight as required (see Displaying Records on page 36).

  • Page 52: Multiple Files

    Multiple Files Multiple Files Multiple Files Model 703 Indicator can store data in multiple TRU-TEST files (up to 99 files) and you can record the date of each file. The Indicator is pre-set to file 1 at the factory and it may be that you have no need to use other files.

  • Page 53: Selecting Files

    Multiple Files Selecting Files To view or change the current file: To view, press ("E" means an empty file) To change, key in a new file number. Press To assist with file management, enter a File Date each time a new file is started (see Setting File Dates on page 53).

  • Page 54: Scanning Files

    Multiple Files Scanning Files Press Press to scroll through the file numbers. (To rapid scroll, press and hold down the key.) You can scan for an empty file by looking for the "E" sign. Press to display file numbers and animal counts. (In this example File 1, 30 animals.) Press again to display file...

  • Page 55: Finding A File By Tag (Id) Search

    Multiple Files Finding a File by Tag (ID) Search If you know the tag number of one of the animals in the file, you can do a global (all files) search for it. Press to select the global file. Press Key in the known tag number.

  • Page 56: Clearing All Of Memory

    Multiple Files Clearing all of Memory Warning: Once the memory has been cleared, the weight data cannot be recovered. Press to select the global file. Press to enter set mode. Press Press Press a third time to confirm the clear operation. (or press LIVE to abort the clear operation) The following table shows the affect of clearing file 0.

  • Page 57: Drafting (Sorting By Weight)

    Drafting (Sorting by Weight) Drafting (Sorting by Weight) Drafting (Sorting by Weight) Model 703 has the ability to do two-way or TRU-TEST three-way drafting (sorting by weight). Setting Draft Limits If you have been using Weight Gain and you don't want weight...

  • Page 58: Weighing In Draft Mode

    Drafting (Sorting by Weight) If the Indicator displays "diF cELL" when entering a draft limit, it means that there are memory records or draft limits present which apply to different Loadbars to those connected. To enable use with the current Loadbars, clear the file or select another file.

  • Page 59: Clearing Draft Limits

    Drafting (Sorting by Weight) Draft mode is akin to live mode. All the functions normally available in live mode are also available in draft mode. The tag and weight recording operations described in Recording (see page 31) also apply to draft mode. (Also see Weight Gain Drafting on page 58.) •...

  • Page 60: Weight Gain

    Weight Gain Weight Gain Weight Gain Using an animal's unique tag number, the Model 703 TRU-TEST can display the weight gain (or loss) as well as the current Gross weight. When a tag number is entered, the Indicator searches a specified file (the gain reference file) for the same number, finds the previous weight and compares it with the current weight on the platform.

  • Page 61: Setting File Dates

    Weight Gain Setting File Dates To view or change the date of the current file: Press Key in the date, including zeros as shown. Press If used for daily weight gain, the file date must be in MM:DD:YY format for the USA or DD:MM:YY format for all other countries.

  • Page 62: Displaying Weight Gain During Weighing

    Weight Gain Press The date is also cleared when the file data is cleared. Displaying Weight Gain During Weighing Press to select Weight Gain Mode. (You can press this key at any time during weight display to toggle between normal weight and weight gain. A brief message "On"...

  • Page 63: Displaying Weight Gain After Weighing

    - that is, they were created using different Loadbars. Ensure that Loadbars with the same base resolutions are used or get one set of Loadbars span calibrated to match the other set(s). (See your TRU-TEST Service Centre.) Displaying Weight Gain After Weighing You can view the weight gains after the weighing session.

  • Page 64: Printing Weight Gain Reports

    Weight Gain • Make sure the two files are set up for weight gain as described above. When a gain reference file is set, the option to display weight gain rather then Gross weight becomes available. • Display the records in the normal way as described on page 36.
  • Page 65 Weight Gain Weights And Measures Versions • Weight gain operation may be disabled. (See Weights And Measures Versions on page 126).

  • Page 66: Weight Gain Drafting

    Weight Gain Drafting Weight Gain Drafting Weight Gain Drafting Weight gain drafting combines the use of the Weight Gain function (see page 52) and the Drafting function (see page 49). When a file has a gain reference file number set, its draft limits are interpreted as weight gain draft limits.

  • Page 67: Weight Gain Drafting Check List

    Weight Gain Drafting Weight Gain Drafting Check List Select an empty file for this weighing session. Set the gain reference file number. Check both file dates (if daily weight gain required). Enter the weight gain draft limits. Press for draft mode. Press key for Weight Gain Mode.

