POWERFORCE CHARGE ARCHIVE
The archive data can be selected on the main screen. After the
range of charge cycles is chosen, the archive will display on the
screen.
AMP HOURS RETURNED
The total ampere-hours returned during the charge cycle. This
number includes ampere-hours delivered to the battery during the
Verify, 0-80%, 80% to End, and Equalize portions of the charge
cycle.
CHARGE TIME
The total charging time of the charge cycle. This number includes
the time of the Verify, 0-80% 80% to End, and Equalize portions
of the charge cycle.
80% TO END
The time the battery was charged from the 80% charged point
until DV/DT or VT (depending on the control setting) charge termi-
nation. This time does not include any equalize charging time that
may have been automatically or manually selected.
BATTERY OCV
The open circuit voltage in volts per cell of the battery immedi-
ately before the beginning of the charge cycle.
START AMPS
The value of the current delivered to the battery at the start of the
charge cycle.
START VOLTS
The value of the battery voltage (in volts/cell) of the battery at the
start of the charge cycle.
FINISH AMPS
The value of the charge current delivered to the battery at the end
of the charge cycle.
FINISH VOLTS
The value of the battery voltage in volts per cell at the end of the
charge cycle.
EQUALIZE TIME
The time of the equalize portion of the charge cycle. Equalize can
be automatically or manually selected.
START TIME
The time at the start of the charge cycle.
END TIME
The time at the end of the charge cycle. Includes the equalize time
if it was automatically or manually selected format.
BATTERY I.D.
The Battery I.D. number of the battery that was charged in the
charge cycle. Requires PowerForce Battery Identification Module
(BID).
BID START TEMP
The temperature of the battery sensed by the PowerForce Battery
Identification Module at the start of the charge cycle.
BID END TEMP
The temperature of the battery sensed by the PowerForce Battery
Identification Module at the end of the charge cycle.
CYC. AMP HOURS
The Ampere-hour setting of the charger during the charge cycle.
This value cannot exceed the maximum charger output rating.
CYCLE CELLS
The Cell Size setting of the charger during the charge cycle. This
value cannot exceed the maximum charger output rating.
BATTERY TYPE
The Battery Type setting of the charger during the charge cycle.
This value cannot exceed the maximum charger output rating.
PRESENT MONTH
The month that the charge cycle occurred.
PRESENT DATE
The day of the month that the charge cycle occurred.
MODULE OUTPUT AND TEMPERATURE
Each module will display its maximum current and temperature as
