Windbit
Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches
Hardware installation and reference guide
Copyright © Windbit Dm3022-I Version 1.0 2023
ESW1L3 & ESW2L3 Series Switches
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESW1L3 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Windbit ESW1L3 Series

Summary of Contents for Windbit ESW1L3 Series

  • Page 1 Windbit Hardware Installation and Reference Guide ESW1L3 & ESW2L3 Series Switches Hardware installation and reference guide Copyright © Windbit Dm3022-I Version 1.0 2023 ESW1L3 & ESW2L3 Series Switches...

  • Page 2: Legal Notice

    Windbit Hardware Installation and Reference Guide Legal Notice Warranty This publication is subject to change. Teldat S.A. offers no warranty whatsoever for information contained in this manual. Teldat S.A. is not liable for any direct, indirect, collateral, consequential or any other damage connected to the delivery, supply or use of this manual.

  • Page 3: Product Overview

    Windbit Hardware Installation and Reference Guide 1 Product Overview The ESW1L3 and ESW2L3 series switches are new generation layer 3 switches, providing high performance, consolidated security and multiple services. The switches are mainly applied to the access layer to provide line-rate switching and complete QoS policies, prioritizing some traffic over others to ensure important data transmission without lantency.
  • Page 4 • SFP Modules and SFP BIDI Modules • SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules. SFP Module Type The module types may update without prior notification. Please contact Windbit for details. • AC Input • Rated Voltage Range: 100 V AC to 240 V AC •...
  • Page 5 Windbit Hardware Installation and Reference Guide Dimensions (W x D x H) 442 mm x 220 mm x 43.6 mm (17.40 in. x 8.66 in. x 1.72 in.) Weight 2.7 kg (5.95 lbs.) Appearance The front panel of the ESW1L3-24GE4XS-E switch provides 24 10/100/1000Base-T Ethernet ports, four 10GE SFP+ ports, one management port, one Console port and one USB port.
  • Page 6 Windbit Hardware Installation and Reference Guide 1. Grounding Stud 2. AC Power Plug Power Supply The ESW1L3-24GE4XS-E switch has a built-in power supply module. The back panel has an an AC power plug. Cooling ESW1L3-24GE4XS-E switch adopts a left-to-right and front-to-right airflow to ensure normal operation. Maintain a minimum clearance of 100 mm (3.94 in.) around the device for air circulation.
  • Page 7 ⚫ SFP Modules and SFP BIDI Modules ⚫ SFP Module Type SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules. The module types may update without prior notification. Please contact Windbit for details. ⚫ AC Input ⚫ Rated Voltage Range: 100 V AC to 240 V AC ⚫...
  • Page 8 Windbit Hardware Installation and Reference Guide Fan Speed Control Fan Fault Alarming Temperature Supported Alarming EMI Certification EMC DIRECTIVE 2014/30/EU (CLASS A) Safety Regulation LVD DIRECTIVE 2014/35/EU Compliance Dimensions (W x D x H) 442 mm x 220 mm x 43.6 mm (17.40 in. x 8.66 in. x 1.72 in.) Weight 3 kg (6.61 lbs.)
  • Page 9 Windbit Hardware Installation and Reference Guide 1. Grounding Stud 2. AC Power Plug Power Supply The ESW1L3-48GE4XS-E switch has a built-in power supply module. The back panel has an AC power plug. Cooling The ESW1L3-48GE4XS-E switch adopts a left-to-right and front-to-right airflow to ensure normal operation. Maintain a minimum clearance of 100 mm (3.94 in.) around the device for air circulation.
  • Page 10 ⚫ SFP Modules and SFP BIDI Modules ⚫ SFP Module Type SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules. The module types may update without prior notification. Please contact Windbit for details. • AC Input • Rated Voltage Range: 100 V AC to 240 V AC •...
  • Page 11 • SFP Modules and SFP BIDI Modules • SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules. SFP Module Type The module types may update without prior notification. Please contact Windbit for details. Power Supply Module Slots  Power Supply Module ESWPSUA/0IB-F ESW1L3 &...
