SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. These mounts are intended for indoor use only. •...
PACKAGE CONTENTS Take an inventory of the package contents to make sure you have all the items listed below. Please contact Monoprice Customer Service for a replacement if anything is missing or damaged. 2x Wall Bracket (A) 2x Tilting End Cap (C) •...
PRE-INSTALLATION These mounts must be securely attached to a wall. They may fall and cause injury and/or damage if they are not properly installed. OPTIONAL SPEAKER WIRE MANAGEMENT A. Wires Concealed Inside the Wall B. Wires Exposed Outside the Wall...
INSTALLATION Mount the bracket (A) to the wall. a. Brick Mount b. Wood Mount...
Page 6
2. Attach the wall bracket cover (B) and the speaker platform (D) to the wall bracket (A).
Page 7
3. Place the speaker on the platform (D). a. Adjust the clamps of the platform (D) to hold the speaker in place. b. Secure the speaker using the M4 x 12 mm wood screws (I)
Page 8
4. Adjust the tilting angle and swing the speaker. Congratulations! You have properly installed and assembled your bookshelf speaker mounts.
Check the website for support times and links. To download the latest drivers, firmware, manuals, etc., go to www.monoprice.com and type 44896 into the search bar. If available, support files are linked at the bottom of the product page. REGULATORY COMPLIANCE Notice for FCC This device complies with Part 15 of the FCC rules.
For more detailed information about the disposal of your unwanted product, please contact your local authorities, waste disposal service, or the shop where you purchased the product. Monoprice™ and all Monoprice logos are trademarks of Monoprice Inc...
