Solaira SMaRT Occupancy On/Off Control
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Serious injury or death could occur
• Disconnect ALL power sources before removing back panel. Power should only be re-connected after
electrical installations are complete and back cover replaced
• Be certain the power source conforms to specifications outlined on heater label.
• Assure to connect green wire from heater to ground connection from electrical supply, not to a live or
"hot" conductor
• Engineer/Electrician/Installer to determine suitability of this appliance in intended application and
compliance with all local, state/provincial and National electrical Code (NEC) requirements
• Do not use in locations containing hazardous or explosive atmospheres.
ELECTRICAL RATING
SMRTOCC40
SMRTOCC60
WARNING SERIOUS INJURY OR DEATH COULD OCCUR, DISCONNECT ALL
POWER PRIOR TO SERVICE
Due to ongoing product improvements, specifications and dimensions are subject to change without notice and without incurring obligations.
IOM ▪ SMRTOCC60/40
SMRTOCC60 and SMRTOCC40
Installation & User Manual
S
AFETY WARNING
ALL INSTALLATIONS/SERVICE MUST ONLY BE
PERFORMED BY A LICENSED/CERTIFIED ELECTRICIAN
TO LOCAL AND NATIONAL ELECTRICAL CODE (NEC).
WARNING: SHOCK AND FIRE HAZARD:
208 - 240VAC 50/60HZ, 16.6A MAX CURRENT, 4000W max load
208 - 240VAC 50/60HZ, 25A MAX CURRENT, 6000W max load
SPE-1000 CANADA INSPECTED
Rev 2. 11.19.22
1
Advertisement
Table of Contents
Related Manuals for Solaira SMRTOCC60
Summary of Contents for Solaira SMRTOCC60
- Page 1 Solaira SMaRT Occupancy On/Off Control SMRTOCC60 and SMRTOCC40 Installation & User Manual KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE AFETY WARNING ALL INSTALLATIONS/SERVICE MUST ONLY BE PERFORMED BY A LICENSED/CERTIFIED ELECTRICIAN TO LOCAL AND NATIONAL ELECTRICAL CODE (NEC). WARNING: SHOCK AND FIRE HAZARD: •...
-
Page 2: Installation
Fresnel lens on the front face of the unit. The detection area and range depend significantly on its mounting position. The SMRTOCC60 and SMRTOCC40 controllers not only detect movement of the human body, but also other heat sources similar to the human body. To prevent false activation, the unit must not be located directly facing or in close proximity to the heater lamps. -
Page 3: Safety First
The unit is fitted with three cable watertight strain reliefs. Only one cable should be fitted per strain relief to prevent degrading the unit’s IP rating. To connect 4 lamps, refer to the Wiring Diagram SMRTOCC60 on the next page for an alternative configuration using two junction boxes. - Page 4 Wir60 Due to ongoing product improvements, specifications and dimensions are subject to change without notice and without incurring obligations. IOM ▪ SMRTOCC60/40 Rev 2. 11.19.22...
- Page 5 The unit MUST be orientated with the cable glands facing down. SMRTOCC60 Mounting Template Due to ongoing product improvements, specifications and dimensions are subject to change without notice and without incurring obligations. IOM ▪ SMRTOCC60/40 Rev 2. 11.19.22...
- Page 6 ‘walk test’ mode. The emitters on-time is fixed at 5 minutes. IMPORTANT! When wall mounting, the unit must be orientated with the cable glands facing down. Due to ongoing product improvements, specifications and dimensions are subject to change without notice and without incurring obligations. IOM ▪ SMRTOCC60/40 Rev 2. 11.19.22...
- Page 7 National Electric Code (NEC) requirements. Inforesight Consumer Products Inc. assumes no responsibility for the heaters or controller electrical plan or installation. Due to ongoing product improvements, specifications and dimensions are subject to change without notice and without incurring obligations. IOM ▪ SMRTOCC60/40 Rev 2. 11.19.22...
- Page 8 SMRTOCC40 Mounting Template Positioning The SMRTOCC60/40 can be wall or ceiling-mounted. For wall-mounting, the unit should be positioned 1 to 3 meters high. The diagram below shows the PIR’s detection area. The unit should be fixed securely using the four mounting holes accessible from the front of the unit. Remove the lid to access the mounting holes.
-
Page 9: Troubleshooting
IP65 Gland Diameter Max Cable Entry 2.5mm² Enclosure Dimensions (WxLxH) 100 x 112 x 55 (mm) Due to ongoing product improvements, specifications and dimensions are subject to change without notice and without incurring obligations. IOM ▪ SMRTOCC60/40 Rev 2. 11.19.22... -
Page 10: Limitation Of Liability
3. No charge for travel and/or mileage will be allowed to purchaser. 4. SOLAIRA reserves the right to make changes in design or make any improvements on any products. The right is always reserved to modify our equipment because of new technology, underwriter’s requirements and/or government regulations.