  • Page 12 Windbit Hardware Installation and Reference Guide AC Input Rated Voltage Range: 100 V AC to 240 V AC Maximum Voltage Range: 90 V AC to 264 V AC Frequency: 50 Hz/60 Hz Rated Current Per Circuit: 2 A  Model: ESWPSUA150IB-F...
  • Page 13 Windbit Hardware Installation and Reference Guide Front Panel Figure 1-10 Front Panel of ESW2L3-24GE4XS-E 1. System Status LED 7. Management Port 2. MGMT Port LED 8. 10/100/1000Base-T Ethernet Port 3. PWR1 Status LED 9. 10GE SFP+ Port 4. PWR2 Status LED 10.
  • Page 14 Windbit Hardware Installation and Reference Guide Cooling The ESW2L3-24GE4XS-E switch adopts a left-to-right and front-to-right airflow to ensure normal operation. Maintain a minimum clearance of 100 mm (3.94 in.) around the device for air circulation. Figure 1-12 Airflow Direction Function...
  • Page 15 SFP+ Port: ⚫ SFP Modules and SFP BIDI Modules ⚫ SFP Module Type SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules. The module types may update without prior notification. Please contact Windbit for details. Power Supply Module Slots  ESWPSUA/0IB-F...
  • Page 16 Windbit Hardware Installation and Reference Guide 1000Base-X Capable Supported Not supported Power Consumption < 55 W 0ºC to 45ºC (32ºF to 113 ºF) at a height below 1800 m (1.12 miles) above the sea level Operating At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the Temperature maximum operating temperature decreases by 1°C (1.8°F) every time the altitude increases...
  • Page 17 Windbit Hardware Installation and Reference Guide 1. System Status LED 7. Management Port 2. Management Port LED 8. 10/100/1000Base-T Ethernet Port 3. PWR1 Status LED 9. 10GE SFP+ Port 4. PWR2 Status LED 10. Port LED 5. USB Port 6. Console Port...
  • Page 18 Windbit Hardware Installation and Reference Guide Function Panel ID Color Status System is not powered on. Blinking Green System is being initialized. Continuous blinking (3 Hz) indicates a fault. Blinking Green System is being located. (10 Hz) System Status LED...
  • Page 19 SFP+ Port: ⚫ SFP Modules and SFP BIDI Modules ⚫ SFP Module Type SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules. The module types may update without prior notification. Please contact Windbit for details. Power Supply Module Slots  ESWPSUA600I-P-F...
  • Page 20 Windbit Hardware Installation and Reference Guide The PoE+ port is compliant with both the PoE (IEEE802.3af) and PoE+ (IEEE802.3at) standards. The maximum number of PoE devices supported by the switch is determined by the available PoE consumption of the switch and the actual PoE consumption of each device.
  • Page 21 Windbit Hardware Installation and Reference Guide Front Panel Figure 1-18 Front Panel of ESW2L3-24GE4XS-P 1. System Status LED 7. USB Port 2. Management Port LED 8. Console Port 3. PWR1 Status LED 9. Management Port 4. PWR2 Status LED 10. 10/100/1000Base-T Ethernet Port 5.
  • Page 22 Windbit Hardware Installation and Reference Guide Function Panel ID Color Status System is not powered on. Blinking Green System is being initialized. Continuous blinking (3 Hz) indicates a fault. Blinking Green System is being located. (10 Hz) System Status LED...
  • Page 23 SFP+ Port: ⚫ SFP Modules and SFP BIDI Modules ⚫ SFP Module Type SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules. The module types may update without prior notification. Please contact Windbit for details. Power Supply Module Slots  ESWPSUA600I-P-F...
  • Page 24 Windbit Hardware Installation and Reference Guide Maximum Voltage Range: 176 V AC to 264 V AC Frequency: 50 Hz/60 Hz Rated Current Per Circuit: 8 A 10GBase-R Capable SFP+ Port 1000Base-X Capable Supported All RJ45 ports are PoE+ capable and each port provides up to 30 W of power.
  • Page 25 Windbit Hardware Installation and Reference Guide Front Panel Figure 1-22 Front Panel of ESW1L3-24GE4XS-P 1. System Status LED 7. Management Port 2. Management Port LED 8. 10/100/1000Base-T Ethernet Port 3. LED Mode Indicator 9. 10GE SFP+ Port 4. LED Mode Button 10.
  • Page 26 Windbit Hardware Installation and Reference Guide Function Panel ID Color Status System is not powered on. Blinking Green System is being initialized. Continuous blinking (3 Hz) indicates a fault. Blinking Green System is being located. (10 Hz) System Status LED...

