Vulcan-Hart VGCTS16 Specifications

SPECIFICATIONS:
Round gas tilting braising pan, Vulcan-Hart Model
No. VGCTS16. Stainless steel front and sides. 10 gauge
polished stainless steel pan body with coved interior corners.
3
Stainless steel / " clad cooking surface. Formed pouring lip.
8
The pan pivots on trunnions. Pan can be fully tilted.
30,000 BTU/hr. stainless steel round burner with electronic
ignition system. Burners shut off when pan is tilted 5°. Faucet
bracket. Controls include a solid state thermostat adjustable
from 100° to 450°F. Mounted on a stand with sliding drain pan.
Requires a 120 volt, 60 Hz, 1 phase control circuit, 3 amps total
draw.
1
Exterior dimensions: 29 / "w x 29
4
with handle 59 1 / "h.
4
CSA design certified. NSF listed.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32278 (10-03)
7 1
/ "d x 43 / " overall height;
8 4
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MODEL VGCTS16
ROUND GAS TILTING BRAISING PAN
STANDARD FEATURES
Stainless steel front and sides. 10 gauge polished stainless
steel pan body with coved interior corners.
Stainless steel 3 / " clad cooking surface. Formed pouring
8
lip.
The pan pivots on trunnions. Pan can be fully tilted.
30,000 BTU/hr. stainless steel round burner with electronic
ignition system. Burners shut off when pan is tilted 5°.
Faucet bracket.
Controls include a solid state thermostat adjustable from
100° to 450°F. Mounted on a stand with sliding drain pan.
Requires a 120 volt, 60 Hz, 1 phase control circuit, 5 amp
total draw. Furnished with cord and plug.
One year limited parts and labor warranty.
OPTIONS
Etched gallon markings.
Pour lip strainer.
Correction facility package:
- Control cover (lock by others).
- Security type tamper resistant fasteners with tack welds.
Second year extended limited parts and labor warranty.
ACCESSORIES
12" swing faucet, single temperature.
12" swing faucet, dual temperature.
18" swing faucet, single temperature.
18" swing faucet, dual temperature.
Steaming pan insert rack to hold 12" x 20" food pans.
Lift off cover.
C.S.I. Section 11420