  • Page 68: Weight Gain Statistics

    Weight Gain Statistics Weight Gain Statistics Weight Gain Statistics Weight Gain On When Weight Gain Mode is On and the gain reference file is set, the statistics keys, MIN, MAX, AVERAGE, TOTAL and COUNT give weight gain statistics for those animals whose tags exist in both the current file and the gain reference file.
  • Page 69 Weight Gain Statistics Example You can look at the average gross weight of the animals in the low weight gain range of the current file to see if there is a correlation between gross weight and weight gain. To do this: Select a gain reference file.

  • Page 70: Tag Number Checking

    If you have a Personal Computer you can use the AgLinker program to load a ready made file of TRU-TEST tag numbers into the Indicator. Set up the Indicator for weight gain operation. That is,...
  • Page 71 Tag Number Checking The weight displayed is the same as the normal weight because the weights in the gain reference file are zero and we are not using daily weight gain because no date is set in the gain reference file. The tag checking capability could also be used to do drafting by tag number.

  • Page 72: Printing Reports

    Printing Reports Printing Reports Printing Reports Model 703 can print eight different full reports TRU-TEST and five different summary reports. You select the required report using the PRINT OP (REPORT OP) option in Setup Mode (see page 13) and then start printing using the PRINT (REPORT) key in live mode.
  • Page 73 Printing Reports Press (REPORT) To abort a printout, press Reports have the relevant animal records in the current file printed on them. Summary reports have statistics only and do not show the information on individual animals. All reports are in tag (ID) number order except the "Cull" report, which is in weight order and the "Condition Code"...

  • Page 74: Reports Available

    Printing Reports • Weight Gain Draft Report (daily or accumulated gain). • Weight Gain Draft Summary (daily or accumulated gain). In addition, setting file dates affects the type of gain report printed. If dates are set for both the current file and the gain reference file, then daily weight gains are printed.
  • Page 75 Printing Reports Statistics: Count, Total, Average, Min, Max Cull Summary Report File number: Date (if set): Cull Summary: 10%, 20%, 25%, 50%, 75%, 100% Statistics: Count, Total, Average, Min, Max Daily Weight Gain Report (Requires gain ref file and both dates set) File number: Date: Gain ref file number:...
  • Page 76 Printing Reports Draft Report (When gain ref file not set) File number: Low draft limit: High draft limit: Columns (in ranges): Tag/ID Weight Condition Code Statistics (in ranges): Count, Total, Average, Min, Max. Statistics (overall): Count, Total, Average, Min, Max. Daily Weight Gain Draft Report (Requires gain ref file and both dates set) File number:...
  • Page 77 Printing Reports Weight statistics: Count, Total, Average, Min, Max. Draft Summary (When gain ref file not set) File number: Low draft limit: High draft limit: Statistics (in ranges) Count, Total, Average, Min, Max. Statistics (overall) Count, Total, Average, Min, Max. Daily Weight Gain Draft Summary (Requires gain ref file and both dates set) File number:...
  • Page 78 Printing Reports Weight statistics: Count, Total, Average, Min, Max. Condition Code Report File number: Date: Columns: Tag/ID Weight Condition Code Statistics: Count, Total, Average, Min, Max File Summary For each file, prints: file number, date, low draft limit, high draft limit, gain ref. file number and date, days, count, total, average, minimum, maximum.

  • Page 79: Global (All Files) Reports

    Note: The printer cable used with the Citizen printers TRU-TEST cannot be used with the MP400 printer. Model 703 Indicator and printer are factory TRU-TEST configured with compatible settings. Earlier model Indicators may need to be set up to communicate correctly with the printer.

  • Page 80: Tru-Test Citizen Model Printer

    Printing Reports TRU-TEST Citizen Model Printer Use only the RS232 cable supplied by TRU-TEST To change the paper, refer to the underside of the mechanism cover on the printer. If there are any problems, refer to Troubleshooting on page 99.

  • Page 81: Group Weighing Mode

    Group Weighing Mode Group Weighing Mode Group Weighing Mode Group Weighing Mode allows you to weigh several animals at once and record the number of animals along with the group weight. Reports can be printed showing statistics for group weights and calculated average animal weights.