  • Page 27: Power Supply Module

    Windbit Hardware Installation and Reference Guide Blinking Green PoE overload occurs. (3 Hz) LED Mode Button The LED Mode button is used to switch the LED mode. The green LED Mode indicator indicates the switching status. Press the LED Mode button, and the LED Mode indicator will turn yellow, indicating the PoE status. Press the LED Mode button again, the indicator switches to indicating the switching status.
  • Page 28 Windbit Hardware Installation and Reference Guide Relative Storage 5% to 95% RH (non-condensing) Humidity Operating Height 0 to 5000 m (3.11 miles) above the sea level Features Feature Benefit Conformal Coating Moisture-proof, salt spray-proof, mold-proof, insulation-proof and leak-proof. Undervoltage protection, output overcurrent protection, output overvoltage protection and Protection output short circuit protection.
  • Page 29 Windbit Hardware Installation and Reference Guide Maximum Output Power 150 W Ground Leakage ≤ 3.5 mA Current Dimensions (W x D x H) 196 mm x 50.5 mm x 40 mm (7.72 in. x 1.99 in. x 1.57 in.) Weight 0.55 kg (1.21 lbs.)
  • Page 30 Windbit Hardware Installation and Reference Guide Power Supply Model ESWPSUA600I-P-F Switch Model ESW2L3-24GE4XS-P, ESW2L3-48GE4XS-P Rated Input Voltage AC Input: 100 V AC to 240 V AC,50 Hz/60 Hz Range HVDC Input: 240 V DC Maximum Input Voltage AC Input: 90 V AC to 264 V AC, 47 Hz/63 Hz...
  • Page 31 Windbit Hardware Installation and Reference Guide overvoltage protection, power supply failure and overheat protection. Solid Green The power supply module is outputing power normally. 1.8.4 ESWPSUA1000I-P-F Module The ESW2L3-24GE4XS-P and ESW2L3-48GE4XS-P switches support the ESWPSUA1000I-P-F power module. The ESWPSUA1000I-P-F module is an AC module (AC/HVDC input and DC output) providing an output voltage of 56 V and an output power of up to 1000 W (PoE power: 740 W).
  • Page 32 Windbit Hardware Installation and Reference Guide Features Benefit Conformal Coating Moisture-proof, salt spray-proof, mold-proof, insulation-proof and leak-proof Undervoltage protection, output overcurrent protection, output overvoltage protection and Protection output short circuit protection I2C Communication The switch can communicate with the power supply module through I2C.

  • Page 33: Preparing For Installation

    Windbit Hardware Installation and Reference Guide 2 Preparing for Installation 2.1 Safety Precautions To avoid personal injury and device damage, carefully read the safety precautions before you install the switch. The following safety precautions may not cover all possible dangers.

  • Page 34: Installation Environment Requirements

    Windbit Hardware Installation and Reference Guide (that is, Action current of the leakage protector/2/Maximum leakage current of each power supply = 30/2/1.75 ≈ 8.57). In other words, the leakage protector with 30 mA rated action current supports no more than eight power supplies. In this case, the 16 power supplies in the system require at least two leakage protectors with 30 mA rated action current and each leakage protector supports eight power supplies.

