The values can be changed by using the zoom and amplification sliders on the left (the min. value) and on the
bottom (the max. value) and saved by pressing the button.
These cropping values will be used on all future measurements however they can be reset to default values for
the current map by re-entering the crop screen.
To exit the analysis screen press the button. The zoom level, amplification level, crop values, and map
position will be kept for future measurements.
To reset them back to the defaults, right for the current map, press the button.
All buttons that appear greyed out are not functional during this process.
Any of the surface maps can be cropped to display a user defined area. To do this press the crop button, a new
screen will be displayed as shown below
