- Page 1 B-Compact OPERATING MANUAL Model-no: • BLR1-010 • BLR2-010 Original document by manufacturer version 1.0 | 2023-06-28...
- Page 2 This document applies to the standard version of this B-Compact. The manufacturer therefore declines all liability for any damage arising from specifications that deviate from the standard version of the B-Compact delivered to you. This document has been compiled with the utmost care. However, the manufacturer cannot be held liable for any errors it contains or the consequences thereof.
-
Page 3: Table Of Contents
Table of contents 1. General information ............1.1 Manual languages . -
Page 5: General Information
1. General information 1.1 Manual languages This manual is supplied with the B-Compact. Other available languages can be downloaded, scan the QR code or double-click/copy the link below. https://www.bravilor.com/en-in/b-compact-manuals 2. Parts and controls 2.1 Parts 6. drain hose 1. lid 2. -
Page 6: Controls
2.2 Controls The basic buttons are described underneath. Controls function Indicators function feedback value with number setting values separator place lid fill time heat temperature unit lock brew B-compact is live circulate ready to dispense stop... -
Page 7: Installation And Prepare For Use
Weekly cleaning on p.9. 700.403.347 (STD) | 700.403.769 (AR) | 700.403.839 (ZH/KO/JA) 2. Place the drip tray for the B-Compact under the manual tap 3. connect the supplied hose to the B-Compact and to a water filter or directly to the water supply ► Only use the hose supplied. -
Page 8: Start Up
3.2 Start up After switching on, the control display shows the set values a after the other. If any of the 7 keys are pressed during start-up, the B-Compact goes straight to standby. Start: • make sure that the water supply is open •... -
Page 9: Stop Button
Information screen: • last set keep warm temperature is displayed • beep sounds • wait for the next screen 3.2d 3.3 Stop button The "stop button" will stop "automatic processes" if they are running... -
Page 10: Standby
• press to go to 5.1a on p.11 • press to go to section §5.5 on p.19 3.3a B-Compact not empty, liquid temperature < 75°C (167°F) • press and hold the to go to screen 5.2c on p.13 • press to go to 5.3c on p.16 • press to go to 5.1c on p.12... -
Page 11: Prepare For Use
6. clean cone and spray plate if neccessary 7. place a new filter paper 8. add the coffee grind, spread the coffee bed evenly ► The use of normal grind is recommended (approx. 40-50 g/l.) ► Exclusively use the Bravilor Bonamat filter paper or filter paper ® of the same quality. 9. place de pray plate and close the cone handles 10. -
Page 12: Cleaning
Weekly drip tray coffee kettle coffee kettle (thorough) filter cone the outside ► Never clean parts of the B-Compact in the dishwasher, only if this is explicitly stated. ► Do not use any aggressive cleaning agents. 4.1 Daily cleaning Drip tray: 1. remove the complete drip tray 2. -
Page 13: Weekly Cleaning
► Use only a non aggressive product due to save the gaskets. Follow the instructions for use of the anti-coffee agent. 4. pour a solution of an anti-coffee agent into the coffee kettle 5. switch on the B-Compact 6. press the "fill button" once?? X haalt de film op 12 liter niet weg X press the "fill button"... -
Page 14: Periodic Cleaning
It may therefore be necessary to clean the gauge glass separately with a gauge glass brush. ► Handle the gauge glass with care, it is very fragile. 1. switch off the B-Compact 2. drain through the manual tap 3. remove the gauge glass cover by gently tilting it forward slightly and pulling it upwards 4.3.1a ... -
Page 15: Functions
► The fill animation (see §5.2 on p.13) alternating with the current water temperature. ► The "fill" and "heat" indicator lights are flashing, "brew" indicator light is flashing at half speed. ► When the B-Compact is filled the next screen appears fill heat brew •... - Page 16 » temperature < 75°C (167°F) go to screen 3.3b on p.6 temperature ≥ 75°C (167°F) go to screen 3.3c on p.6 » 5.1d Warning screen coffee ready: • when the coffee brewing process is ready, the B-compact beeps three times • after 2 seconds the next screen will appear 5.1e Coffee ready: • the temperature and the ready indicator are displayed • the option to enable circulation is now available: »...
-
Page 17: Fill
5.2 Fill ► The B-Compact must always be filled with cold water from the mains During filling, the display shows the following as an animation. Standby mode, when B-Compact is empty: Automatic filling: • press once to go to the next screen ► Once this procedure is completed, the remaining buttons are available. - Page 18 Semi-automatic filling ► The "Fill" indicator is flashing and the fill animationis displayed. • when the button is released the B-Compact will go in standby mode » temperature < 75°C (167°F) go to screen 3.3b on p.6 temperature ≥ 75°C (167°F) go to screen 3.3c on p.6 » 5.2d ...
-
Page 19: Fill And Heat
Information screen filling and heating: ► The fill animation (see §5.2 on p.13) alternating with the current water temperature. ► The "fill" and "heat" indicator lights are flashing. ► When the B-Compact is filled the next screen appears • press to go to screen 5.1b on p.11 • to cancel the process, press... - Page 20 ► Depending on irregularities in the water supply at the location, the automatic filling procedure may result in an incompletely filled B-compact. In this case, fill the rest of the B-compact to the required amount using the semi-automatic filling procedure.
-
Page 21: Circulate
5.4 Circulate This function is only active when liquid is registered in the B-Compact, allowing the pump to circulate the liquid. If this function is used with liquid of 50°C or more, the lid must be in place, otherwise the lid protection will be activated ( see section 6.1 on p.21) - Page 22 Circulation animation progress screen: • the B-Compact returns to the screen where it was activated » standby screen 3.3b on p.6 3.3c on p.6 depending on the liquid temperature » automatic brewing 5.1f on p.12 filling 5.2c on p.13 » » heating 5.3d on p.16 5.4d ...
-
Page 23: Setting Items
5.5 Setting items The setting button is available if no other processes are running Setting Standard adjust from - to S 01 brew temperature 95°C (203°F) 85 - 95°C (185 - 203°F) S 02 brew time 10 minutes 4 - 16 minutes S 03 heat temperature 85°C (185°F) - Page 24 Heat temperature (S 03): • press the to change the value • press to save the changes • when ready a a beep sounds and the carousel is displayed • to cancel press and go back to the carousel 5.5d Pause times (S 04): ►...
-
Page 25: Special Functions
If a process is started while the liquid temperature is between 0-50°C (32-122°F), the lid indicator will flash as a reminder that the lid must be in place. As soon as the liquid reaches 50°C (122°F) the text "lid" appears and the B-Compact stops heating, the temperature is kept at 50°C (122°F) , as soon as the lid is placed the procedure started can continue. -
Page 26: Lock Mode
6.2a Locked B-Compact: ► The lock indicator illuminates and all buttons are inactive except the "stop" button ► If a button other than "stop" is pressed, the lock indicator flashes once. • press to unlock the B-Compact 6.2b ... -
Page 27: Errors
E 21 elektrode werkt niet. (Detecteert niet het leegraken van de B-compact). Element keep warm blijft aan staan » if the error persists, contact your dealer E 22 B-compact leeg tijdens zet proces » if the error persists, contact your dealer... - Page 28 © 2023-06-28 VHH...