  • Page 35: Cleanliness Requirements

    Windbit Hardware Installation and Reference Guide ⚫ In an environment with high relative humidity, the insulating material may have poor insulation or even leak electricity. ⚫ In an environment with low relative humidity, static electricity is prone to occur and damage the internal circuits of the switch.
  • Page 36 Windbit Hardware Installation and Reference Guide ⚫ Route interface cables only indoors to prevent signal ports from getting damaged by overvoltage or overcurrent caused by lightning strikes. 2.2.5 Grounding Requirements A proper grounding system is the basis for stable and reliable running and is indispensable for preventing lightning strikes and interference.

  • Page 37: Emi Requirements

    Windbit Hardware Installation and Reference Guide 2.2.7 EMI Requirements All interference sources, either from outside or inside of the device or application system, affect the device by capacitive coupling, inductive coupling, or electromagnetic waves. Electromagnetic interference (EMI) occurs due to electromagnetic radiation or conduction, depending on the transmission path.

  • Page 38: Installing The Switch

    Windbit Hardware Installation and Reference Guide 3 Installing the Switch Ensure that requirements in Chapter 2 are all met. ESW1L3 & ESW2L3 Series Switches...

  • Page 39: Installing Procedure

    Windbit Hardware Installation and Reference Guide 3.1 Installing Procedure Prepare for installation Prepare for installation Install the rack Mount the switch into the rack Ground the switch Install the modules Turn on the power Connect the cables Bundle the cables Verify the installation ESW1L3 &...

  • Page 40: Before You Begin

    3.3.1 Mounting the Switch in a Rack All models of the ESW1L3 series switches can be installed in a standard 19-in. four-post EIA rack. All models of the ESW2L3 series switches can be installed in a standard 19-in. four-post EIA rack. Mount the switch in the rack with the front panel face forward.
  • Page 41 Windbit Hardware Installation and Reference Guide Install two cage nuts on the inside of each front rack and drive the screws halfway into the cage nuts. Figure 3-2 Installing Cage Nuts and Screws Secure the switch on the rack rails by tightening the screws.

  • Page 42: Mounting The Switch On The Wall

    Hardware Installation and Reference Guide 3.3.2 Mounting the Switch on the Wall All models of the ESW1L3 series switches can be installed on the wall. All models of the ESW2L3 series switches cannot be installed on the wall. Rotate the brackets by 90 degrees and secure the brackets to the switch by using the screws.

  • Page 43: Installing And Removing A Power Supply Module

    Windbit Hardware Installation and Reference Guide 3.4 Installing and Removing a Power Supply Module Wear an anti-static wrist strap before the following operation. Installing the AC Power Supply Module Remove the module from its packing materials and make sure the input specifications meet requirements.

  • Page 44: Connecting Cables

    Windbit Hardware Installation and Reference Guide Notes ⚫ The sectional area of the grounding wire should be determined according to the possible maximum current. Cables of good conductor should be used. ⚫ Do not have bare wires exposed ⚫ Grounding resistance: Less than 1 ohm.

  • Page 45: Verifying Installation

    Windbit Hardware Installation and Reference Guide On both sides of the chassis, fasten the fibers and twisted pairs to the cable management ring or cabling chute. For the power cords, you should bundle them closely along the bottom of the chassis, in a straight line wherever possible.

  • Page 46: Setting Up Configuration Environment

    Windbit Hardware Installation and Reference Guide 4 Verifying Operating Status 4.1 Setting up Configuration Environment Setting up Configuration Environment Connect the PC to the management port of the switch with an Ethernet cable. Figure 4-1 Configuring Environment Connecting an Ethernet Cable ⚫...
  • Page 47 Windbit Hardware Installation and Reference Guide ⚫ The power supply voltage complies with the requirement of the switch. ⚫ The Ethernet cable is properly connected. The terminal (it can be a PC) used for configuration is already started. The parameters are already configured.

