Page 1 Manufactured by: Backyard Discovery 3305 Airport Drive, Pittsburg, KS 66762 800-856-4445 Basepoint Business Centre: Rivermead Drive,Westlea, Swindon SN5 7EX Phone: 0800-118-2476 J.P. Coenstraat 7, The Bridge, The Hague, 2595 WP, Netherlands Phone: 08005678990 ZALIE GREENHOUSE MODEL # : 2304123 For Horticulture Use Only Please visit www.backyarddiscovery.com...
Page 2 OWNER'S MANUAL - BASIC SETUP DIMENSIONS & ASSEMBLY NOTES It is critically important that you start with square and level footings or concrete pad to attach your structure Pay close attention to the items needed for each step. Make sure you are using the correct hardware for each step. •...
Page 3 Bellerose Greenhouse Site Location and Preparation Check your local building and city codes for permit requirements or restrictions, including any HOA restrictions. Select a location with lots of sun, good drainage, and the ability to create a level firm surface for your greenhouse. •...
Page 4: Hardware Parts
PRE-ASSEMBLY STEP 1 - SORTING PARTS It is critical for ease of assembly that you take the time to sort and organize the wood and hardware. WOOD PARTS: • Organize wood parts by the three-digit, alpha-numeric number stamped on each board (ex. P01). •...
Page 5 PRE-ASSEMBLY STEP 2 - TOOLS REQUIRED Drill Attachments: Open End Phillips Head Wrenches 1/2" & 9/16" 1/8", 3/16", 3/8" & 7/16" Drill Bits 3/8" Drive Ratchet, 1/2" & 7/16" STD Sockets 1/2" & 7/16" Deep Sockets Phillips Screw Driver Cordless Drill or Electric Drill Rubber Mallet Claw Hammer...
Page 6 PRE-ASSEMBLY STEP 3 - CHOOSE YOUR ASSEMBLY METHOD There are several types of assembly instructions available to you. 1. Printed Assembly Manual included with your set 2. BILT APP - 3D interactive instructions 3. Combination of the Printed Manual and BILT APP (Note: Step numbers can differ between the two methods)
Page 18: Hardware Components
OWNER'S MANUAL - PARTS IDENTIFICATION Hardware Components H100513 | BOLT WH BLK H100456 | LAG SCREW WH BLK (x48) | 5/16x4-1/4 (x8) | 1/4x2-1/2 H100503 | BOLT WH BLK H100792 | LAG SCREW WH BLK (x6) | 5/16x3-1/2 (x8) | 1/4x3 H100201 | SCREW PFH BLK (x32)
Page 19 OWNER'S MANUAL - PARTS IDENTIFICATION Hardware Components H100198 | WASHER LOCK EXT BLK H100193 | NUT BARREL WH BLK (x143) | 8x19 (x19) | 5/16x1-1/2 H100199 | WASHER LOCK EXT BLK (x1) | 12x19 H100469 | NUT BARREL WH BLK (x1) | 5/16x5/8 H100400...
Page 74 IMPORTANT!! Polycarbonate Sheeting Information The Polycarbonate Sheeting has UV protection on ONE (1) SIDE. CRITICAL to install with the UV protection facing the OUTSIDE • Wear safety gloves to protect against any sharp edges during handling or install. • Do NOT use knife or sharp object to remove protective film as it may result in damage to polycarbonate sheeting •...
Page 143 ONLY USE FOR ANCHORING TO GROUND. SEE STEP 104 FOR ANCHORING TO CONCRETE.
