Summary of Contents for 3nStar RPT004
-
Page 2: What's In The Box
WHATS IN THE BOX • 80mm Thermal Receipt Printer • AC adapter with one AC cable power cord • Data Cable except for Ethernet Port • User's Manual • 80mm roll paper • Software Disc (optional) • Wi-Fi antenna (for Wi-Fi printer with external antenna only) CONNECTING THE CABLES A. -
Page 3: Paper Roll Installation
PAPER ROLL INSTALLATION The steps to install a paper roll are as follows: 1. Open the printer cover. 2. Install the thermal paper roll into the printer as shown in the following. 3. Pull out a small section of the paper until it is outside the cover, then close the cover. - Page 4 BUTTON AND INDICATORS (1) FEED BUTTON Press to FEED paper manually. (2) PAPER INDICATOR When this indicator and Error indicator are ON, it means the printer is out of paper; when both lights are off, it means the printer has paper. (3) POWER INDICATOR This LED is on indicates that the printer is powered on.
- Page 5 CAUTIONS: 1. The printer should be installed in a stable place and avoid placing the printer in vibration and shake. 2. Do not use and store the printer in places with high temperatures, high humidity, and serious pollution. 3. Connect the printer's power adapter to a properly grounded socket. Avoid using the same outlet with large motors or other equipment that can cause power supply voltage fluctuations.
-
Page 6: Printer Cleaning
PRINTER CLEANING The print head should be cleaned when the printer has one of the following conditions: 1. Printing is not clear. 2. The vertical column of the printed page is not clear. 3. Paper feed noise is loud. The steps for cleaning the print head are as follows: 1.
