- Page 1 INSTALLATION & OPERATION MANUAL ROUND GAS TILTING SKILLET MODEL VGTRS35 MODEL VGTRS35 ML-114950 V U L C A N - H A R T C O M P A N Y , P.O. BOX 696, LOUISVILLE, KY 40201-0696, TEL. (502) 778-2791 FORM 31061 (4-98) Get other manuals https://www.bkmanuals.com...
- Page 2 CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT. IN THE EVENT OF A POWER FAILURE, DO NOT ATTEMPT TO OPERATE THIS DEVICE. — 2 — © VULCAN-HART COMPANY, 1998 Get other manuals https://www.bkmanuals.com...
-
Page 3: Table Of Contents
TABLE OF CONTENTS GENERAL............... 4 INSTALLATION . -
Page 4: General
GENERAL Your Vulcan-Hart Round Tilting Skillet is a versatile piece of equipment. It allows you to stew, simmer, pan fry, braise, grill, or saute, and all with a very uniform heat pattern. Capacity of Model VGTRS35 is 35 gallons. Vulcan-Hart tilting skillets are produced with quality workmanship and material. Proper installation, usage and maintenance of your tilting skillet will result in many years of satisfactory performance. -
Page 5: Installation Codes And Standards
The skillet must be installed so that the flow of combustion and ventilation air will not be obstructed. Adequate clearance for air openings into the combustion chamber must be provided. Make sure there is an adequate supply of air in the room to allow for that required for combustion of gas at the burners. Do not permit fans to blow directly at the skillet. -
Page 6: Gas Connections
6. Place carpenter's level on top of skillet and re-level side to side and front to back. 7. Bolt and anchor skillet securely to the floor. 8. Seal bolts and flanged feet with silicone or equivalent compound. GAS CONNECTIONS Gas supply connections and any pipe joint compound must be resistant to the action of propane gases. Location of the gas inlet is at the rear of the skillet. -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: ELECTRICAL AND GROUNDING CONNECTIONS MUST COMPLY WITH THE APPLICABLE PORTIONS OF THE NATIONAL ELECTRICAL CODE AND/OR OTHER LOCAL ELECTRICAL CODES. WARNING: APPLIANCES EQUIPPED WITH A FLEXIBLE ELECTRIC SUPPLY CORD ARE PROVIDED WITH A THREE-PRONG GROUNDING PLUG. IT IS IMPERATIVE THAT THIS PLUG BE CONNECTED INTO A PROPERLY GROUNDED THREE-PRONG RECEPTACLE. -
Page 8: Operation
OPERATION WARNING: THE TILTING SKILLET AND ITS PARTS ARE HOT. USE CARE WHEN OPERATING, CLEANING OR SERVICING THE TILTING SKILLET. CONTROLS (Fig. 1) POWER SWITCH TEMPERATURE LIGHT THERMOSTAT IGNITION LIGHT PL-41053-1 Fig. 1 Thermostat — Maintains set temperature by controlling power supply. Power Switch —... -
Page 9: Lighting The Tilting Skillet
LIGHTING THE TILTING SKILLET 1. Open main gas valve. 2. Ensure skillet is in the UPRIGHT position. 3. Turn power switch ON. Set thermostat dial to desired setting. This will turn on the electronic ignition. The gas solenoid valve will open, supplying gas to the burner. The RED temperature light and the GREEN ignition light will come on. -
Page 10: Cleaning
The following are approximate temperature equivalents for the Thermostat dial settings: Approx. Temp. Setting (°F) (°C) 1 - 4 100 - 200 38 - 93 5 - 6 225 - 275 107 - 135 7 - 8 300 - 350 149 - 177 8 - 9 325 - 375... -
Page 11: Maintenance
To obtain service and parts information concerning this tilting skillet, contact the Vulcan-Hart Service Agency in your area (refer to listing supplied with the skillet), or Vulcan-Hart Company Service Department at the address or phone number shown on the front cover of this manual. - Page 12 NOTES FORM 31061 (4-98) PRINTED IN U.S.A — 12 — Get other manuals https://www.bkmanuals.com...
