Solaira SMaRT 34-DV Variable Controller
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
SAFETY WARNING
ALL INSTALLATIONS/SERVICE MUST
ONLY BE PERFORMED BY A
LICENSED/CERTIFIED ELECTRICIAN TO
LOCAL AND NATIONAL ELECTRICAL
CODE (NEC).
WARNING:
HAZARD:
•
Serious injury or death could occur
•
Disconnect ALL power sources before removing cover. Power should only be re-connected after
electrical installations are complete and cover replaced
•
Be certain the power source conforms to the specifications outlined on the heater label
•
Maximum heater load SHOULD NOT EXCEED 38 AMPERE
•
The unit must be externally fused
•
The Controller MUST BE PROPERLY GROUNDED. Ensure that the ground connection from
the electrical supply is connected to the Controller and Heater ground using a green sleeved
conductor.
•
Do not connect the Controller or Heater ground connection to a live or "hot" conductor.
•
Follow state, provincial, local and national electric codes (NEC) including field certifications
•
Do not use in locations containing hazardous or explosive atmospheres.
ELECTRICAL RATING
Maximum load
WARNING SERIOUS INJURY OR DEATH COULD OCCUR,
DISCONNECT ALL POWER PRIOR TO SERVICE
Installation & User Manual
SHOCK
8.0kW @208-240VAC 50/60HZ
4.0kW @120VAC 50/60HZ
SPE-1000 CANADA INSPECTED
AND
FIRE
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Solaira SMaRT 34-DV
Summary of Contents for Solaira SMaRT 34-DV
- Page 1 Solaira SMaRT 34-DV Variable Controller Installation & User Manual KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE SAFETY WARNING ALL INSTALLATIONS/SERVICE MUST ONLY BE PERFORMED BY A LICENSED/CERTIFIED ELECTRICIAN TO LOCAL AND NATIONAL ELECTRICAL CODE (NEC). WARNING: SHOCK FIRE HAZARD: • Serious injury or death could occur •...
- Page 2 The Solaira SMaRT 34-DV Variable Control has been engineered to work with Infrared Heaters, with a maximum rating of 8.0kW @ 208-240V or 4.0kW @ 120V. The Solaira SMaRT 34-DV Control has a 1 to 5 step setting allowing you to find the optimum comfort setting in your specific area.
- Page 3 INSTALLATION The control can be installed in a convenient VENTED location and does not have to be installed in the immediate area of the heaters. The unit is shipped with the Occupancy sensor/pushbutton input fitted with a wire link which continually re-triggers the "ON" timer so that it never expires. If the user decides to utilize the optional Occupancy Monitor, the occupancy monitor should be mounted 8’...
- Page 4 Occupancy Sensor (optional) 12V dc Operating Voltage 90° Adjustable Direction 45’ (18 Meters) Detection WARNING: Solaira SMaRT 34-DV Variable control is a high power electrical device and MUST ONLY BE INSTALLED BY A CERTIFIED ELECTRICIAN TO LOCAL AND NATIONAL ELECTRICAL CODE...
- Page 5 SMaRT 34-DV ILLUSTRATIVE WIRING DIAGRAM* WARNING SERIOUS INJURY OR DEATH COULD OCCUR, DISCONNECT ALL POWER PRIOR TO SERVICE...
- Page 6 Temperature Sensor Input For local temperature sensor input and optional remote temperature sensor input. The local temperature sensor is included with all SMaRT 34-DV controllers. If the user wishes NOT to use the temperature monitoring feature, simply disconnect the temperature sensor.
- Page 7 No charge for travel and/or mileage will be allowed to purchaser. SOLAIRA reserves the right to make changes in design or make any improvements on any products. The right is always reserved to modify our equipment because of new technology, underwriter’s requirements and/or government regulations.