  • Page 82: Making Corrections

    Group Weighing Mode Making Corrections If incorrect numbers have been keyed in, but you have not yet pressed ENTER, you can: • Delete digits one at a time by pressing If ENTER has been pressed, you can: • View the number of animals you have entered by pressing •...

  • Page 83: Displaying Records

    Group Weighing Mode With Group Mode Off the statistics keys display the following: COUNT The number of groups in the current file. TOTAL Sum of the group weights in the current file. AVERAGE Average group weight (TOTAL / COUNT). Minimum group weight. Maximum group weight.

  • Page 84: Using The Indicator As A Calculator

    Using the Indicator as a Calculator Using the Indicator as a Calculator Using the Indicator as a Calculator Model 703 has the ability to perform TRU-TEST multiplication's on a displayed quantity - live weight, statistic, weight gain, condition code, tag or even the result of a previous calculation.
  • Page 85 Using the Indicator as a Calculator Often the displayed weight needs to be multiplied by the same number for each animal - a constant. In this case, there is no need to enter the number every time. To multiply by a constant number: Carry out the same steps for normal multiplication for the first weight.

  • Page 86: Using The Indicator As A Notepad

    Using the Indicator as a Notepad Using the Indicator as a Notepad Using the Indicator as a Notepad The Insert Record function (see page 40) of the Indicator can be used for manual entry of numeric data other than weights and tag numbers.

  • Page 87: Quick Reference Section

    Quick Reference Section Quick Reference Section Quick Reference Section Typical Weighing Session Turn the Indicator On. Scan for an empty file ("E"). Return to live mode. First animal onto platform. Enter tag (ID) number. Enter condition code (alternatively group count). Wait for Stable pointer.

  • Page 88: Keys

    Quick Reference Section Keys Grey coloured keys are accessible during LIVE mode. White coloured keys are accessible during SET mode. (0 to 9) - numeric keys. Displays the average weight or weight gain, of all animals recorded in the current file. Clears the last digit entered during numerical keypad entry (tags, draft limits, date, condition codes, weights,...
  • Page 89 Quick Reference Section From live display, displays the top (last) animal record. If displaying records, scrolls up. When selecting files - selects the next file. This key auto-repeats when held down. If pressed after the Search key, finds and displays the heaviest animal record.
  • Page 90 Quick Reference Section View or set the current file date. View or set the current file number. Selects Weight Gain display format. View or set the gain reference file number. View or enter current group count. (ID) Displays the current id number or initiates entry of an ID (USA Model Indicators).
  • Page 91 Quick Reference Section Turns the Indicator On. View or set the pre-tag number. (PREFIX) View or set the ID prefix (USA Model Indicators). Prints a report or summary of the records in the current memory file. Records the displayed live weight (and associated tag and condition code (or group count)).
  • Page 92 Quick Reference Section Cancels out dirt and excrement accumulating on the platform and returns the display to exactly zero.

  • Page 93: Display Pointers

    Quick Reference Section Display Pointers SPAN Shows that the Span Calibration option is being used. (For Service Centres' use only.) ZERO Shows that the weight is within one quarter of a division of zero. TARE Shows that Net weights are being displayed (a Tare has been entered).

