ROUND GAS TILTING SKILLET
MODEL VGCTS16
MODEL
VGCTS16
V U L C A N - H A R T C O M P A N Y , P . O . B O X 6 9 6 , L O U I S V I L L E , K Y 4 0 2 0 1 - 0 6 9 6 , TEL. (502) 7 7 8 - 2 7 9 1
FORM 31041 (12-97)
ML-114827
INSTALLATION &
OPERATION MANUAL
MODEL VGCTS16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VGCTS16 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vulcan-Hart VGCTS16

  • Page 1 ROUND GAS TILTING SKILLET MODEL VGCTS16 MODEL VGCTS16 ML-114827 V U L C A N - H A R T C O M P A N Y , P . O . B O X 6 9 6 , L O U I S V I L L E , K Y 4 0 2 0 1 - 0 6 9 6 , TEL. (502) 7 7 8 - 2 7 9 1 FORM 31041 (12-97) INSTALLATION &...
  • Page 2 READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT. IN THE EVENT OF A POWER FAILURE, DO NOT ATTEMPT TO OPERATE THIS DEVICE. © VULCAN-HART COMPANY, 1997 IMPORTANT FOR YOUR SAFETY WARNING — 2 —...
  • Page 3: Table Of Contents

    GENERAL............... 4 INSTALLATION .
  • Page 4: General

    Your Vulcan Round Tilting Skillet is a versatile piece of equipment. It allows you to stew, simmer, pan fry, braise, grill, or saute, and all with a very uniform heat pattern. Capacity of Model VGCTS16 is 16 gallons (4.2 liters).
  • Page 5: Installation Codes And Standards

    Do not permit fans to blow directly at the skillet. Wherever possible, avoid open windows next to the skillet. Avoid wall-type fans which create air cross currents within the room. INSTALLATION CODES AND STANDARDS The Vulcan tilting skillet must be installed in accordance with: In the United States of America: 1. State and local codes.
  • Page 6: Leveling

    LEVELING Place a carpenter's level on top of the skillet. Level the skillet front to back and side to side by turning the adjustable feet. GAS CONNECTIONS Gas supply connections and any pipe joint compound used must be resistant to the action of propane gases.
  • Page 7: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING: ELECTRICAL AND GROUNDING CONNECTIONS MUST COMPLY WITH THE APPLICABLE PORTIONS OF THE NATIONAL ELECTRICAL CODE AND/OR OTHER LOCAL ELECTRICAL CODES. WARNING: THE SUPPLY CORD ON THE GAS TILTING SKILLET IS PROVIDED WITH A THREE- PRONG GROUNDING PLUG. IT IS IMPERATIVE THAT THIS PLUG BE CONNECTED INTO A PROPERLY GROUNDED THREE-PRONG RECEPTACLE.
  • Page 8: Floor Plan

    FLOOR PLAN (Shown with and without optional stand and drain pan accessory) 29-1/4 (743) 5-5/8 DRAIN (143) 17-5/8 (448) (660) 26 (660) ID 24-7/8 (381) DRAIN 9-5/8 (244) 4-1/4 (108) 15/16 (24) 2-3/4 (70) 1-3/4 (44) 13-5/16 (356) (194) 29-7/8 (759) 7/16 (11) O 2-1/8 (54)
  • Page 9: Operation

    WARNING: THE TILTING SKILLET AND ITS PARTS ARE HOT. USE CARE WHEN OPERATING, CLEANING OR SERVICING THE TILTING SKILLET. CONTROLS (Fig. 1) Thermostat — Maintains set temperature by controlling power supply. Temperature range is from Off to 450 F (232 C). Power Switch —...
  • Page 10: Lighting The Tilting Skillet

    LIGHTING THE TILTING SKILLET 1. Open main gas valve. 2. Ensure skillet is in the DOWN position. 3. Turn Power Switch ON. Set thermostat dial to desired setting. This will turn on the electronic ignition. The gas solenoid valve will open, supplying gas to the burner. The RED temperature light and the GREEN ignition light will come on.
  • Page 11: Cleaning

    6. At the end of cooking, turn the Thermostat to OFF and turn the Power Switch to OFF. 7. Skillet Without Optional Stand: Tilt the skillet to empty product into a food receiving pan. Skillet With Optional Stand: The skillet is provided with a stationary support for holding the drain pan.
  • Page 12: Maintenance

    To obtain service and parts information concerning this tilting skillet, contact the Vulcan-Hart Service Agency in your area (refer to listing supplied with the skillet), or Vulcan-Hart Company Service Department at the address or phone number shown on the front cover of this manual.
