Summary of Contents for Saluki SPA-18-40-40
- Page 1 SPA-18-40-40 Broadband Power Amplifier S/N: S56033032 Table of Contents...
- Page 2 SPA-18-40-40 1、Test Report………………………………….1 2、Operation Manual………………………… 6...
- Page 3 SPA-18-40-40 DATE: Mar 31th, 2023 S/N: S56033032 1. Small Signal Test： Fig.1:Small Signal Gain at 25℃(Pin=-30dBm) Fig.2:Input VSWR at 25℃(Pin=-30dBm)
- Page 4 SPA-18-40-40 2. Large Signal Test： Fig.3: P1dB , P3dB and Psat at 25℃ Pout= Psat Fig.4: Power Gain vs Frequency at 25℃(...
- Page 5 SPA-18-40-40 Fig.5: Output Power vs Frequency at 25℃ Fig.6:Gain Compression at 25℃...
- Page 6 SPA-18-40-40 Fig. 7：Noise Floor vs Frequency at 25℃ Fig.8：Output Power vs.Gain.at 25℃...
- Page 7 SPA-18-40-40 Table 1: Spurious vs Frequency(@Pout=46dBm, 25℃) Serial Frequency 2nd Harmonic Spurious Number (GHz) (dBc) (dBc) 18.0 -31.7 -66.2 19.0 -23.7 -65.5 20.0 -25.6 -66.8 21.0 -32.6 -67.6 22.0 -51.0 -71.0 23.0 -51.2 -67.0 24.0 -47.5 -67.4 25.0 -48.0 -64.3 26.0...
-
Page 8: Product Description
SPA-18-40-40 1．Product Description SPA-18-40-40 18-40GHz 40Watts Broadband Power Amplifier Features: Multi-octave Broadband, High output power, High efficiency, High reliability Applications: Test & Measurement, SATCOM, EW GENERAL SPECIFICATIONS: Parameter Unit Min. Typical Max. Frequency Small Signal Gain Gain Adjustment Gain Flatness... -
Page 9: Environmental Specifications
SPA-18-40-40 2．Specifications ENVIRONMENTAL SPECIFICATIONS: Parameter Unit Min. Typical Max. Voltage V(AC) Current@220V ℃ Operating Temperature ℃ Non-Operating Temperature MECHANICAL SPECIFICATIONS: Parameter Unit Min. Typical Max. 588x483x192 Dimensions LxWxH inch 23.15x19.02x7.56 Weight 20.0 RF Input&Output 2.92-Female& 24JS18000 MODEL APPEARANCE(inch/mm) 3．Operation Instructions ➢... - Page 10 SPA-18-40-40 Then, turn on the source output. ➢ Steps to turn off the power amplifier: Firstly, turn off the source output. Secondly, turn off the RF switch. Then, turn off the power switch. ➢ Always keep the voltage within 90V-240V. It is...
- Page 11 SPA-18-40-40 check if the environmental temperature higher than 50 ℃, or the fans work improperly.