  • Page 94: Display Messages

    Quick Reference Section Display Messages Message Meaning - 0000 - Drafting, no weight on platform. File number and date. 8 Volt Internal 8 volt supply failure. 12.5 Volt Diag information 1, supply voltage. Diag information 2. Diag information 3. Diag information 4. 9600Baud Baud rate of communications port.
  • Page 95 Quick Reference Section Auto Rec Setup automatic weight recording options. Autozero Setup Automatic zero options. Average weight statistic. Az Off Automatic zeroing Off. Az On Automatic zeroing On. Az on Net Automatic zeroing on Net weights. Bad Code Bad code from Loadbar cable plug. Bad Conf Configuration data is lost.
  • Page 96 Quick Reference Section Clr File Do you want to clear file? Count statistic. Condcode Print option: Condition code report. Count Enter group count. Cptr Out Computer output format. Cs Fault Checksum Fault in EPROM. Cts Pin5 CTS handshaking on pin 5 of the communications interface.
  • Page 97 Quick Reference Section Draft low limit. Draft Print option: Draft report. Draft S Print option: Draft summary report. Dsr Pin6 DSR handshaking on pin 6 of communications interface. Duplicat Duplicate tag warning. Enter ID Enter an identification number. Entr Tag Enter a tag.
  • Page 98 Quick Reference Section Fleece Setup Fleece Mode options. Found Tag found. Full Memory is full. Gain Print option: Weight gain report. Gain Dft Print option: Weight gain draft report. Gain (accumulated). Gn Dft S Print option: Weight gain draft summary. Gn Fl xx Gain reference file is xx.
  • Page 99 Quick Reference Section Hon-Hoff XON XOFF handshaking on the communications interface. Last Rec Last record before memory is full. Lith Bat Internal lithium battery flat. Minimum (low) weight statistic. - Lo - Drafting LOW range. Lo Bat Low supply voltage indicated. Neg Volt Internal negative voltage failure.
  • Page 100 Quick Reference Section Not Stbl Not stable when attempting to record. Overflo Overflow in number entry (value too large). Overload Overload on scale. Pr Fault Processor fault. Printing Printing in progress. Print Op Setup print options. Protocol Setup handshaking protocol options. Pu Zero Setup Power Up Zero options.
  • Page 101 Quick Reference Section Service The Indicator requires service. Indicator Set Mode keys active. Spc Lost Span Calibration data is lost. StbL xPC Stable pointer On when within x%. Sure ? Are you sure about clearing all files? Set Tare value. Tag Id Print option: tag (ID) ordered report.
  • Page 102 Quick Reference Section Zero OL Zero overload for Weights and Measures versions and when using Span Calibration. Zeroing The Indicator is Zeroing.

  • Page 103: Care And Maintenance

    Care and Maintenance Care and Maintenance Care and Maintenance Model 703 Indicator is a rugged and robust TRU-TEST product designed to withstand the environment associated with livestock handling. The case is made from extremely tough, ultraviolet-resistant polycarbonate. The keyboard is completely sealed for all-weather operation.

  • Page 104: Internal Battery

    Refer all servicing matters to your Service Centre. The case is a sealed unit TRU-TEST and, if opened, moisture could affect the operation of the Indicator. The product warranty becomes void if the case seal is broken.
  • Page 105 The charger only restarts once the external power supply has been disconnected or turned Off and then reapplied. Model 703 enables the user to read the voltage at TRU-TEST any time in order to check the condition of the internal battery, see Setup Mode on page 13.
  • Page 106 Care and Maintenance A fully charged internal battery reads 12.5 volts or more when Model 703 has been On for 5 to 10 minutes with TRU-TEST no Loadbars or external power source connected. The internal battery is considered low when the voltage reads less than 11.0 volts.

  • Page 107: Troubleshooting

    Troubleshooting Troubleshooting Troubleshooting "8 VoLt" displayed Cause The internal 8 volt supply (used to supply the Loadbars) is outside its specified limits. Solution Disconnect the Loadbar cables from the Indicator one at a time. If the "8 voLt" message disappears then there is a fault in the Loadbars or their cables.
  • Page 108 Troubleshooting If the Indicator is not using Span Calibration then it may still be used without its Standard Calibration but with reduced accuracy. The accuracy cannot be guaranteed. Return the Indicator to your Service Centre to have its Standard Calibration data cleared or restored.
  • Page 109 Troubleshooting Display is unstable The display jumps from reading to reading or cycles up or down. Cause Moisture or dirt in the Indicator or Loadbar plugs. Solution Clean with methylated spirits or ethyl alcohol and dry out the Indicator and Loadbar plugs. Cause Loadbar cable damaged.
  • Page 110 Troubleshooting "High Bat" displayed Cause The supply voltage is greater than 16 volts DC. This message is displayed for 15 seconds and then the Indicator switches itself Off. Solution Replace power supply with a unit that can provide 10.5 to 16 volts DC.
  • Page 111 Troubleshooting "Neg Volt" displayed Cause The internal negative supply is outside its specified limits. Solution Disconnect any cable plugged in to the communications (printer) socket. If the problem disappears check the cable. Otherwise return the Indicator to your Service Centre. "No Cell"...
  • Page 112 If using two Loadbar systems with different minimum resolutions either obtain compatible Loadbars, or contact your local Service Centre and get one of the TRU-TEST Loadbar systems span calibrated to match the other (the majority of systems are 0.5kg (lb)).
  • Page 113 Troubleshooting "Pr Fault" displayed Cause The processor inside the Indicator has "crashed", probably due to an electrical trauma in the power supply line. Solution Turn the Indicator Off and then On. If there is a "Bad Conf", "Cal Lost" or "SPC Lost" message during turn On then the crash has caused the loss of vital internal data which the Indicator has been unable to recover by itself.
  • Page 114 Troubleshooting Printout - sections missing Cause Hand shaking is not working. Solution Try changing the handshaking to DSR pin 6. If the Indicator now locks up when printing, check the cabling. See Printer Interfacing on page 120. "Service" or "Bad Conf" displayed Cause Essential memory data containing the configuration number has been corrupted or an upgrade attempt has...
  • Page 115 Troubleshooting Solution Remove any live weight from the platform. If you have two Loadbars, disconnect one at a time to determine if one is faulty. Check the power supply by replacing it or running the Indicator from a 12 volt car battery. "Under Ld"...
  • Page 116 Troubleshooting Solution Press the Gain key to turn Weight Gain Mode On. (If it turns Off, press again to turn back On.) The display does not switch to weight gain display until a weight is on the platform. Try re-entering the tag. Weight readings inaccurate •...
  • Page 117 Troubleshooting...

