Tru-Test XR3000 Pairing Instructions

ENGLISH
Introduction
Bluetooth allows the XR3000 to communicate wirelessly with a Bluetooth computer and/or a Bluetooth
EID Stick Reader. Bluetooth wireless technology can work anywhere and everywhere and is perfectly suited
to the farm environment.
The Bluetooth XR3000 comes complete with a Bluetooth USB dongle to allow class 1 communications
between your PC/laptop and the XR3000 (range of up to 100 m/330').
If your laptop has onboard Bluetooth, this can be used. However, most laptops have class 2
communications which only offers a range of up to 10 m (33').
Configuring instructions differ, depending on whether you are using the XR3000 with Link3000 or with
Tru-Test Pinnacle. Make sure you follow the appropriate configuration instructions.
Preparing the Bluetooth XR3000 indicator for use with other Bluetooth devices
The Bluetooth XR3000 indicator comes with Bluetooth enabled by default and is pre-configured to
communicate with other Bluetooth devices without any additional setup. However your other device will
need to be paired with the Bluetooth XR3000 (see below for instructions on how to do this for PCs and
laptops).
If Bluetooth communications has been disabled on your XR3000 for some reason, and you want to enable
it again, follow these instructions:
To enable Bluetooth communication on the XR3000:
Note: You should not normally need to enable Bluetooth communication on the XR3000, as it has
Bluetooth enabled by default.
1. Press ,
2. Enable Bluetooth.
The indicator's Bluetooth address setting is displayed.
Tip: The indicator's Bluetooth address setting may be required when configuring another device to
communicate with the indicator. It may also be used to identify an individual indicator if more than one
Bluetooth XR3000 indicator is being used to communicate with a computer at one time.
, , to go to the Bluetooth screen.
1
