- Page 1 PORTABLE WELDING CARRIAGE WELDYPOCKET SAFETY INSTRUCTION FOR USE AND MAINTENANCE 8695 5875 EDITION : EN Instructions for use REF : REVISION : D DATE : 10-2018 Original instructions...
- Page 2 Thank for the trust you have expressed by purchasing this equipment, which will give you full satisfaction if you follow its instructions for use and maintenance. Its design, component specifications and workmanship comply with applicable European directives. Please refer to the enclosed CE declaration to identify the directives applicable to it.
-
Page 3: Table Of Contents
2 - TECHNICAL SPECIFICATIONS ..................7 D - INSTRUCTIONS FOR USE ......................8 1 - CARRIAGE .......................... 8 2 - OPERATING OF WELDYPOCKET ..................10 E - MAINTENANCE ..........................12 1 - SERVICING ......................... 12 2 - SPARE PARTS ........................13 3 - WIRING DIAGRAM ...................... - Page 4 The measuring tools or displays for voltage, intensity and speed ..either analog or digital, must be considered as indicators REVISIONS REVISION B 07/09 DESIGNATION PAGE Update E14-E15 REVISION C 08/14 DESIGNATION PAGE Spare parts REVISION D 10/18 DESIGNATION PAGE To change logos WELDYPOCKET...
-
Page 5: A - Identification
8695 5875 / D A - IDENTIFICATION Please enter the number of your equipment in the following box. Quote this information in all correspondence. WELDYPOCKET... -
Page 6: B - Safety Instructions
Periodically check that electrical connections are properly tightened and do not overheat. WARNING ! Be careful not to crush your fingers Make sure that no spray or water enters into the electrical box of the carriage. IP23 PROTECTION WELDYPOCKET... - Page 7 B - SAFETY INSTRUCTIONS 8695 5875 / D WELDYPOCKET...
-
Page 8: C - Description
Charger On /Off Control panel A) MOTORIZATION WELDYPOCKET is driven by a 9,6 V CC motor. The carriage is autonomous. The battery ensures a continuous work during 5 hours. The four drive wheels have a rubber coating and a disengagement... - Page 9 The crabbing is obtained by setting back front roller from the back roller. Adjusting crabbing for the advance direction Adjusting crabbing for the advance direction Advance direction from left to right Advance direction from right to left WELDYPOCKET...
- Page 10 25mm which have different fixation steps. The torch holder enables an easy and quick setting, and can be changed by a specific tool E) CARRYING Lightweight 5 kg and handy (M5), WELDYPOCKET can be held easily by an operator for a fast commissioning. WELDYPOCKET...
-
Page 11: Technical Specifications
15 to 120 cm/mn Magnetic attraction 15 kg Protection index IP 23 Trigger control 1 contact 1T/1A Operating temperature -5°C to +50°C Storage temperature -10°C to +70°C Relative humidity <90% Length 240 mm Width 140 mm Height 220 mm WELDYPOCKET... -
Page 12: D - Instructions For Use
- selection of the displacement direction (right) Active arc sensor led B) MAGNETISATION BASE The magnetisation base of the carriage allows the WELDYPOCKET to weld on tilted plan without any tools. The surface with the copper rollers is magnetic, which allows a better follow of the guidance piece. - Page 13 Connect the charger to a main connector 220-240V / 50-60 Hz. When the battery is well connected, according to the polarities, green warning light goes red and the charge begins. The light remains red during all the charging time. When the charge is over, the light turns green. WELDYPOCKET...
-
Page 14: Operating Of Weldypocket
D - INSTRUCTIONS FOR USE 8695 5875 / D 2 - OPERATING OF WELDYPOCKET When power is turned on with M12 - The direction is automatically set to the right - The automatic start arc sensor is activated (green led lit) Carriage movement - Either by pressing the ‘’start / stop’’... - Page 15 D - INSTRUCTIONS FOR USE 8695 5875 / D WELDYPOCKET D-11...
-
Page 16: E - Maintenance
- adjust the clearance of guiding shims on the slides - adjust the clearance of the geared motor on the large sprocket wheel. - wash and grease the wheels. - blow very carefully the electronic card, speed regulator, electric rack. WELDYPOCKET E-12... -
Page 17: Spare Parts
W000XXXXXX Machine interface board W000XXXXXX Flowmeter 9357 XXXX Silk-screen printed front panel For parts order, give the quantity required and put the number of your machine in the box below. TYPE: Number: WELDYPOCKET E-13... - Page 18 E - MAINTENANCE 8695 5875 / D WELDYPOCKET E-14...
- Page 19 Set of 2 wheel battery side W000275063 Set of 2 wheel belt side W000275062 Drive belt For parts order, give the quantity required and put the number of your machine in the box below. TYPE: Number: WELDYPOCKET E-15...
-
Page 20: Wiring Diagram
E - MAINTENANCE 8695 5875 / D 3 - WIRING DIAGRAM CD1/M1 GREEN GREY BLACK 9.6Vcc A0/A1 CDE/V1 WELDYPOCKET E-16... -
Page 21: Electrical Maintenance
Note : If the carriage is overloaded, the display indicates "Err" ; turn off and on the power supply to reinitialize If the problem persists, return the carriage to Customer Support (SAV) for evaluation.. WELDYPOCKET E-17... -
Page 22: Personal Notes
E - MAINTENANCE 8695 5875 / D PERSONAL NOTES Lincoln Electric France S.A.S. Avenue Franklin Roosevelt 76120 Le Grand Quevilly 76121 Le Grand Quevilly cedex www.lincolnelectriceurope.com WELDYPOCKET E-18...