  • Page 118: Service Centres

    Troubleshooting Service Centres If after carrying out the above recommended solutions to the various problems the fault has not been rectified, contact your local Service Centre: TRU-TEST New Zealand Phone Facsimile Toll Free (09) 274 5799 (09) 274 6367 0800 653 356...
  • Page 119 Troubleshooting Selecting the Diag SETUP option, then pressing the three times gives the information in the following sequence (see Setup on page 13): Battery voltage Model numbers, language and software version. PCB type, memory size and Loadbar code. Configuration number. Write the diagnostic information here: ___.__ Voltage...

  • Page 120: Technical Information

    Technical Information Technical Information Technical Information Communications Port Model 703 is equipped with an RS232C serial TRU-TEST interface port for connection to a computer or printer. The Indicator is configured as a DTE (Data Terminal Equipment) device and therefore requires a cross-wired cable for most computers which are also DTE devices.
  • Page 121 Technical Information For connection to a computer or printer using software ("Hon- HoFF" selected), only TX, RX and SG need to be wired. TX and RX usually must be cross wired. For connection to a printer using hardwired (or sometimes called DTR) handshaking, only TX, DSR and SG need to be wired.

  • Page 122: Downloading To A Computer

    Technical Information Downloading to a Computer Model 703 has the facility to download the TRU-TEST records in its memory to a computer. This allows tag (ID) numbers, condition codes (or group counts) and weights to be saved on the computer and used for further farm management purposes.

  • Page 123: Remote Control By Computer

    The following gives details for those writing their own software to control the Indicator. Remote control of the Indicator is gained by sending a STX (02Hex) or a SOH (01Hex) to the Model 703. STX temporarily sets the Indicator to 9600 baud and Xon-Xoff.
  • Page 124 The output consists of a single character: 0, L, C, H which mean zero, low, centre or high respectively. Beep. Activates the Model 703 beeper. TRU-TEST Remote keys 42, 43, 45 & 46 control output modes which are mutually exclusive. The output mode activated remains active when computer control is relinquished and over Indicator power downs.
  • Page 125 Technical Information Remote keys 42, 43, 45 & 46 can be executed from the Indicator's keyboard if necessary. This allows the Indicator to talk to some unintelligent output devices. To do this, turn the Indicator Off and then hold down the '0' key while turning it back On.
  • Page 126 Technical Information Where T1..T9 are the nine display pointers from left to right. The contents of the LCD display then follow as ASCII characters, including any decimal points, commas or colons in their respective positions. Leading or trailing spaces are not removed, so the number of characters is always at least 8.
  • Page 127 Technical Information eg. for 110 baud, wait 200mS. Discard any characters received except ACK. Start at 9600 baud and work down to avoid the Indicator getting junk characters. After determining the baud rate, send an STX (this will temporarily set the Indicator to 9600 baud and Xon-Xoff). Wait until all characters have been sent and then change the computer to 9600 baud, Xon-Xoff.

  • Page 128: Printer Interfacing

    If another make of printer is used, or for some reason the factory settings have been changed, the required details are described in Non Tru-Test Printers below. The Indicator's factory default baud (data transfer) rate is 9600 and the handshaking method is "Hon-Hoff" to suit the printer.

