Solaira SMRTOCC40 PIR Controller
Installation & User Manual, 4kW
Issue 2
____________________________________________________________
• ALL INSTALLATIONS/SERVICE MUST BE PERFORMED BY A
LICENCED/CERTIFIED ELECTRICIAN
• KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
__________________________________
SHOCK AND FIRE HAZARD:
• Serious injury or death could occur.
• Disconnect ALL power sources before removing cover. Power should only be re-
connected after electrical installations are complete and cover replaced.
• Be certain the power source conforms to specifications outlined on heater label.
• Assure to connect green wire from heater to ground connection from electrical
supply, not to a live or "hot" conductor.
• Follow state, provincial, local and national electric codes (NEC) including field
certifications.
• Do not use locations containing hazardous or explosive atmospheres.
ELECTRICAL RATING:
• 208-240V AC @ 50/60Hz.
WARNING SERIOUS INJURY OR DEATH COULD OCCUR, DISCONNECT
SAFETY WARNING!
ALL POWER PRIOR TO SERVICE
SPE-1000 Certified
Page 1 of 7
Feb-16
Advertisement
Table of Contents
Related Manuals for Solaira SMRTOCC40
Summary of Contents for Solaira SMRTOCC40
- Page 1 Solaira SMRTOCC40 PIR Controller Installation & User Manual, 4kW Issue 2 Feb-16 ____________________________________________________________ SAFETY WARNING! • ALL INSTALLATIONS/SERVICE MUST BE PERFORMED BY A LICENCED/CERTIFIED ELECTRICIAN • KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE __________________________________ SHOCK AND FIRE HAZARD: • Serious injury or death could occur.
- Page 2 Feb-16 Introduction The Solaira SMRTOCC40 4kW PIR is part of a family of controllers designed to provide energy saving when used with Quartz Infrared Halogen Lamps. The ‘P’ model has a built in PIR sensor allowing the lamps to automatically switch on only when people are present. In addition to the PIR, a temperature sensor monitors the outside temperature and inhibits the lamps when the temperature exceeds a pre-determined set point of between 1°C and 60°C.
- Page 3 Wiring SAFETY FIRST The Solaira SMaRT PIR is a high power electrical devise and MUST ONLY BE INSTALLED BY A CERTIFIED ELECTRICIAN TO LOCAL AND NATIONAL ELECTRICAL CODE. Warning! Isolate the mains supply before commencing any work on this unit. Ensure all earth wires are connected to maintain earth continuity to the lamp fittings.
- Page 4 Solaira SMRTOCC40 PIR Controller Installation & User Manual, 4kW Issue 2 Feb-16 Wiring Diagram Page 4 of 7...
- Page 5 Vertical Positioning The Solaira SMRTOCC40 4kW PIR can be wall or ceiling-mounted. For wall mounting, the unit should be positioned 1-3 metres high. The diagram above shows the PIR’s detection area. The unit should be fixed securely using the four mounting holes accessible from the front of the unit.
- Page 6 Solaira SMRTOCC40 PIR Controller Installation & User Manual, 4kW Issue 2 Feb-16 Commissioning Turn the set point temperature preset (VR1) fully clockwise to select ‘walk test’ mode. VR1 is located at the top of the printed circuit board as shown opposite.
- Page 7 3. No charge for travel and/or mileage will be allowed to purchaser. 4. SOLAIRA reserves the right to make changes in design or make any improvements on any products. The right is always reserved to modify our equipment because of new technology, underwriter’s requirements and/or government regulations.