  • Page 48: Monitoring And Maintenance

    Windbit Hardware Installation and Reference Guide 5 Monitoring and Maintenance 5.1 Monitoring When the switch is running, you can monitor the module status by observing the module LED. ⚫ If the SYS indicator is red, it indicates that the system is faulty. Log in to the web-based management system to troubleshoot the fault.
  • Page 49 Windbit Hardware Installation and Reference Guide Replacing Lithium Battery The device has a built-in lithium battery to maintain the real-time clock without external power to the switch. To replace the lithium battery, contact technical support personnel. Replacing the battery with the wrong type may cause explosion or danger. If the battery is damaged, please replace it with the same type.

  • Page 50: Troubleshooting Flowchart

    Windbit Hardware Installation and Reference Guide 6 Troubleshooting 6.1 Troubleshooting Flowchart The device is not working properly Check the rack installation Check the device installation Check the power connection Check the installation of the power supply module Check the connector of each module...
  • Page 51 Check whether the configuration of the serial port on the HyperTerminal is consistent with that in Configuration Guide. If there is still no output on the serial port, please contact Windbit technical support. Fault 4: The serial port console output is garbled.
  • Page 52 Windbit Hardware Installation and Reference Guide Check whether the wavelength of the SFP modules on the two sides are consistent. For example, an SFP module with a wavelength of 1310 nm cannot be connected to an SFP module of 1550 nm.
  • Page 53 Windbit Hardware Installation and Reference Guide 7 Appendix 7.1 Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T The 1000BASE-T/100BASE-TX/10BASE-T is a 10/100/1000 Mbps auto-negotiation port that supports auto MDI/MDIX Crossover. Compliant with IEEE 802.3ab, 1000BASE-T requires Category 5e 100-ohm UTP or STP (STP is recommended) with a maximum distance of 100 meters (328 feet).
  • Page 54 Windbit Hardware Installation and Reference Guide Fiber Connection You can choose single mode or multimode fibers according to the module types. Figure 7- shows connection of fiber-optic cable. Figure 7-3 Fiber-Optic Cable Connection ESW1L3 & ESW2L3 Series Switches...

  • Page 55: Lightening Protection

    Windbit Hardware Installation and Reference Guide 7.2 Lightening Protection Installing AC Power Arrester (Lightning Protection Power Strip) The AC power port must be connected to an external lightning protection power strip to prevent the switch from being struck by lightning when the AC power cord is introduced from the outdoor and directly connected to the power port of the switch.
  • Page 56 Windbit Hardware Installation and Reference Guide Tools: Phillips screwdrivers or flat-head screwdriver, multimeter, and diagonal pliers Installation Steps: Tear one side of the protective paper for the double-sided adhesive tape and paste the tape to the housing of the Ethernet port arrester. Tear the other side of the protective paper for the double-sided adhesive tape and paste the Ethernet port arrester to the switch housing.
  • Page 57 Windbit Hardware Installation and Reference Guide ESW1L3 & ESW2L3 Series Switches...
  • Page 58 Windbit Hardware Installation and Reference Guide 7.3 Cabling When the switch is installed in a standard 19-inch rack, secure the cables around the cable management brackets. Top cabling or bottom cabling is adopted according to the actual situation in the equipment room. All transferred cable connectors should be placed at the bottom of the rack in an orderly manner instead of outside the rack that is easy to touch.
  • Page 59 Windbit Hardware Installation and Reference Guide ⚫ Cables of different types (such as power cords, signal cables, and ground cables) should be separated in cabling and bundling. Mixed bundling is disallowed. When they are close to each other, it is recommended to adopt crossover cabling.
  • Page 60 Windbit Hardware Installation and Reference Guide ⚫ The power cords connecting moving parts such as door grounding wires should be reserved with some access after being assembled to avoid suffering tension or stress. After the moving part is installed, the remaining cable part should not touch heat sources, sharp corners, or sharp edges.

  • Page 61: Site Selection

    Windbit Hardware Installation and Reference Guide 7.4 Site Selection ⚫ The equipment room should be at least 5 km away from heavy pollution sources, such as the smelter works, coal mine, and thermal power plant. The equipment room should be at least 3.7 km away from medium pollution sources, such as the chemical factory, rubber factory, and electroplating factory.