  • Page 129: Electronic Tag (Eid) Reading

    Xoff" handshaking to match the Indicator. Otherwise set the Indicator to match the printer. Check your printer manual for the parameters. Electronic Tag (EID) Reading Model 703 Indicator can be coupled to TRU-TEST electronic tag readers. This section gives technical information about communication between the two devices.
  • Page 130 Technical Information Example Transmission Data Identify the tag number and convert to an 8 digit (or less) whole number. No decimal points allowed. Gain control of the Indicator by transmitting STX ASCII (03hex), if identification is valid. Transmit numbers to the Indicator: LIVE ASCII (31hex, 30hex) ASCII (32hex, 39hex)

  • Page 131: Autoranging

    The live capacity of the scale is usually a round multiple of the base resolution, for example: 3000 x 0.5kg = 1500kg. Refer to the Loadbars Manual for live capacities of TRU-TEST Loadbars and Suspension Cells. TRU-TEST Weights And Measures Versions •...

  • Page 132: Usa Model Indicators

    Keys Reference on page 80 and Display Pointers on page 85. See also Weights and Measures Versions on page 126. FCC Warning Model 703 Indicator is certified to comply with TRU-TEST the limits for a Class B computing device in accordance with...
  • Page 133 USA Model Indicators • Plug the Indicator into a different power outlet (if used) so that the Indicator and the receiver are on different branch circuits. If necessary, the user should consult the dealer or experienced radio/television technician for additional suggestions. The user may find the following booklet prepared by the Federal Communications Commission helpful: "How to Identify and Resolve Radio-TV Interference...

  • Page 134: Weights And Measures Versions

    For further details on correct configuration numbers contact your local Dealer. TRU-TEST The weighing system needs to be checked and approved for trade by a Weights and Measures inspector on a regular basis. (This is the responsibility of the user.)

  • Page 135: Model 703 Specifications

    Model 703 Specifications Model 703 Specifications Model 703 Specifications Note For configuration details of Weights and Measures versions see Weights And Measures Versions on page 126. Analogue input Loadcell excitation: 8 volts DC, 4 wire, 6 x 350 ohm loadcells max.
  • Page 136 Model 703 Specifications Multi-interval (Weights and Measures): 5000 maximum (Max3/d1). Three division sizes (d1, d2, and d3). Transitions at 500d2 and 500d3. Requires configuration. Maximum number of divisions selectable as required during Span Calibration. Standard versions (non trade): Set by built-in configuration, dependent on loadcell type used.
  • Page 137 Model 703 Specifications Zero and Tare controls Push button Zero: For span cal and Weights and Measures: Maximum ± weight which can be zeroed is 2% of live capacity. For std cal or 50% deadweight allowance option: Any weight up to live capacity may be zeroed.
  • Page 138 Model 703 Specifications Internal battery Sealed lead acid. Must be stored in a charged state. Operating time: 8 hours @ 20°C (70°F), with two Loadbars connected. Charging time: Not less than 6 hours using 12 volt DC 1.5A (3 Amp 20uS pulses) @ 20°C (70°F).
  • Page 139 Model 703 Specifications Memory capacity 64K RAM: 7600 records. Tag numbers: Eight numerical digits. Stored Weights: Up to 16383 divisions (Positive weights only). Condition codes or group counts: up to 4 digits. Number of files: up to 99. Physical dimensions Display: 8 by 7-segment LCD.

  • Page 140: Index

    Index Index Index report Configuration number Accuracy Constant - in calculation AgLinker - computer program Count - statistics Automatic Power Off CS Fault message Automatic Zero Cull report Autoranging Average weight gain Date printing on report setting file date Bad Code message Delete Bad Conf message number...
  • Page 141 Index Loss - weight loss scanning for searching for selecting Maintenance Fleece Mode Manual Zero Maximum effect of taring Gain load reference file statistics Troubleshooting weight gain weight gain Memory weight gain displaying clearing weight gain printing display records in weight gain statistics print Global file...
  • Page 142 System Overview tag number Print options - Setup Mode Tag entered pointer reports Tag number Printer checking Troubleshooting drafting TRU-TEST Citizen duplicate TRU-TEST MP400 entering 25, 26 prefix recording Rd message Ready message search for Recorded pointer Tare Recording...
  • Page 143 Index weight gain displaying weight gain printing weight gain statistics Weight - maximum effect of taring Weight gain draft report 66, 68 Weight gain report Weights and Measures Zero Ol message Zeroing Auto Zero Manual Zero Power Up Zero zeroing and taring...

Table of Contents
